Motion Detection 2.0
|
|
Human/Vehicle Analysis
|
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
|
|
Video and Audio
|
|
IP Video Input
|
2-ch (up to 18-ch) Up to 5 MP resolution
Support H.265+ / H.265 / H.264+ / H.264 IP cameras
|
|
Analog Video Input
|
16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
|
|
HDTVI Input
|
1080p25, 1080p30, 720p25, 720p30
|
|
AHD Input
|
1080p25, 1080p30, 720p25, 720p30
|
|
HDCVI Input
|
1080p25, 1080p30, 720p25, 720p30
|
|
CVBS Input
|
PAL/NTSC
|
|
HDMI Output
|
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
|
|
VGA Output
|
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
|
|
Video Output Mode
|
HDMI/VGA simultaneous output
|
|
Audio Input
|
1-ch RCA (2.0 Vp-p, 1 KΩ), and 16-ch via coaxial cable
|
|
Audio Output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-Way Audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
|
|
Synchronous Playback
|
16-ch
|
|
Recording
|
|
Video Compression
|
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
|
|
Encoding Resolution
|
For 1080p stream access: 1080p Lite / 720p Lite / WD1
For 720p stream access: 720p / WD1 / 4CIF
For standard definition stream access: WD1 / 4CIF / VGA
|
|
Frame Rate
|
Main stream:
For 1080p stream access: 1080p Lite / 720p Lite / WD1 @15 fps For 720p stream access: 720p / WD1 / 4CIF / VGA / CIF @15 fps
For SD stream access: WD1 / 4CIF / VGA / CIF@25 fps (P)/30 fps(N)
Sub-stream:
For 1080p and 720p stream access CIF/QVGA@15 fps
For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N)
|
|
Video Bitrate
|
32 Kbps to 4 Mbps
|
|
Dual-stream
|
Support
|
|
Stream Type
|
Video, Video & Audio
|
|
Audio Compression
|
G.711u
|
|
Audio Bitrate
|
64 Kbps
|
|
Network
|
|
Total Bandwidth
|
96 Mbps
|
|
Remote Connection
|
128
|
|
Network Protocol
|
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS, ONVIF
|
|
Network Interface
|
1, RJ45 10M/100M self-adaptive Ethernet interface
|
|
Auxiliary Interface
|
|
SATA
|
1, SATA interface
|
|
Capacity
|
Up to 6 TB capacity for each disk
|
|
USB Interface
|
2 × USB 2.0
|
|
General
|
|
Power Supply
|
12 VDC, 1.6 A
|
|
Consumption
|
≤ 7 W (without HDD)
|
|
Working Temperature
|
-10 °C to 55 °C (14 °F to 131 °F)
|
|
Working Humidity
|
10% to 90%
|
|
Dimension (W × D × H)
|
285 × 210 × 48 mm (11.2 × 8.3 × 1.9 inch)
|
|
Weight
|
≤ 1.8 kg (without HDD, 4.0 lb.)
|
