Intelligent Analytics
|
|
AI by Device
|
Facial recognition,
perimeter protection, motion detection 2.0
|
|
AI by Camera
|
Facial recognition, perimeter
protection, throwing objects from building,
motion detection2.0, ANPR, VCA
|
|
Facial Recognition
|
|
Facial Detection and
Analytics
|
Face picture comparison,
human face capture, face picture search
|
|
Face Picture Library
|
Up to 16 face picture
libraries, with up to 20,000 face pictures in total (each picture ≤ 4
MB, total capacity ≤ 1
GB)
|
|
Facial Detection and
Analytics Performance
|
1-ch, 8 MP
|
|
Face Picture Comparison
|
4-ch
|
|
Motion Detection 2.0
|
|
By Device
|
All channels, 4 MP (when
enhanced SVC mode is enabled, up to 8 MP) video analysis for
human and vehicle
recognition to reduce false alarm
|
|
By Camera
|
All channels
|
|
Perimeter Protection
|
|
By Device
|
2-ch, 4 MP (HD network
camera, H.264/H.265) video analysis for human and vehicle
recognition to reduce false
alarm
|
|
By Camera
|
All channels
|
|
Video and Audio
|
|
IP Video Input
|
32-ch
|
|
Incoming Bandwidth
|
256 Mbps
|
|
Outgoing Bandwidth
|
160 Mbps
|
|
HDMI Output
|
1-ch, 4K (3840 × 2160) / 30
Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080 / 60 Hz, 1600 × 1200 / 60 Hz, 1280
× 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
|
|
VGA Output
|
1-ch, 1920 × 1080 / 60 Hz,
1280 × 1024 / 60 Hz, 1280 × 720/60 Hz
|
|
Video Output Mode
|
HDMI / VGA independent
output
|
|
CVBS Output
|
N/A
|
|
Audio Output
|
1-ch, RCA (2.0 Vp-p, 1 KΩ,
using the audio input)
|
|
Two-Way Audio
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Decoding
|
|
Decoding Format
|
H.265 / H.265+ / H.264+ / H.264
|
|
Recording Resolution
|
12 MP / 8 MP / 6 MP / 5 MP /
4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF
/ 2CIF / CIF / QCIF
|
|
Synchronous playback
|
16-ch
|
|
Decoding Capability
|
AI on: 1-ch@12 MP (30
fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
AI off: 2-ch@12 MP (30
fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps)
|
Stream Type
|
Video, Video & Audio
|
Audio Compression
|
G.711ulaw / G.711alaw / G.722
/ G.726 / AAC
|
Network
|
Remote Connection
|
128
|
API
|
ONVIF (profile S/G); SDK;
ISAPI
|
Compatible Browser
|
IE11, Chrome V57, Firefox
V52, Safari V12, Edge V89, or above version
|
Network Protocol
|
TCP/IP, DHCP, IPv4, IPv6,
DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
UPnP™, HTTP, HTTPS
|
Network Interface
|
1 RJ-45 10/100/1000 Mbps
self-adaptive Ethernet interface
|
Auxiliary Interface
|
SATA
|
2 SATA interfaces
|
Capacity
|
Up to 10 TB capacity for
each HDD
|
USB Interface
|
Front panel: 1 × USB 2.0;
Rear panel: 1 × USB 2.0
|
Alarm In/Out
|
4/1
|
General
|
Power Supply
|
12 VDC, 3.3 A
|
Consumption
|
≤ 15 W (without HDD)
|
Working Temperature
|
-10 °C to 55 °C (14 °F to
131 °F)
|
Working Humidity
|
10% to 90%
|
Dimension (W × D × H)
|
385 mm × 315 mm × 52 mm
(15.2"× 12.4" × 2.0")
|
Weight
|
≤ 1 kg (without HDD,
2.2 lb.)
|
Certification
|
FCC
|
Part 15 Subpart B, ANSI
C63.4-2014
|
CE
|
EN 55032: 2015, EN
61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
|
Obtained Certification
|
CE, FCC, IC, CB, KC, UL,
Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
|
