Camera
|
Max.
Resolution
|
3840
× 2160
|
Sensor
|
1/1.8"
progressive scan CMOS
|
Min.
Illumination
|
Color:
0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux@(F1.5, AGC ON), 0 Lux with IR
|
Shutter
Speed
|
1/1
s to 1/30000 s
|
Slow
Shutter
|
Yes
|
Day
& Night
|
IR cut
filter
|
Zoom
|
25x
optical, 16x digital
|
Lens
|
Focal
Length
|
5.9mm
to 147.5 mm
|
Zoom
Speed
|
Approx.
4.8 s
|
FOV
|
Horizontal
field of view: 50.8° to 2.6° (wide-tele),
Vertical
field of view: 29.4° to 1.5° (wide-tele),
Diagonal
field of view:57.4° to 3° (wide-tele)
|
Aperture
|
Max.
F1.5
|
Focus
|
Auto,
semi-auto, manual, rapid focus
|
Illuminator
|
Supplement
Light Range
|
IR Distance:
up to 200 m
|
Supplement
Light Type
|
IR
|
PTZ
|
Movement
Range (Pan)
|
360°
|
Movement
Range (Tilt)
|
-15°
to 90° (auto flip)
|
Pan
Speed
|
Pan
speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
|
Tilt
Speed
|
Tilt
speed: configurable from 0.1° to 120°/s, preset speed 200°/s
|
Proportional
Pan
|
Yes
|
Presets
|
300
|
Patrol
Scan
|
8 patrols,
up to 32 presets for each patrol
|
Pattern
Scan
|
4 pattern
scans
|
Power-off
Memory
|
Yes
|
Park
Action
|
Preset,
pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan
|
3D Positioning
|
Yes
|
PTZ
Status Display
|
Yes
|
Preset
Freezing
|
Yes
|
Scheduled
Task
|
Preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan, dome reboot, dome adjust, aux output
|
Video
|
Main
Stream
|
50 Hz:
25 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz:
24 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
|
Sub-Stream
|
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz:
24 fps (704 × 480, 640 × 480, 352 × 240)
|
Third
Stream
|
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60 Hz:
24 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264
Sub-stream:
H.265 / H.264 / MJPEG
Third
stream: H.265 / H.264 / MJPEG
|
Video
Bit Rate
|
32 kbps
to 16384 kbps
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
H.265
Type
|
Main
Profile
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
Region
of Interest (ROI)
|
8 fixed
regions for each stream
|
Network
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
|
Protocols
|
IPv4/IPv6,
HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP,
TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, Websocket, Websockets
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings,
security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address)
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
Enhancement
|
BLC,
HLC, 3D DNR
|
Wide
Dynamic Range (WDR)
|
120
dB
|
Defog
|
Digital
defog
|
Stabilization
|
EIS
|
Regional
Exposure
|
Yes
|
Regional
Focus
|
Yes
|
Settings
|
Saturation,
brightness, contrast, sharpness, gain, and white balance adjustable by client
software or web browser
|
Privacy
Mask
|
24 programmable
polygon privacy masks, mask color or mosaic configurable
|
SNR
|
>
52 dB
|
Interface
|
Ethernet
Interface
|
1 RJ45
10M/100M self-adaptive Ethernet port
|
On-board
Storage
|
Built-in
memory card slot, support microSD / SDHC / SDXC card, up to 256 GB
|
Alarm
|
2 inputs,
1 output
|
Reset
|
Yes
|
Audio
|
1 input
(line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%;
1 output
(line out), line level, output impedance: 600 Ω
|
Built-in
Speaker
|
1 built-in
speaker with effective distance reaching max. 30 meters
|
Event
|
Basic
Event
|
Motion
detection, video tampering alarm, exception, alarm input and output
|
Smart
Event
|
Line
crossing detection, intrusion detection, region entrance detection, region exiting
detection, unattended baggage detection, object removal detection, audio exception
detection
|
Smart
Tracking
|
Manual
tracking, auto-tracking
|
Alarm
Linkage
|
Upload
to FTP / NAS / memory card, notify surveillance center, send email, trigger alarm
output, trigger recording, audible warning, white light flashing, and PTZ
actions (such as preset, patrol scan, pattern scan)
|
Deep Learning Function
|
Face
Capture
|
Detects
up to 5 faces simultaneously.
Supports
detecting, capturing, grading, selecting of face in motion, and output the best
face picture of the face
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting
Support
alarm triggering by specified target types (human and vehicle)
|
General
|
Power
|
24 VAC,
max. 42 W (including max. 18 W for IR and max. 10 W for heater);
Hi-PoE
|
Operating
Condition
|
-30
°C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
|
Demist
|
Yes
|
Material
|
ADC12
|
Dimension
|
Ø 220
mm × 363.3 mm (Ø 8.66" × 13.91")
|
Weight
|
Approx.
5 kg (11.03 lb.)
|
Approval
|
Protection
|
IP66
(IEC 60529-2013), IK10 (excluding glass window), TVS 6000V lightning protection,
surge protection and voltage transient protection
|
EMC
|
FCC
SDoC (47 CFR Part 15, Subpart B);
CE-EMC
(EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011
+A1:
2014);
RCM
(AS/NZS CISPR 32: 2015);
IC VoC
(ICES-003: Issue 6, 2019);
KC (KN
32: 2015, KN 35: 2015)
|
