Thermal Module
|
|
Image Sensor
|
VOx Uncooled Focal Plane Arrays
|
|
Resolution
|
640 × 512
|
|
Pixel Interval
|
12 μm
|
|
Response Waveband
|
8 μm to 14 μm
|
|
NETD
|
Less than 35 mK (@ 25 °C, F#=1.0)
|
|
Focal Length
|
50 mm
|
|
Focus Mode
|
Athermalized
|
|
IFOV
|
0.34 mrad
|
|
Aperture
|
F1.0
|
|
Field of View
|
8.78° × 7.03° (H × V)
|
|
Min. Focusing Distance
|
50m
|
|
Digital Zoom
|
×2, ×4, ×8
|
|
Optical Module
|
|
Image Sensor
|
1/1.8" Progressive Scan CMOS
|
|
Resolution
|
2688 × 1520, 4 MP
|
|
Min. Illumination
|
Color: 0.005 Lux @(F1.3, AGC ON), B/W: 0.00 Lux @(F1.3, AGC ON)
|
|
Field of View
|
56.6° ×33.7° (H × V) ~ 1.8° ×1.0° (H × V)
|
|
Focal Length
|
6-240 mm, 40x
|
|
Aperture (Range)
|
F1.3-F4.6
|
|
Focus Mode
|
Auto / Semi-auto / Manual
|
|
Digital Zoom
|
×2, ×4, ×8, ×16
|
|
Shutter Speed
|
1s to 1/30,000s
|
|
WDR
|
120 dB
|
|
Optical Defog
|
Yes
|
|
Image Effect
|
|
Picture in Picture
|
Display partial image of thermal channel on the full screen of optical channel
|
|
Target Coloration
|
Supported in white hot and black hot mode
|
|
PTZ
|
|
Movement Range
|
Pan: 360° Continuous Rotate; Tilt: From -20° to + 90° (auto flip)
|
|
Pan Speed
|
Configurable, From 0.1°/s to 200°/s, Preset Speed: 240°/s
|
|
Tilt Speed
|
Configurable, From 0.1°/s to 105°/s, Preset Speed: 200°/s
|
|
Proportional Zoom
|
Yes
|
|
Presets
|
300 in total, 273 are configurable.
|
|
Patrol Scan
|
8; Up to 32 Presets Per Patrol
|
|
Pattern Scan
|
4; More Than 10 Minutes Per Pattern
|
|
Power Off Memory
|
Yes
|
|
Park
|
Preset / Pattern Scan / Patrol Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan
|
|
PT Status
|
Turn On/Turn Off
|
|
Scheduled Task
|
Preset / Pattern Scan / Patrol Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan / Doom Reboot / Doom Adjust / Aux Output
|
|
Illuminator
|
|
IR Distance
|
Up to 150m
|
|
IR Intensity and Angle
|
Automatically adjusted
|
|
Smart Function
|
|
VCA
|
Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 10 scenes and 8 VCA rules for each scene
|
|
Temperature Measurement
|
Support 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)
|
|
Temperature Range
|
-20 °C to 150 °C (-4 °F to 302 °F)
|
|
Temperature Accuracy
|
± 8 °C (±14.4 °F)
|
|
Fire Detection
|
Dynamic fire detection, up to 10 fire points detectable.
|
|
Video and Audio
|
|
Main Stream
|
Thermal channel
50fps (1920 × 1080, 1280 × 960, 1280 × 720，704×576，640×512，384×288)
Optical channel
50Hz:25fps (2688 × 1520，1920 × 1080, 1280 × 960, 1280 × 720)
60Hz:30fps (2688 × 1520，1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-stream
|
Thermal channel 50fps (704×576，640×512，384×288)
Optical channel
50Hz: 25fps (704 × 576, 352 × 288)
60Hz: 30fps (704 × 576, 352 × 288)
|
|
Video Compression
|
Main stream: H.265+ / H.265 / H.264+ / H.264
Sub-stream: H.265 / H.264 / MJPEG
|
|
Audio Compression
|
G .711u / G.711a / G.722.1 / MP2L2 / G.726 / PCM
|
|
Network
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
|
|
Network Storage
|
MicroSD / SDHC / SDXC card (256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
|
|
User/Host level
|
Up to 32 users, 3 levels: Administrator, Operator, User
|
|
Security
|
User authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
|
|
Client
|
iVMS-4200, Hik-Connect
|
|
Interface
|
|
Alarm Input
|
7-ch inputs (0-5 VDC)
|
|
Alarm Output
|
2-ch relay outputs, alarm response actions configurable
|
|
Alarm Action
|
Preset / Patrol Scan / Pattern Scan / SD Card Record / Relay Output / Smart capture / FTP upload / Email linkage
|
|
Audio Input
|
1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%
|
|
Audio Output
|
Linear Level; Impedance: 600 Ω
|
|
Communication Interface
|
1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface
|
|
Analog Video Output
|
1.0 V [p-p]/75 Ω, BNC for thermal channel
|
|
General
|
|
Power Supply
|
24V AC ± 20%, 36V DC ± 20%, 48V DC ± 20%
|
|
Power Consumption
|
65W Max
|
|
Work Temperature / Humidity
|
From -40°C to 65°C (-40°F to 149°F); Humidity: 95% or Less
|
|
Wiper
|
Yes
|
|
Protection Level
|
IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
|
Dimension
|
220 mm × 410 mm × 198.6 mm (8.66" × 16.15" × 7.82")
|
|
Weight
|
Approx. 9kg (19.84 lb)
|
