Camera
Module
|
|
Image Sensor
|
1/1.8" progressive
scan CMOS
|
|
Min. Illumination
|
Color: 0.002 Lux
@(F1.5, AGC ON) B/W: 0.0002 Lux @(F1.5, AGC ON)
0 Lux with IR
|
|
Shutter Time
|
1/1 s to 1/30,000 s
|
|
White Balance
|
Auto / Manual / ATW
(Auto-tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium
Lamp
|
|
AGC
|
Auto / Manual
|
|
Day & Night
|
IR cut filter
|
|
Digital Zoom
|
16×
|
|
Privacy Mask
|
24 programmable privacy
masks
|
|
Focus Mode
|
Auto / Semi-automatic /
Manual
|
|
3D DNR
|
Support
|
|
BLC
|
Support
|
|
HLC
|
Support
|
|
WDR
|
120dB
|
|
Optical Defog
|
Support
|
|
EIS
|
Support
|
|
Regional Exposure
|
Support
|
|
Regional Focus
|
Support
|
|
Rapid Focus
|
Support
|
|
Lens
|
|
Focal Length
|
5.7 mm to 205.2 mm, 36×
Optical
|
|
Zoom Speed
|
Approx.4.4 s (optical
lens, wide-tele)
|
|
Field of View
|
Horizontal field of
view: 51.1° to 1.7° (wide-tele)
Vertical field of view:
31.3° to 1.0° (wide-tele)
Diagonal field of view:
58.0° to 2.0° (wide-tele)
|
|
Working Distance
|
10 mm to 1500 mm
(wide-tele)
|
|
Aperture Range
|
F1.5 to F4.5
|
|
PTZ
|
|
Movement Range (Pan)
|
360° endless
|
|
Pan Speed
|
Configurable, from
0.1°/s to 210°/s, Preset Speed: 280°/s
|
|
Movement Range (Tilt)
|
From -20° to 90°
|
|
Tilt Speed
|
Configurable, from
0.1°/s to 150°/s, Preset Speed: 250°/s
|
|
Proportional Zoom
|
Support
|
|
Presets
|
300
|
|
Patrol Scan
|
8 patrols, up to 32
presets for each patrol
|
|
Pattern Scan
|
4 pattern scans, record
time over 10 minutes for each scan
|
|
Power-off Memory:
|
Support
|
|
Park Action
|
Preset / Pattern Scan /
Patrol Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama
Scan
|
|
PTZ Status Display
|
Support
|
|
Preset Freezing
|
Support
|
|
Scheduled Task
|
Preset / Pattern Scan /
Patrol Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama
Scan / Dome Reboot / Dome Adjust / Aux Output
|
|
Smart
Features
|
|
Smart Detection
|
Intrusion Detection,
Line Crossing Detection, Region Entrance Detection, Region Exiting Detection,
Face Detection, Audio Exception Detection
|
|
Smart Tracking
|
Manual Tracking, Auto
Tracking, Event Tracking
|
|
Smart Record
|
ANR (Automatic Network
Replenishment), Dual-VCA
|
|
IR
|
|
IR Distance
|
200 m
|
|
Smart IR
|
Support
|
|
Network
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
50Hz: 25 fps (2560 ×
1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30 fps (2560 ×
1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
50Hz: 25fps (704 × 576,
640 × 480, 352 × 288)
60Hz: 30fps (704 × 480,
640 × 480, 352 × 240)
|
|
Third Stream
|
50Hz: 25fps (1920 ×
1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 ×
1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
ROI
|
Support
|
|
SVC
|
Support
|
|
Video Compression
|
Main Stream: H.265+ /
H.265 / H.264+ / H.264
Sub-Stream: H.265 /
H.264 / MJPEG
Third Stream: H.265 /
H.264 / MJPEG
H.264 with Baseline /
Main / High Profile
|
|
Audio compression
|
G.711alaw / G.711ulaw /
G.722.1 / G.726 / MP2L2 / PCM
|
|
Protocols
|
IPv4 / IPv6, HTTP,
HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP,
TCP/IP, DHCP, PPPoE, Bonjour
|
|
Simultaneous Live View
|
Up to 20 channels
|
|
User/Host
|
Up to 32 users
3 levels:
Administrator, Operator and User
|
|
Security Measures
|
User authentication (ID
and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x
port-based network access control; IP address filtering
|
|
System
Integration
|
|
Alarm Input / Output
|
7-ch alarm input and
2-ch alarm output
|
|
Alarm Linkage
|
Alarm actions, such as
Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger
Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send
Email, etc.
|
|
Audio Input / Output
|
1-ch audio input and
1-ch audio output
|
|
Network Interface
|
1 RJ45 10 M / 100 M
Ethernet Interface; Hi-PoE
|
|
CVBS
|
Support
|
|
RS-485
|
HIKVISION, Pelco-P,
Pelco-D, self-adaptive
|
|
Storage
|
Built-in memory card
slot, support Micro SD / SDHC / SDXC, up to 256 GB; NAS (NPS, SMB /
CIPS), ANR
|
|
API
|
Open-ended, support
ONVIF, and CGI, support HIKVISION SDK and Third-Party Management Platform
|
|
Client
|
iVMS-4200, iVMS-4500,
iVMS-5200, Hik-Connect
|
|
General
|
|
Power
|
24 V, 3.0 A, 50/60Hz,
AC (Max. 60 W, including max. 18 W for IR and max. 6 W for heater)
Hi-PoE, 42.5 to 57 V,
1.41 A (Max. 50 W, including max. 18 W for IR and max. 6 W for heater)
|
|
Working Temperature
|
Outdoor: -40°C to 65°C
(-40°F to 149°F)
|
|
Working Humidity
|
≤ 90%
|
|
Protection Level
|
IP66 Standard, IK10
(only supported by camera without wiper), TVS 6,000V Lightning Protection,
Surge Protection and Voltage Transient Protection
|
|
Dimensions
|
Φ 266.6 mm × 410 mm (Φ
10.50" × 16.14")
|
|
Weight
|
Approx. 8 kg (17.64 lb)
|
