Camera
|
|
Image Sensor
|
Three 1/2.8"
progressive scan CMOS
|
|
Min. Illumination
|
Color: 0.05 Lux @(F2.0, AGC
ON) B/W: 0.01 Lux @(F2.0, AGC ON)
0 Lux with IR
|
|
White Balance
|
Auto / Manual / ATW
(Auto-Tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium Lamp
|
|
Shutter Time
|
1/25 s to 1/30,000 s
|
|
Day & Night
|
IR Cut Filter
|
|
Focal Length
|
2 mm
|
|
Aperture Range
|
F2.0
|
|
FOV
|
Horizontal field of view:
128.5° × 3
Vertical field of view: 75.7°
|
|
Resolution
(Sub-stream enabled)
|
Main stream:
50 Hz: 20 fps (1920 × 1080,
1280 × 960, 1280 × 720)
60 Hz: 20 fps (1920 × 1080,
1280 × 960, 1280 × 720)
Sub-stream:
50 Hz: 20 fps (704 × 576,
640 × 480, 352 × 288)
60 Hz: 20 fps (704 × 480,
640 × 480, 352 × 240)
|
|
Resolution
(Sub-stream not enabled)
|
Main stream:
50 Hz: 25 fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080,
1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Video Compression
(Sub-stream enabled)
|
Main stream: H.265/H.264
Sub-stream:
H.265 / H.264 / MJPEG (MJPEG is only supported by channel 1)
H.264 with Main
Profile / High Profile, H.265 with Main Profile
|
|
Video Compression
(Sub-stream not enabled)
|
Main stream:
H.265 / H.264 / MJPEG (MJPEG is only supported by channel 1)
H.264 with Main
Profile / High Profile, H.265 with Main Profile
|
|
Audio Compression
|
G.711alaw / G.711ulaw / G.722.1 / G.726 / MP2L2
|
|
IR Radius
|
10 m
|
|
Smart Coding
|
ROI, SVC
|
|
Smart Record
|
ANR (Automatic Network
Replenishment)
|
|
Basic Event Detection
|
Motion Detection, Video
Tampering Detection, Exception
|
|
Smart Event Detection
|
Audio Exception Detection,
Intrusion Detection, Line Crossing Detection (Smart event detection is only
supported by channel 1)
|
|
Privacy Mask
|
4 × 3 programmable privacy
masks
|
|
Smart Image Enhancement
|
Digital WDR / HLC / BLC / 3D DNR / Defog / Regional Exposure
|
|
Network
|
|
Network Storage
|
Built-in memory card slot,
support Micro SD/SDHC/SDXC, up to 256 GB
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS,
802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP,
DHCP, PPPoE, Bonjour
|
|
API
|
Open-ended, support ONVIF,
ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
|
|
User/Host
|
Up to 32 users
3 levels: Administrator,
Operator and User
|
|
Security Measures
|
User authentication (ID and
PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x
port-based network access control; IP address filtering
|
|
Client
|
iVMS-4200, iVMS-4500,
iVMS-5200, Hik-Connect
|
|
Interface
|
|
Network Interface
|
1 RJ45 10 M/100 M Ethernet
|
|
Audio Interface
|
1-ch audio input and 1-ch
audio output
|
|
General
|
|
Power
|
12 VDC, 2.0 A & PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, Class4 Max.20 W (Max. 6 W for IR)
|
|
Working Temperature
|
-10°C to 50°C (14°F to
122°F)
|
|
Working Humidity
|
≤ 90%
|
|
Protection Level
|
TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
|
Material
|
PC & Aluminum alloy
|
|
Dimensions
|
Φ 183 mm × 76 mm (Φ
7.20" × 2.99")
|
|
Weight
|
Approx. 0.68 kg (1.50 lb)
|
