Video and Audio
|
|
IP
video input
|
16-ch
|
|
Up
to 12 MP resolution
32
MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP / 1080p / UXGA / 720p / VGA
*: 32 MP and 24 MP is only available for channel 1 when ultra-HD resolution
mode is enabled. For DS-8632NI-I8, when ultra-HD resolution mode is enabled,
it will reduce the IP video input to 24-ch.
|
|
Incoming
bandwidth
|
256
Mbps
|
|
Outgoing
bandwidth
|
256
Mbps
|
|
Incoming
bandwidth (RAID mode)
|
200
Mbps
|
|
Outgoing
bandwidth (RAID mode)
|
200
Mbps
|
|
HDMI
1 output
|
4K
(3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
HDMI
2 output
|
1920
× 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
VGA
1 output
|
1920
× 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
VGA
2 output
|
1920
× 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
Video
output mode
|
HDMI
1 and VGA 1 provide simultaneous video output, and work as the main output;
HDMI
2 and VGA 2 provide simultaneous video output, and work as the auxiliary
output
|
|
CVBS
output (optional)
|
1-ch,
BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
|
|
Audio
output
|
2-ch,
RCA (Linear, 1 KΩ)
|
|
Two-way
audio input
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ, using the audio input)
|
|
Decoding
|
|
Decoding
format
|
H.265+
/ H.265 / H.264+ / H.264 / MPEG4
|
|
Recording
resolution
|
32
MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP / 1080p / UXGA / 720p / VGA
*:
32 MP and 24 MP is only available for channel 1 when ultra-HD resolution mode
is enabled. For DS-8632NI-I8, when ultra HD resolution mode is enabled, it
will reduce the IP video input to 24-ch.
|
|
Synchronous
playback
|
16-ch
|
|
Capability
|
1-ch@32
MP (30 fps)/2-ch@12 MP (20 fps)/4-ch@8 MP (25 fps)/8-ch@4 MP (30
fps)/16-ch@1080p (30 fps)
|
|
Dual
stream recording
|
Support
|
|
Stream
type
|
Video,
Video & Audio
|
|
Network
|
|
Remote
connections
|
128
|
|
Network
protocol
|
TCP/IP,
DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
UPnP™, HTTP, HTTPS
|
|
Network
interface
|
2,
RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
RAID
|
|
RAID
Type
|
RAID0,
RAID1, RAID5, RAID6, and RAID10 (at least 4 TB for each HDD)
|
|
Auxiliary Interface
|
|
Serial
Interface
|
RS-232;
RS-485; Keyboard
|
|
SATA
|
8
SATA interfaces
|
|
eSATA
|
1
eSATA interface
|
|
Capacity
|
Up
to 10 TB capacity for each disk
|
|
Alarm
in/out
|
16/4
|
|
USB
interface
|
Front
panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
|
|
General
|
|
Power
supply
|
100
to 240 VAC, 50 to 60 Hz
|
|
Consumption
(without HDD)
|
≤ 30 W
|
|
Working
temperature
|
-10
°C to 55 °C (14 °F to 131 °F)
|
|
Working
humidity
|
10%
to 90%
|
|
Dimension
(W × D × H)
|
445
× 470 × 94 mm (17.5"× 18.5" × 3.7")
|
|
Weight
(without HDD)
|
≤ 8 kg (17.6 lb)
|
|
Certification
|
|
FCC
|
Part
15 Subpart B, ANSI C63.4-2014
|
|
CE
|
EN
55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
|
