Camera
|
|
Sensor
|
[Bullet
channel]: 1/2.8" Progressive Scan CMOS; [PTZ channel]: 1/2.8" progressive
scan CMOS
|
|
Min.
Illumination
|
[Bullet
channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;
[PTZ
channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON),
0 Lux with IR
|
|
Shutter
Speed
|
1 s
to 1/30,000 s
|
|
Slow
Shutter
|
Yes
|
|
Focus
|
semi-auto,
manual, auto
|
|
Day
＆ Night
|
ICR
|
|
Zoom
|
[PTZ
channel] 25 × optical, 16 × digital
|
|
Day/Night
Switch
|
day,
night, auto, scheduled-switch
|
|
White
Balance
|
auto,
ATW, sodium lamp, fluorescent lamp, indoor, outdoor, MWB, Locked WB
|
|
Max.
Resolution
|
[Bullet
channel] 1920 × 1080, [PTZ channel] 1920 × 1080
|
|
Lens
|
|
Focal
Length
|
[Bullet
channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical
|
|
Zoom
Speed
|
[PTZ
channel]: approx. 3.6 s
|
|
FOV
|
[Bullet
channel]: Horizontal field of view: 106.1°, Vertical field of view: 56.8°，Diagonal field of view: 126.5°;
[PTZ
channel]: Horizontal field of view: 54.8° to 2.8° (wide-tele), Vertical field
of view: 31.4° to 1.5° (wide-tele), Diagonal field of view: 62.2° to 3.2°
(wide-tele)
|
|
Aperture
|
[Bullet
channel]: F1.0; [PTZ channel]: F1.6
|
|
Illuminator
|
|
Supplement
Light Type
|
[PTZ
channel]: IR; [Bullet channel]: White Light
|
|
Smart
Supplement Light
|
Yes
|
|
Supplement
Light Range
|
[PTZ
channel]: up to 100 m; [Bullet channel]: up to 30 m
|
|
PTZ
|
|
Movement
Range (Pan)
|
360°
|
|
Movement
Range (Tilt)
|
-15°
to 90° (auto flip)
|
|
Pan
Speed
|
pan
speed: configurable from 0.1° to 80°/s; preset speed: 80°/s
|
|
Tilt
Speed
|
tilt
speed: configurable from 0.1° to 80°/s, preset speed 80°/s
|
|
Proportional
Zoom
|
yes
|
|
Presets
|
300
|
|
Patrol
Scan
|
8 patrols,
up to 32 presets for each patrol
|
|
Pattern
Scan
|
4 pattern
scans
|
|
Power-off
Memory
|
yes
|
|
Park
Action
|
preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan
|
|
3D Positioning
|
yes
|
|
PTZ
Status Display
|
yes
|
|
Preset
Freezing
|
yes
|
|
Scheduled
Task
|
preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama
scan, dome reboot, dome adjust, aux output
|
|
Exception
Detection
|
IP address
conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot
|
|
Video
|
|
Region
of Interest (ROI)
|
8 fixed
regions for each stream
|
|
Stream
Type
|
main
stream, sub-stream, third stream
|
|
Main
Stream
|
[Bullet
channel]:
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
[PTZ
channel]:
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
[Bullet
channel]:
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz:
30 fps (704 × 480, 640 × 480, 352 × 240)
[PTZ
channel]:
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz:
30 fps (704 × 480, 640 × 480, 352 × 240)
|
|
Third
Stream
|
[Bullet
channel]:
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
[PTZ
channel]:
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Video
Compression
|
H.265,
H.264, MJPEG
|
|
Video
Bit Rate
|
32 kbps
to 16384 kbps
|
|
H.264
Type
|
baseline
profile, main profile, high profile
|
|
H.265
Type
|
main
profile
|
|
H.264+
|
yes
|
|
H.265+
|
yes
|
|
SVC
|
yes
|
|
Smart Features
|
|
Smart
Record
|
ANR,
Dual-VCA
|
|
Network
|
|
API
|
Open
Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
|
|
Network
Storage
|
NAS
(NFS, SMB/ CIFS), ANR
|
|
|
|
Settings
|
sharpness,
saturation, brightness, contrast
|
|
Wide
Dynamic Range (WDR)
|
120
dB
|
|
SNR
|
≥ 52 dB
|
|
Defog
|
Digital
defog
|
|
Stabilization
|
EIS
|
|
Enhancement
|
BLC,
HLC, 3D DNR
|
|
Regional
Focus
|
Yes
|
|
Regional
Exposure
|
Yes
|
|
Parameters Switch
|
Yes
|
|
Privacy
Mask
|
[Bullet
channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon
privacy masks; mask color or mosaic configurable
|
|
Interface
|
|
Communication
Interface
|
RJ45,
self-adaptive 10M/100M Ethernet port
|
|
On-board
Storage
|
Built-in
memory card slot, support Micro SD / Micro SDHC / Micro SDXC, up to 256 GB
|
|
Alarm
Input
|
1 alarm
input
|
|
Alarm
Output
|
1 alarm
output
|
|
Audio
Input
|
1 audio
input, 2.0 to 2.4Vp-p, 1k Ohm±10%
|
|
Audio
Output
|
1 audio
output, line level, impedance: 600 Ω
|
|
Event
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception, alarm input and output
|
|
Smart
Event
|
audio
exception detection, region entrance detection, region exiting detection, intrusion
detection, Line crossing detection
|
|
Alarm Linkage
|
[Bullet
channel] Upload to FTP / NAS / memory card, notify surveillance center, send
email, trigger alarm output, and trigger recording
[PTZ
channel] Upload to FTP / NAS / memory card, notify surveillance center, send email,
trigger alarm output, trigger recording, and PTZ actions (such as preset,
patrol scan, pattern scan)
|
|
Deep Learning Function
|
|
Face
Capture
|
[Bullet
channel] no, [PTZ channel] yes
|
|
General
|
|
General
Function
|
mirror,
password protection, watermark, IP address filter
|
|
Power
|
12VDC,
PoE+
|
|
Power
Consumption and Current
|
Max.
24 W, including max. 2.6 W for heater and max. 11 W for supplement light
|
|
Reset
|
yes
|
|
Demist
|
Demist
by heating the glass
|
|
Material
|
ADC12
|
|
Dimensions
|
Ø 166
mm × 375 mm (Ø 6.5" × 14.7")
|
