Camera
|
|
Sensor
|
1/2.8"
Progressive Scan CMOS
|
|
Max.
Resolution
|
2560
× 1440
|
|
Min.
Illumination
|
Color:
0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
|
Shutter
Speed
|
1/1
s to 1/30,000 s
|
|
Day
＆ Night
|
IR cut
filter
|
|
Zoom
|
25 ×
optical, 16 × digital
|
|
Slow
Shutter
|
Yes
|
|
Lens
|
|
Focal
Length
|
4.8
to 120 mm
|
|
FOV
|
Horizontal
FOV 53.3° to 2.6°,
Vertical
FOV 30.6° to 1.5°,
Diagonal
FOV 60.5° to 3°
|
|
Focus
|
Auto,
semi-auto, manual
|
|
Aperture
|
Max.
F1.6
|
|
Zoom
Speed
|
Approx.
3.4 s
|
|
Illuminator
|
|
Supplement
Light Type
|
IR
|
|
Supplement
Light Range
|
IR Distance:
up to 50 m
|
|
Smart
Supplement Light
|
Yes
|
|
IR Wavelength
|
850
nm
|
|
PTZ
|
|
Movement
Range (Pan)
|
0° to
360°
|
|
Movement
Range (Tilt)
|
-5°
to 90°
|
|
Pan
Speed
|
Pan
speed: configurable from 0.1° to 300°/s; preset speed: 350°/s
|
|
Tilt
Speed
|
Tilt
speed: configurable from 0.1° to 160°/s, preset speed 200°/s
|
|
Proportional
Zoom
|
Yes
|
|
Presets
|
300
|
|
Preset
Freezing
|
Yes
|
|
Patrol
Scan
|
8 patrols,
up to 32 presets for each patrol
|
|
Pattern
Scan
|
4 pattern
scans, record time over 10 minutes for each scan
|
|
Park
Action
|
Preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan
|
|
3D Positioning
|
Yes
|
|
PTZ
Status Display
|
Yes
|
|
Scheduled
Task
|
preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan, dome reboot, dome adjust
|
|
Power-off
Memory
|
Yes
|
|
Video
|
|
Main
Stream
|
50 Hz:
25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz:
30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (704 × 480, 640 × 480, 352 × 240)
|
|
Third
Stream
|
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264
Sub-stream:
H.265 / H.264 / MJPEG
Third
stream: H.265 / H.264 / MJPEG
|
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
|
H.265
Type
|
Main
profile
|
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
|
Region
of Interest (ROI)
|
8 fixed
regions for each stream
|
|
Network
|
|
Protocols
|
IPv4/IPv6,
HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP,
TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets
|
|
Simultaneous
Live View
|
Up to
20 channels
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, control timeout settings, security audit log,
TLS 1.2, host authentication (MAC address)
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
|
|
|
|
Parameters Switch
|
Yes
|
|
Settings
|
Saturation,
brightness, contrast, sharpness, gain, and white balance adjustable by client
software or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
|
Wide
Dynamic Range (WDR)
|
120
dB
|
|
SNR
|
＞52 dB
|
|
Defog
|
Digital
Defog
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Privacy
Mask
|
24 programmable
polygon privacy masks, mask color or mosaic configurable
|
|
Regional
Focus
|
Yes
|
|
Regional
Exposure
|
Yes
|
|
Interface
|
|
Ethernet
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
|
On-board
Storage
|
Built-in
memory card slot, support microSD / SDHC / SDXC card, up to 256 GB
|
|
Audio
|
1 input
(line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output
(line out), line level, output impedance: 600 Ω
|
|
Alarm
|
2 inputs,
2 outputs
|
|
Reset
|
Yes
|
|
Event
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception, alarm input and output
|
|
Smart
Event
|
line
crossing detection, intrusion detection, region entrance detection, region exiting
detection, unattended baggage detection, object removal detection, audio exception
detection
|
|
Alarm
Linkage
|
Upload
to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm
output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern
scan)
|
|
Smart
Tracking
|
Manual
tracking, auto-tracking
|
|
Deep Learning Function
|
|
Face
Capture
|
Detects
up to 5 faces simultaneously,
Supports
detecting, tracking, capturing, grading, selecting of face in motion, and
outputs the best face picture
|
|
General
|
|
Power
|
12 VDC,
Max. 24 W; PoE (802.3at)
|
|
Dimension
|
Ø
169 mm × 161 mm (Ø 6.65" × 6.34")
|
|
Weight
|
Approx.
2.45 kg (5.40 lb.)
|
|
Operating
Condition
|
-30
°C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
|
|
General
Function
|
Mirror,
password protection
|
|
Approval
|
|
Protection
|
IP66
(IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage
transient protection
|
