Intelligent Analytics
|
|
AI
by Device
|
Facial
recognition, perimeter protection, motion detection 2.0
|
|
AI
by Camera
|
Facial
recognition, perimeter protection, video structuralization, throwing objects
from building, motion detection 2.0, ANPR, people counting, VCA
|
|
Engine
|
1,
engine mode is adjustable
|
|
Facial Recognition
|
|
Facial
Detection and Analytics
|
Face
picture comparison, human face capture, face picture search
|
|
Face
Attributes
|
Wearing
glasses, wearing a mask, facial expression, body temperature
|
|
Face
Picture Library
|
Up
to 16 face picture libraries, with up to 50,000 face pictures in total (each
picture ≤ 512 KB, total capacity ≤ 1 GB)
|
|
Face
Picture Comparison (Captured from Camera)
|
8-ch
|
|
Facial
Detection and Analytics Performance
|
4-ch
human face capture (HD network camera, up to 2 MP, H.264/H.265)
|
|
Motion Detection 2.0
|
|
By
Device
|
All
channels for Hikvision cameras
|
|
By
Camera
|
All
channels
|
|
Perimeter Protection
|
|
By
Device
|
4-ch,
2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce
false alarm;
Up
to 12 rules in total
|
|
By
Camera
|
All
channels
|
|
ANPR
|
|
By
Camera
|
All
channels
|
|
Vehicle
Attributes
|
Plate
number, license plate color, license plate type
|
|
Plate
Attributes
|
Vehicle
brand, vehicle color, vehicle type
|
|
Video and Audio
|
|
IP
Video Input
|
32-ch
|
|
Incoming
Bandwidth
|
256
Mbps
|
|
Outgoing
Bandwidth
|
256
Mbps
|
|
HDMI
1 Output
|
4K
(3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 ×
1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
HDMI
2 Output
|
4K
(3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 ×
1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
VGA
Output
|
1920
× 1080/60 Hz, 1600 × 1200/60 HZ, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60
Hz
|
|
Video
Output Mode
|
HDMI1/VGA
simultaneous output, HDMI2/VGA independent output
|
|
CVBS
Output
|
1-ch,
BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
|
|
Audio
Output
|
1-ch,
RCA (Linear, 1 KΩ)
|
|
Two-Way
Audio
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ)
|
|
Decoding
|
|
Decoding
Format
|
H.265+
/ H.265 / H.264+ / H.264
|
|
Recording
Resolution
|
32MP
/ 24MP / 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 720p
32MP
/ 24MP / 12MP / 8MP / 7MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p
*:
The NVR supports up to 4-ch 32 MP/24 MP IP video inputs.
|
|
Synchronous
Playback
|
16-ch
|
|
Decoding
Capability
|
Enable
AI by NVR: 20-ch@1080p (30 fps)
Disable
AI by NVR: 32-ch@1080p (30 fps)
|
|
Dual-Stream
Recording
|
Support
|
|
Stream
Type
|
Video,
Video & Audio
|
|
Audio
Compression
|
G.711ulaw
/ G.711alaw / G.722 / G.726 / AAC / MP2L2 / PCM
|
|
Network
|
|
Network
Interface
|
2,
RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
Remote
Connection
|
128
|
|
Network
Protocol
|
TCP/IP,
DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
UPnP™, HTTP, HTTPS
|
|
API
|
ONVIF
(profile S/G); SDK; ISAPI
|
|
Auxiliary Interface
|
|
Serial
Interface
|
2
RS-485 (half-duplex), 1 RS-232
|
|
SATA
|
4
SATA interfaces
|
|
Capacity
|
Up
to 10 TB capacity for each disk
|
|
eSATA
|
1
eSATA interface
|
|
Alarm
In/Out
|
16/9
|
|
USB
Interface
|
Front
panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
|
|
Ctrl
12V
|
Controllable
12 VDC, 0.5 A power output for external alarm device; The power will be
turned on when the alarm output is triggered.
*:
The Ctrl 12V power is controlled by alarm output 9.
|
|
DC
12V
|
12
VDC, 1 A power output
|
|
General
|
|
Power
Supply
|
100
to 240 VAC, 50 to 60 Hz
|
|
Consumption
|
≤ 30 W (without HDD)
|
|
Working
Temperature
|
-10
°C to 55 °C (14 °F to 131 °F)
|
|
Working
Humidity
|
10%
to 90%
|
|
Chassis
|
19-inch
rack-mounted 1.5U chassis
|
|
Dimension
(W × D × H)
|
445
× 391 × 75 mm (17.5"× 15.4" × 3.0")
|
|
Weight
|
≤ 3.6 kg (without HDD, 7.9 lb.)
|
|
Certification
|
|
Obtained
Certification
|
CE,
CB, REACH, WEEE, UKCA, LOA
|
|
CE
|
EN
55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
|
