DS-3E1526P-EI/M

Hikvision DS-3E1526P-EI/M 24 Port Gigabit Smart POE Switch, 24 x gigabit PoE RJ45 ports, 1 × gigabit RJ45 port, 1 x gigabit fiber optical port, Total PoE power budget 230W, Unified cloud management for security systems, Network topology at your fingertips, MAC Address Table: 8 K, Switching Capacity: 56 Gbps, Packet Forwarding Rate: 41.66 Mpps, Internal Cache: 4.1 Mbits, IEEE 802.3af, IEEE 802.3at, Port Isolation, PoE Watchdog, Link Aggregation, Loop Prevention, VLAN, 6 kV surge protection.

https://www.esco.pk/web/image/product.template/24212/image_1920?unique=2b29d9c

    Rs. 0.00 0.0 PKR Rs. 0.00

    Not Available For Sale

    This combination does not exist.

    Add to Cart
    Add to wishlist Compare

    Please get in touch for pricing & availability.

    Contact Us
    Hikvision

    Is our price higher than expected or showing as zero? Chat with us now for the best price and product availability. Prices if shown are inclusive of applicable taxes. Tax rate may be adjusted as per customer's taxation status. For supply of product only, excluding any cabling and/or installation. Shipping charges can sometimes vary.

    ​

    Smart PoE Switch

    Hikvision DS-3E1526P-EI/M 24 Port Gigabit Smart POE Switch

    Non-PoE Ports

    1 x 10/100/1000 Mbps uplink ethernet port

    SFP Port

    1 x Gigabit Fiber Optical Port

    PoE Standard

    IEEE 802.3af, IEEE 802.3at

    Power Budget

    Total PoE power budget: 230W

    Switching Capacity

    Switching Capacity: 56 Gbps

    Mac Address Table

    MAC Address Table: 8 K

    Software Function

    Port Isolation, PoE Watchdog, Link Aggregation, Loop Prevention, Support 802.1Q VLAN

    General



    Shell

    Metal material



    Net Weight

    2.96 kg (6.52 lb)



    Gross Weight

    3.2 kg (7.05 lb)



    Dimensions (W × H × D)

    440.0 mm × 220.8 mm × 44.0 mm (17.32'' × 8.69'' × 1.73'')



    Operating Temperature

    0 °C to 45 °C (0 °F to 113 °F)



    Storage Temperature

    -40 °C to 85 °C (-40 °F to 185 °F)



    Operating Humidity

    5% to 95% (no condensation)



    Relative Humidity

    5% to 95% (no condensation)



    Power Supply

    100~240 V AC, 50/60 Hz, Max. 4 A



    Installation Mode

    Rack (equipped with mounting ears)



    Max. Power Consumption

    250 W



    Power Consumption in Idle

    30 W



    Surge Protection

    6 kV



    Network Parameters



    Ports

    24 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port



    MAC Address Table

    8 K



    Switching Capacity

    56 Gbps



    Packet Forwarding Rate

    41.66 Mpps



    Internal Cache

    4.1 Mbits



    PoE Power Supply



    PoE Standard

    IEEE 802.3af, IEEE 802.3at



    PoE Power Pin

    8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)



    PoE Port

    PoE: Ports 1 to 24



    Max. Port Power

    30 W



    PoE Power Budget

    230 W



    Software Function



    Long Range

    Ports 1 to 24: up to 300 m.

    Long range performance may vary depend on camera model or cable condition.





    Port Isolation

    Ports 1 to 24: port isolation mode to improve network security.

    Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.



    PoE Watchdog

    Ports 1 to 24: auto detect and restart the cameras that do not respond.



    Link Aggregation

    Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection.

    Support static link aggregation. Support 8 aggregation groups.



    Loop Prevention

    Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.

    Support 802.1D STP. Support 802.1w RSTP.



    VLAN

    VLAN is used for network scale planning and network health improvement. Support 802.1Q.

    Configurable VLAN ID from 1-4094. Support Trunk, Access port mode. Support Max. 32 VLAN.

    HPP

    Support one-click activation and remote management via Hik-Partner Pro. Functions supported:

    Display the port rate.

    Display the port bandwidth utilization rate.

    Display the PoE power usage.

    Display topology information.

    Display the alarm status.

    Restart ports and devices.

    Enable port long-rage mode.

    Remotely upgrade the device.

    System Maintenance

    Support device management via web.

    Support DHCP Client. Enabled by default for dynamic assignment of management IP addresses.

    Support Super IP, which is a fixed IP address (10.180.190.200) for direct access. Support remote management via Hik-Partner Pro.

    Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected.

    Support 802.1ab LLDP for peer device discovery. Support port mirroring for fault locating.

    Approval

    EMC

    CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)

    Safety

    CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)

    Chemistry

    CE-RoHS (201165EU); WEEE (201219EU); Reach (Regulation (EC) No.19072006)
