Camera Module
|
|
Sensor
|
[panoramic
channel]: 1/2.8" Progressive Scan CMOS;
[PTZ
channel]: 1/2.8" progressive scan CMOS
|
|
Min.
Illumination
|
[PTZ
channel]: Color: 0.005 Lux @ (F1.2, AGC ON), B/W: 0.001 Lux @ (F1.2, AGC ON);
[panoramic
channel]: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
|
Shutter
Speed
|
1/1
s to 1/30000 s
|
|
Slow
Shutter
|
yes
|
|
Focus
|
semi-auto,
manual, auto
|
|
Day
& Night
|
ICR
|
|
Day/Night
Switch
|
day,
night, auto, scheduled-switch
|
|
BLC
|
yes
|
|
WDR
|
120
dB WDR
|
|
HLC
|
yes
|
|
3D DNR
|
yes
|
|
Defog
|
yes
|
|
EIS
|
yes
|
|
Regional
Exposure
|
yes
|
|
Regional
Focus
|
yes
|
|
Settings
|
saturation,
brightness, contrast, sharpness
|
|
White
Balance
|
auto,
ATW, sodium lamp, fluorescent lamp, indoor, outdoor, MWB, locked WB
|
|
Digital
Zoom
|
16 ×
|
|
Optical
Zoom
|
32 ×
|
|
Privacy
Mask
|
polygon
region, mosaic mask, mask color configurable, [panoramic channel] 8 masks
[PTZ
channel] 4 masks
|
|
SNR
|
＞52 dB
|
|
Lens
|
|
Focal
Length
|
[panoramic
channel]: 4 mm; [PTZ channel]: 4.8 to 153 mm, 32 ×
|
|
Zoom
Speed
|
approx.
4.2 s
|
|
FOV
|
[panoramic
channel]:
Horizontal
field of view: 79°, Vertical field of view: 42.4°; [PTZ channel]:
Horizontal
field of view: 58.4° to 2.14° (wide-tele), Vertical field of view: 33.8° to
1.2° (wide-tele),
Diagonal
field of view: 65.6° to 2.46° (wide-tele)
|
|
Aperture
|
[panoramic
channel]: F1.6; [PTZ channel]: F1.2
|
|
PTZ
|
|
Movement
Range (Pan)
|
360°
|
|
Movement
Range (Tilt)
|
-15°
to 90°(auto flip)
|
|
Pan
Speed
|
pan
speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
|
|
Tilt
Speed
|
tilt
speed: configurable from 0.1° to 120°/s, preset speed 200°/s
|
|
Proportional
Zoom
|
yes
|
|
Presets
|
300
|
|
Patrol
Scan
|
8 patrols,
up to 32 presets for each patrol
|
|
Pattern
Scan
|
4 pattern
scans
|
|
Power-off
Memory
|
yes
|
|
Park
Action
|
preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,
panorama scan
|
|
3D Positioning
|
yes
|
|
PTZ
Status Display
|
yes
|
|
Preset
Freezing
|
yes
|
|
Scheduled
Task
|
preset,
pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan,
panorama scan, dome reboot, dome adjust, aux output
|
|
Video
|
|
Max.
Resolution
|
2560
× 1440
|
|
Stream
Type
|
main
stream, sub-stream, third stream
|
|
Main
Stream
|
[panoramic
channel]:
50 Hz:
25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz:
30fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
[PTZ
channel]:
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz:
30 fps ( 1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
[panoramic
channel]:
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (704 × 480, 640 × 480, 352 × 240)
[PTZ
channel]:
50 Hz:
25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (704 × 480, 640 × 480, 352 × 240)
|
|
Third
Stream
|
[panoramic
channel]:
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
[PTZ
channel]:
50 Hz:
25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
|
Video
Compression
|
H.265,
H.264, MJPEG
|
|
Video
Bit Rate
|
32 kbps
to 16384 kbps
|
|
H.264
Type
|
baseline
profile, main profile, high profile
|
|
H.265
Type
|
main
profile
|
|
H.264+
|
yes
|
|
H.265+
|
yes
|
|
SVC
|
yes
|
|
ROI
|
main
stream, sub-stream and third stream respectively support eight fixed areas
|
|
Smart Features
|
|
Face
Capture
|
Support
detecting up to 5 faces at the same time. Support detecting, tracking, capturing,
grading, selecting of face in motion, and output the best face picture of the
face
|
|
Basic
Event
|
motion
detection, alarm input, alarm output, exception
|
|
Smart
Event
|
intrusion
detection, line crossing detection, region entrance detection, region exiting
detection, audio exception detection
|
|
Smart
Tracking
|
manual
tracking, panorama tracking, event tracking, auto-tracking, tracking takeover
|
|
Smart
Record
|
ANR,
Dual-VCA
|
|
Alarm
Linkage
|
preset,
patrol scan, pattern scan, memory card video recording, alarm output, sending
email, notify surveillance center, upload to FTP, smart tracking
|
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting
Support
alarm triggering by specified target types (human and vehicle)
|
|
Network
|
|
Network
Storage
|
NAS
(NFS, SMB/ CIFS), ANR
|
|
Smooth
Streaming
|
yes
|
|
Security
Measures
|
Authenticated
username and password, MAC address binding, HTTPS encryption, 802.1X
authenticated access, IP address filter
|
|
Interface
|
|
Communication
Interface
|
RJ45,
self-adaptive 10M/100M Ethernet port
|
|
On-board
Storage
|
support
microSD / microSDHC / microSDXC cards, up to 256 GB
|
|
Alarm
Input
|
2 alarm
inputs
|
|
Alarm
Output
|
1 alarm
output
|
|
Audio
Input
|
1 audio
input
|
|
Audio
Output
|
1 audio
output, line level, impedance: 600 Ω
|
|
Supplement Light
|
|
IR
Distance
|
200
m
|
|
General
|
|
Power
|
24 VAC,
Hi-PoE
|
|
Power
Consumption and Current
|
Max.
60 W, including max. 3.7 W for heater and max. 16 W for supplement light
|
|
Operating
Conditions
|
-30°C
to 65°C (-22°F to 149°F), humidity: ≤ 90%
|
|
Reset
|
yes
|
|
Demist
|
Demist
by heating the glass
|
|
Material
|
ADC
12, PC, PC+10%GF
|
|
Dimensions
|
Ø 220.0
mm × 373.3 mm (Ø 8.7" × 14.7")
|
|
Weight
|
Approx.
6 kg (13.23 lb.)
|
|
Approval
|
|
Protection
|
IP66
Standard, IK10 (excluding glass window), 6000 V Lightning Protection, Surge Protection
and Voltage Transient Protection
|
