Camera
Module
|
|
Image Sensor
|
1/2.8" progressive
scan CMOS
|
|
Min. Illumination
|
Color: 0.005 Lux @(F1.6,
AGC ON) B/W: 0.001Lux @(F1.6, AGC ON)
0 Lux with IR
|
|
White Balance
|
Auto / Manual / ATW
(Auto-tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium
Lamp
|
|
Gain
|
Auto / Manual
|
|
Shutter Time
|
50Hz: 1 / 1 s to 1 / 30,000
s
60Hz: 1 / 1 s to 1 / 30,000
s
|
|
Day & Night
|
IR Cut Filter
|
|
Digital Zoom
|
16×
|
|
Privacy Mask
|
24 programmable privacy
masks
|
|
Focus Mode
|
Auto / Semi-automatic / Manual
|
|
WDR
|
120 dB WDR
|
|
Lens
|
|
Focal Length
|
4.8 mm to 120 mm, 25×
optical zoom
|
|
Zoom Speed
|
Approx. 3.6 s (optical
lens, wide-tele)
|
|
Field of View
|
Horizontal field of view:
57.6° to 2.5° (Wide-Tele) Vertical field of view: 34.4° to 1.4° (Wide-Tele)
Diagonal field of view: 64.5° to 2.9° (Wide-Tele)
|
|
Working Distance
|
10 mm to 1500 mm
(wide-tele)
|
|
Aperture Range
|
F1.6 to F3.5
|
|
IR
|
|
IR Distance
|
100 m
|
|
Smart IR
|
Support
|
|
PTZ
|
|
Movement Range (Pan)
|
360° endless
|
|
Pan Speed
|
Configurable, from 0.1°/s
to 80°/s, Preset speed: 80°/s
|
|
Movement Range (Tilt)
|
From -15° to 90°
(auto-flip)
|
|
Tilt Speed
|
Configurable, from 0.1°/s
to 80°/s Preset Speed: 80°/s
|
|
Proportional Zoom
|
Support
|
|
Presets
|
300
|
|
Patrol Scan
|
8 patrols, up to 32 presets
for each patrol
|
|
Pattern Scan
|
4 pattern scans, record
time over 10 minutes for each scan
|
|
Power-off Memory
|
Support
|
|
Park Action
|
Preset / Pattern Scan / Patrol
Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan
|
|
3D Positioning
|
Support
|
|
PTZ Position Display
|
Support
|
|
Preset Freezing
|
Support
|
|
Scheduled Task
|
Preset / Pattern Scan / Patrol
Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan / Dome
Reboot / Dome Adjust / Aux Output
|
|
Compression
Standard
|
|
Video Compression
|
Main Stream: H.265+ / H.265
/ H.264+ / H.264
Sub-stream: H.265 / H.264 /
MJPEG
Third Stream: H.265 / H.264
/ MJPEG
|
|
H.264 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.264+
|
Support
|
|
H.265 Type
|
Baseline Profile / Main
Profile / High Profile
|
|
H.265+
|
Support
|
|
Video Bitrate
|
32 Kbps to 16384 Kbps
|
|
Audio Compression
|
G.711alaw / G.711ulaw / G.722.1
/ G.726 / MP2L2 / PCM
|
|
Audio Bitrate
|
G.711alaw / G.711ulaw: 64
Kbps
G.722.1 / G.726: 16 Kbps
MP212 / PCM: 32 Kbps / 64
Kbps / 128 Kbps
|
|
SVC
|
Support
|
|
Smart
Features
|
|
Basic Event
|
Motion Detection, Video
Tampering Detection, Exception
|
|
Smart Event
|
Intrusion Detection, Line
Crossing Detection, Region Entrance Detection, Region Exiting Detection,
Object Removal Detection, Unattended Baggage Detection
|
|
Smart Record
|
ANR (Automatic Network
Replenishment), Dual-VCA
|
|
ROI
|
Main stream, sub-stream,
and third stream respectively support four fixed areas.
|
|
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) |
|
Sub-Stream
|
50Hz: 25fps (704 × 576, 640
× 480, 352 × 288)
60Hz: 30fps (704 × 480, 640
× 480, 352 × 240)
|
|
Third Stream
|
50Hz: 25fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Image Enhancement
|
HLC / BLC / 3D DNR / Defog
/ EIS / Regional Exposure / Regional Focus
|
|
Network
|
|
Network Storage
|
Built-in memory card slot,
support Micro SD / SDHC / SDXC, up to 256 GB; NAS (NPS, SMB / CIPS), ANR
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS,
802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP,
UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
|
API
|
Open-ended, support ONVIF,
ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
|
|
Security Measures
|
User authentication (ID and
PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x
port-based network access control; IP address filtering
|
|
Client
|
iVMS-4200, iVMS-4500,
iVMS-5200, Hik-Connect
|
|
Interface
|
|
Audio Interface
|
1-ch audio input and 1-ch
audio output
|
|
Network Interface
|
1 RJ45 10 M/100 M Ethernet,
PoE+ (802.3 at, class4)
|
|
General
|
|
Power
|
12 VDC and PoE+ (802.3 at,
class4)
Max.: 18 W (Max. 7W for IR)
|
|
Working Temperature
|
-30°C to 65°C (-22°F to
149°F)
|
|
Working Humidity
|
≤ 90%
|
|
Protection Level
|
IP66 Standard, TVS 4000V
Lightning Protection, Surge Protection and Voltage Transient Protection
|
|
Material
|
ADC 12, PC, PC+10% GF
|
|
Dimensions
|
Φ 164.5 mm × 290 mm (Φ
6.48" × 11.42")
|
|
Weight
|
Approx. 2 kg (4.41 lb)
|
