PoE Power Supply
|
|
PoE
Standard
|
IEEE
802.3af, IEEE 802.3at
|
|
PoE
Power Pin
|
End-span:
1/2(-), 3/6(+)
Mid-span:
4/5(+), 7/8(-)
8-pin
power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
|
|
PoE
Port
|
PoE:
Ports 1 to 24
|
|
Max.
Port Power
|
Port
1 to 24: 30 W
|
|
PoE
Power Budget
|
370
W
|
|
Network Parameters
|
|
Port
Number
|
24
× gigabit PoE port, and 2 × gigabit fiber optical port
|
|
Port
Type
|
RJ45
port, full duplex, MDI/MDI-X adaptive
|
|
Standard
|
IEEE
802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z
|
|
Forwarding
Mode
|
Store-and-forward
switching
|
|
Working
Mode
|
Standard
mode (default) Extend mode
|
|
MAC
Address Table
|
8 K
|
|
Switching
Capacity
|
52
Gbps
|
|
Packet
Forwarding Rate
|
36.688
Mpps
|
|
Internal
Cache
|
4.1
Mbits
|
|
Software Function
|
|
Device
Maintenance
|
Remote
upgrade, default parameters recovery, logs viewing, basic network parameters
configuration, import and export configuration, time sync
|
|
Port
Configuration
|
Port
rate configuration, flow control, and ports enabling
|
|
Long
Range
|
Up
to 300 m transmission
|
|
PoE
Configuration
|
PoE
watchdog: Ports 1 to 24 auto detect and restart the cameras that do not
respond.
PoE
enabling: Support
|
|
Port
Rate-Limiting
|
Rate-limiting
for ingress and egress ports
|
|
Storm
Control
|
Storm
control of unknown unicast, multicast and broadcast
|
|
Port
Mirroring
|
Support
|
|
Link
Aggregation
|
Static
link aggregation supported
|
|
Port
Isolation
|
Ports
in isolation group cannot communicate with each other.
|
|
QoS
|
WRR
and SP scheduling and port priority
|
|
VLAN
|
4094
VLANs
|
|
STP
|
STP
and RSTP protocols
|
|
SNMP
|
SNMPv1
and SNMPv2c supported for obtaining node information of the system and
interfaces
|
|
LLDP
|
LLDP
protocol supported for port configuration, global configuration and neighbor
discovery
|
|
General
|
|
Shell
|
Metal
material
|
|
Net
Weight
|
2.975
kg (6.56 lb)
|
|
Gross
Weight
|
3.535
kg (7.79 lb)
|
|
Dimension
(W × H × D)
|
440
mm × 44 mm × 221 mm (17.32” × 1.73” × 8.7”)
|
|
Operating
Temperature
|
-10°C
to 55°C (14°F to 131°F)
|
|
Storage
Temperature
|
-40°C
to 85°C (-40°F to 185°F)
|
|
Operating
Humidity
|
5%
to 95% (no condensation)
|
|
Relative
Humidity
|
5%
to 95% (no condensation)
|
|
Power
Supply
|
100
to 240 VAC, 50/60 Hz, Max. 6.5 A
|
|
Max.
Power Consumption
|
400
W
|
|
Power
Consumption in Idle
|
30
W
|
|
Approval
|
|
EMC
|
FCC
(47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN IEC 61000-3-2: 2019,
EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011 +A1: 2014, EN 55035: 2017); IC
(ICES-003: Issue 6); RCM (AS/NZS CISPR 32: 2015)
|
|
Safety
|
UL
(UL 60950-1); CB (IEC 60950-1:2005, AMD1:2009, AMD2:2013, IEC 62368-1: 2014
(Second Edition); CE-LVD (EN 60950-1: 2006 + A11: 2009 +A1: 2010+A12:
2011+A2: 2013, EN 62368-1: 2014+A11: 2017)
|
|
Chemistry
|
CE-RoHS
(2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006)
|
