Camera
|
|
Sensor
|
1/1.8"
progressive scan CMOS
|
|
Min.
Illumination
|
Color:
0.002 Lux @ (F1.5, AGC ON), B/W: 0.0002 Lux @ (F1.5, AGC ON)
|
|
Shutter
Speed
|
1/1
s to 1/30,000 s
|
|
Slow
Shutter
|
Yes
|
|
Day
& Night
|
IR cut
filter
|
|
Zoom
|
48x
optical, 16x digital
|
|
Max.
Resolution
|
2560
× 1440
|
|
Lens
|
|
Focus
|
Auto,
semi-auto, manual, rapid focus
|
|
Focal
Length
|
6.0
to 288 mm
|
|
Zoom
Speed
|
Approx.
7.8 s
|
|
FOV
|
Horizontal
field of view: 60.0° to 2.0° (wide-tele),
Vertical
field of view: 35.8° to 1.2° (wide-tele),
Diagonal
field of view: 67.0° to 2.4° (wide-tele)
|
|
Aperture
|
Max.
F1.5
|
|
Illuminator
|
|
Supplement
Light Type
|
Laser
|
|
Supplement
Light Range
|
Laser
Distance: up to 500 m
|
|
Smart
Supplement Light
|
Yes
|
|
PTZ
|
|
Movement
Range (Pan)
|
360°
|
|
Movement
Range (Tilt)
|
-20°
to 90° (auto flip)
|
|
Pan
Speed
|
Pan
speed: configurable from 0.1° to 210°/s; preset speed: 280°/s
|
|
Tilt
Speed
|
Tilt
speed: configurable from 0.1° to 150°/s, preset speed 250°/s
|
|
Proportional
Pan
|
Yes
|
|
Presets
|
300
|
|
Patrol
Scan
|
8 patrols,
up to 32 presets for each patrol
|
|
Pattern
Scan
|
4 pattern
scans, record time over 10 minutes for each scan
|
|
Power-off
Memory
|
Yes
|
|
Park
Action
|
Preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan
|
|
3D Positioning
|
Yes
|
|
PTZ
Status Display
|
Yes
|
|
Preset
Freezing
|
Yes
|
|
Scheduled
Task
|
Preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan, dome reboot, dome adjust, aux output
|
|
Video
|
|
Main
Stream
|
50 Hz:
25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz:
24 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz:
24 fps (704 × 480, 640 × 480, 352 × 240)
|
|
Third
Stream
|
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz:
24 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264
Sub-stream:
H.265 / H.264 / MJPEG
Third
stream: H.265 / H.264 / MJPEG
|
|
Video
Bit Rate
|
32 Kbps
to 16384 Kbps
|
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
|
H.265
Type
|
Main
Profile
|
|
Scalable
Video Coding (SVC)
|
H.264
and H.265 encoding
|
|
Region
of Interest (ROI)
|
8 fixed
regions for each stream
|
|
Network
|
|
Network
Storage
|
NAS
(NFS, SMB/ CIFS), ANR
|
|
User/Host
|
Up to
32 users 3 user levels: administrator, operator, and user
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings,
security audit log, TLS 1.3, host authentication (MAC address)
|
|
|
|
Day/Night
Switch
|
Day,
night, auto, scheduled-switch
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Wide
Dynamic Range (WDR)
|
140
dB
|
|
Defog
|
Optical
defog
|
|
Stabilization
|
OIS
|
|
Regional
Exposure
|
Yes
|
|
Regional
Focus
|
Yes
|
|
Settings
|
Saturation,
brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
|
|
Parameters Switch
|
Yes
|
|
Privacy
Mask
|
Up to
24 masks, mosaic mask, mask color configurable, rectangle region
|
|
SNR
|
≥ 52 dB
|
|
Interface
|
|
Ethernet
Interface
|
1 RJ45
10M/100M self-adaptive Ethernet port
|
|
On-board
Storage
|
Built-in
memory card slot, support microSD / microSDHC / microSDXC cards, up to 256GB
|
|
Alarm
|
7 inputs,
2 outputs
|
|
Audio
|
1 input
(line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output
(line out), line level, output impedance: 600 Ω
|
|
RS-485
|
Half
duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
|
|
Event
|
|
Basic
Event
|
Audio
exception, motion detection, video tampering alarm, alarm input, alarm output,
exception
|
|
Smart
Event
|
Line
crossing detection, region entrance detection, unattended baggage detection,
object removal detection, intrusion detection, region exiting detection, vandal-proof
alarm, audio exception detection
|
|
Smart
Tracking
|
Manual
tracking, auto-tracking
|
|
Alarm
Linkage
|
Preset,
patrol scan, pattern scan, memory card video recording, alarm output, sending
email, notify surveillance center, upload to FTP, NAS video recording
|
|
Deep Learning Function
|
|
Face
Capture
|
Support
detecting up to 30 faces at the same time. Support detecting, tracking,
capturing,
grading, selecting of face in motion, and output the best face picture of the
face
|
|
Face
Comparison
|
Yes
|
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting
Support
alarm triggering by specified target types (human and vehicle)
|
|
Road Traffic and Vehicle Detection
|
|
Road
Traffic
|
Support
vehicle detection (license plate number, vehicle model, and vehicle color recognition)
|
|
General
|
|
Operating
Condition
|
Temperature:
-40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%
|
|
Power
Consumption and Current
|
24 VAC
(Max. 62 W, including max. 12 W for IR and max. 8 W for heater), PoE 802.3 bt
(Max.
51 W, including max. 12 W for IR and max. 8 W for heater)
|
|
Wiper
|
Yes.
Rain-sensing auto control
|
|
Dimension
|
Ø
267 mm × 430 mm (Ø 10.51" × 16.93")
|
|
Weight
|
Approx.
9.6 kg (21.16 lb.)
|
|
Approval
|
|
EMC
|
FCC
SDoC (47 CFR Part 15, Subpart B);
CE-EMC
(EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN
50130-4:
2011 +A1: 2014);
RCM
(AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 7);
KC (KN
32: 2015, KN 35: 2015)
|
|
Safety
|
UL (UL
62368-1)
CB (IEC
62368-1: 2014+A11);
CE-LVD
(EN 62368-1: 2014+A11: 2017),
BIS
(IS 13252(Part 1):2010/ IEC 60950-1: 2005); LOA (IEC/EN 60950-1)
|
|
Environment
|
CE-RoHS
(2011/65/EU); WEEE (2012/19/EU);
Reach
(Regulation (EC) No 1907/2006)
|
|
Protection
|
IP67
(IEC 60529-2013), 6000V Lightning Protection, Surge Protection and Voltage Transient
Protection
|
