Intelligent Analytics
|
AI
by Device
|
Facial
recognition, perimeter protection, motion detection 2.0
|
AI
by Camera
|
Facial
recognition, perimeter protection, throwing objects from building, motion detection
2.0, ANPR, VCA
|
Facial Recognition
|
Facial
Detection and Analytics
|
Face
picture comparison, human face capture, face picture search
|
Face
Picture Library
|
Up
to 16 face picture libraries, with up to 20,000 face pictures in total (each
picture ≤ 4MB, total capacity ≤ 1 GB)
|
Facial
Detection and Analytics Performance
|
1-ch,
8 MP
|
Face
Picture Comparison
|
4-ch
|
Motion Detection 2.0
|
By
Device
|
All
channels, up to 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis
for human and vehicle recognition to reduce false alarm
|
By
Camera
|
All
channels
|
Perimeter Protection
|
By
Device
|
2-ch,
4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition
to reduce false alarm
|
By
Camera
|
All
channels
|
Video and Audio
|
IP
Video Input
|
16-ch
|
Incoming
Bandwidth
|
160
Mbps
|
Outgoing
Bandwidth
|
160
Mbps
|
HDMI
Output
|
1-ch,
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
VGA
Output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
|
Video
Output Mode
|
HDMI/VGA
independent output
|
CVBS
Output
|
N/A
|
Audio
Output
|
1-ch,
RCA (Linear, 1 KΩ)
|
Two-Way
Audio
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ, using the audio input)
|
Decoding
|
Decoding
Format
|
H.265
/ H.265+ / H.264+ / H.264
|
Recording
Resolution
|
12 MP/8
MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p
|
Synchronous
playback
|
16-ch
|
Decoding
Capability
|
AI
on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30
fps)
AI
off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p
(30 fps)
|
Stream
Type
|
Video,
Video & Audio
|
Audio
Compression
|
G.711ulaw
/ G.711alaw / G.722 / G.726 / AAC
|
Network
|
Remote
Connection
|
128
|
API
|
ONVIF
(profile S/G); SDK; ISAPI
|
Network
Protocol
|
TCP/IP,
DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™,
HTTP, HTTPS
|
Network
Interface
|
2
RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
|
Auxiliary Interface
|
SATA
|
4
SATA interfaces
|
Capacity
|
Up
to 10 TB capacity for each HDD
|
Serial
Interface
|
2
RS-485 (half-duplex), 1 RS-232
|
Alarm
In/Out
|
16/4
(16/9 is optional)
|
USB
Interface
|
Front
panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
|
Ctrl
12V
|
N/A
(optional to support)
|
DC
12V
|
N/A
(optional to support)
|
General
|
Power
Supply
|
100
to 240 VAC, 50 to 60Hz
|
Consumption
|
≤ 20 W (without HDD)
|
Working
Temperature
|
-10
°C to 55 °C (14 °F to 131 °F)
|
Working
Humidity
|
10
to 90 %
|
Dimension
(W × D × H)
|
445
× 400 × 75 mm (17.5"× 15.7" × 3.0")
|
Weight
|
≤ 5 kg (without HDD, 11 lb.)
|
Certification
|
FCC
|
Part
15 Subpart B, ANSI C63.4-2014
|
CE
|
EN
55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
|
