DS-3E0110MP-E/M

DS-3E0110MP-E/M

Hikvision DS-3E0110MP-E/M 8 Port Fast Ethernet Unmanaged PoE Switch, 8 × 10/100 Mbps PoE RJ45 ports and 2 × 10/100 Mbps RJ45 ports, Auto MDI/MDIX of ports, Store-and-forward switching mode, Auto MAC address learning and aging, MAC Address Table: 2K, Switching Capacity: 1.6 Gbps, Packet Forwarding Rate: 1.19 Mpps, Internal Cache: 768 Kbit, PoE Power Budget: 60 W, Metal material, 48 VDC.

PoE Switch

Hikvision DS-3E0110MP-E/M 8 Port Fast Ethernet Unmanaged PoE Switch

PoE power budget

60W

Ports

8 × 10/100 Mbps PoE port,2 × 10/100 Mbps RJ45 port

Mac Address Table

2K

Switching Capacity

1.6 Gbps

Packet Forwarding rate

1.19 Mpps

Network Parameters

Ports

8 × 10/100 Mbps PoE port,2 × 10/100 Mbps RJ45 port

MAC Address Table

2 K

Switching Capacity

1.6 Gbps

Packet Forwarding Rate

1.19 Mpps

Internal Cache

768 Kbits

PoE Power Supply

PoE Power Pin

End-span: 1/2(-), 3/6(+)

PoE Port

PoE: Ports 1 to 8

PoE Power Budget

60 W

General

Shell

Metal material, fan-free design

Net Weight

0.29 kg (0.65 lb)

Gross Weight

0.84 kg (1.85 lb)

Dimensions (W × H × D)

170.00 mm × 27.60 mm × 93.10 mm (6.69'' × 1.09'' × 3.67'')

Operating Temperature

0 °C to 40 °C (32 °F to 104 °F)

Storage Temperature

-40 °C to 85 °C (-40 °F to 185 °F)

Operating Humidity

5% to 95% (no condensation)

Relative Humidity

5% to 95% (no condensation)

Power Supply

48 V DC, 1.35 A

Max. Power Consumption

65 W

Power Consumption in Idle

2.8 W

Installation Mode

Desk-Mounted,Wall-Mounted

Surge Protection

2 kV

Approval

EMC

CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3:

2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)

Safety

CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)

Chemistry

CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
