Camera Module
|
Sensor
|
1/1.8”
progressive scan CMOS, dual-sensor structure
|
Min.
Illumination
|
color:
0.0005 Lux @ (F1.6, AGC ON), B/W: 0.0001 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
Shutter
Speed
|
1/1
to 1/30,000s
|
Slow
Shutter
|
yes
|
Focus
|
semi-auto,
manual, auto
|
Day
& Night
|
electronic
|
Day/Night
Switch
|
day,
night, auto, scheduled-switch
|
BLC
|
yes
|
WDR
|
140
dB WDR
|
HLC
|
yes
|
3D DNR
|
yes
|
Defog
|
yes
|
EIS
|
Yes.
Built-in gyroscope to improve EIS performance.
|
Regional
Exposure
|
yes
|
Regional
Focus
|
yes
|
Settings
|
saturation,
brightness, contrast, sharpness
|
Parameters Switch
|
yes
|
White
Balance
|
auto,
ATW, sodium lamp, fluorescent lamp, indoor, outdoor, MWB
|
Digital
Zoom
|
16 ×
|
Optical
Zoom
|
45 ×
|
Privacy
Mask
|
up to
24 masks, polygon region, mosaic mask, mask color configurable
|
Overlay
|
yes
|
SNR
|
≥55 dB
|
General
Function
|
mirror,
password protection, watermark, IP address filter
|
Lens
|
Focal
Length
|
5.9
mm to 265 mm
|
Zoom
Speed
|
approx.
4.8 s
|
FOV
|
Horizontal
field of view: 58.9° to 1.7°(wide-tele)
Vertical
field of view: 35.3° to 0.9°(wide-tele)
Diagonal
field of view: 65.9° to 1.9° (wide-tele)
|
Min.
Working Distance
|
100
mm to 1500 mm (wide-tele)
|
Aperture
|
F1.6
|
Aperture
Range
|
F1.6
to F4.4
|
PTZ
|
Movement
Range (Pan)
|
360°
|
Movement
Range (Tilt)
|
-25°
to 90° (auto flip)
|
Pan
Speed
|
pan
speed: configurable from 0.1° to 210°/s; preset speed: 280°/s
|
Tilt
Speed
|
tilt
speed: configurable from 0.1° to 150°/s; preset speed 250°/s
|
Proportional
Zoom
|
yes
|
Presets
|
300
|
Patrol
Scan
|
8 patrols,
up to 32 presets for each patrol
|
Pattern
Scan
|
4 pattern
scans, record time over 10 minutes for each scan
|
Power-off
Memory
|
yes
|
Park
Action
|
preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,
panorama scan
|
3D Positioning
|
yes
|
PTZ
Status Display
|
yes
|
Preset
Freezing
|
yes
|
Scheduled
Task
|
preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan, dome reboot, dome adjust, aux output
|
Vandal-proof
alarm
|
yes
|
Video
|
Max.
Resolution
|
1920
× 1080
|
Stream
Type
|
main
stream, sub-stream, third stream
|
Main
Stream
|
50Hz:
25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz:
30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
Sub-Stream
|
50Hz:
25fps (704 × 576, 640 × 480, 352 × 288)
60Hz:
30fps (704 × 480, 640 × 480, 352 × 240)
|
Third
Stream
|
50Hz:
25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz:
30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
Video
Compression
|
H.265,
H.264, MJPEG
|
Video
Bit Rate
|
32 Kbps
to 16384 Kbps
|
H.264
Type
|
baseline
profile, main profile, high profile
|
H.265
Type
|
main
profile
|
H.264+
|
yes
|
H.265+
|
yes
|
SVC
|
yes
|
ROI
|
yes
|
Smart Features
|
Face
Capture
|
Support
detecting up to 30 faces at the same time. Support detecting, tracking,
capturing, grading, selecting of face in motion, and output the best face picture
of the face
|
Road
Traffic
|
Support
vehicle detection (license plate number, vehicle model, and vehicle color recognition)
|
Basic
Event
|
motion
detection, video tampering alarm, alarm input and output, exception
|
Smart
Event
|
unattended
baggage detection, object removal detection, intrusion detection, line
crossing detection, region entrance detection, region exiting detection,
audio exception detection
|
Smart
Tracking
|
manual
tracking, event tracking, auto-tracking
|
Smart
Record
|
ANR,
Dual-VCA
|
Alarm
Linkage
|
preset,
patrol scan, pattern scan, memory card video recording, alarm output, sending
email, notify surveillance center, upload to FTP, smart tracking, NAS video
recording
|
Smart
Encoding
|
H.265+,
H.264+, ROI, SVC
|
Network
|
Protocols
|
IPv4/IPv6,
HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP,
TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
Security
Measures
|
Authenticated
username and password, MAC address binding, HTTPS encryption, 802.1X
authenticated access, IP address filter
|
Interface
|
Communication
Interface
|
1 RJ45
10 M/100 M Ethernet Interface
|
On-board
Storage
|
Built-in
microSD slot, support microSD / microSDHC / microSDXC cards, up to 256 GB
|
Alarm
Input
|
7 alarm
inputs
|
Alarm
Output
|
2 alarm
output
|
Audio
Input
|
1 audio
input, 2.0 to 2.4Vp-p, 1k Ohm±10%
|
Audio
Output
|
1 audio
output, line level, impedance: 600 Ω
|
Video
Output
|
1.0V[p-p]/75Ω,
PAL, NTSC, BNC connector
|
RS-485
|
Half
duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive
|
Supplement Light
|
IR
Distance
|
500
meters
|
Smart
IR
|
yes
|
General
|
Power
|
36 VDC
|
Power
Consumption and Current
|
max.
90 W, including max. 12 W for IR
|
Operating
Conditions
|
Temperature:
-40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%
|
Wiper
|
Yes.
Rain-sensing auto control
|
Material
|
ADC12
|
Dimensions
|
Φ 293
mm × 422 mm (Φ 11.5" × 16.6")
|
Weight
|
Approx.
13 kg (28.7 lb)
|
Approval
|
EMC
|
Lightning
Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to Gnd,
±3kV Line to Line, IEC61000-4-5
|
Protection
|
IP67
|
