DS-7608NXI-K1

DS-7608NXI-K1

Hikvision DS-7608NXI-K1 8-ch K Series AcuSense 4K NVR, Up to 1-ch@12 MP or 2-ch@8 MP or 4-ch@4 MP or 8-ch@1080p decoding capacity, All channels support Motion Detection 2.0, 1-ch facial recognition for video stream, or 4-ch facial recognition for face picture, Incoming/Outgoing Bandwidth: 80 Mbps, HDMI/VGA independent output, 1 SATA interface, 12 VDC, 1.5A.

IP Video Input

Hikvision DS-7608NXI-K1 8-ch K Series AcuSense 4K NVR

Decoding Format

Supports H.265+/H.265/H.264+/H.264 Video formats

Bandwidth

Incoming bandwidth: 80 Mbps, Outgoing bandwidth: 80 Mbps

AcuSense

1-ch facial recognition for video stream, or 4-ch facial recognition for face picture

All channels support Motion Detection 2.0

Video Output

HDMI/VGA independent output

Resolution

Live view, storage, and playback at up to 12MP resolution

Interface

 1SATA interface connectable for recording and backup

Smart Function

Support multiple VCA (Video Content Analytics) events

Smart search for the selected area in the video

Facial Recognition

Facial Detection and Analytics

Face picture comparison, human face capture, face picture search

Face Picture Library

Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture 4MB, total capacity 1 GB)

Facial   Detection and Analytics Performance

1-ch human face capture

Face Picture Comparison

4-ch face picture comparison alarm

Motion Detection 2.0

Human/Vehicle Analysis

8-ch

Video and Audio

IP Video Input

8-ch

Incoming Bandwidth

80 Mbps

Outgoing Bandwidth

80 Mbps

HDMI Output

1-ch, 4K (3840 × 2160)/30 Hz,  2K (2560 ×  1440)/60 Hz,  1920  ×  1080/60  Hz,  1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

VGA Output

1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

Video Output Mode

HDMI/VGA independent output

CVBS Output

N/A

Audio Output

1-ch, RCA (Linear, 1 KΩ)

Two-Way Audio

1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

Decoding

Decoding Format

H.265 / H.265+ / H.264+ / H.264

Recording Resolution

12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 720p / VGA

Synchronous Playback

8-ch

Decoding Capability

AI on: 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)

AI off: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30fps)

Stream Type

Video, Video & Audio

Audio Compression

G.711ulaw / G.711alaw / G.722 / G.726 / AAC

Network

Remote Connection

128

Network Protocol

TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS

Network Interface

1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

Auxiliary Interface

SATA

1 SATA interface

Capacity

Up to 10 TB capacity for each HDD

USB Interface

Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0

General

Power Supply

12 VDC, 1.5 A

Consumption

10 W (without HDD)

Working Temperature

-10 °C to 55 °C (14 °F to 131 °F)

Working Humidity

10% to 90%

Dimension (W × D × H)

320 mm × 240 mm × 48 mm (12.6"× 9.4" × 1.9")

Weight

1 kg (without HDD, 2.2 lb.)

Certification

FCC

Part 15 Subpart B, ANSI C63.4-2014

CE

EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017


Note:

Alarm in/out can be optional for certain models. If you select a device model with "/Alarm4+1", then the device will have 4 alarm inputs and 1 alarm outputs.

Facial recognition and motion detection 2.0 cannot be enabled at the same time.
