Intelligent Analytics
|
|
AI by NVR
|
Facial recognition, perimeter protection, motion detection 2.0
|
|
AI by Camera
|
Facial recognition, perimeter protection, throwing objects from building, motion detection 2.0, ANPR, people counting, VCA
|
|
Engine
|
1, engine mode is adjustable
|
|
Facial Recognition
|
|
Facial Detection and Analytics
|
Face picture comparison, human face capture, face picture search
|
|
Face Picture Library
|
Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤512 KB, total capacity ≤ 1 GB)
|
|
Face Picture Comparison (Captured from Camera)
|
8-ch
|
|
Facial Detection and Analytics Performance
|
4-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)
|
|
Motion Detection 2.0
|
|
By NVR
|
All channels for Hikvision cameras
|
|
By Camera
|
All channels
|
|
Perimeter Protection
|
|
By NVR
|
4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total
|
|
By Camera
|
All channels
|
|
ANPR
|
|
By Camera
|
All channels
|
|
Vehicle Attributes
|
Plate number, license plate color, license plate type
|
|
Plate Attributes
|
Vehicle brand, vehicle color, vehicle type
|
|
Video and Audio
|
|
IP Video Input
|
64-ch
|
|
Incoming Bandwidth
|
384 Mbps
|
|
Outgoing Bandwidth
|
256 Mbps
|
|
HDMI 1 Output
|
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
HDMI 2 Output
|
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
VGA 1 Output
|
1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
VGA 2 Output
|
1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 ×768/60 Hz
|
|
Video Output Mode
|
HDMI1/VGA1 simultaneous output, HDMI2/VGA2 simultaneous output, HDMI1/HDMI2 independent output
|
|
CVBS Output
|
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
|
|
Audio Output
|
2-ch, RCA (Linear, 1 KΩ)
|
|
Two-Way Audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ)
|
|
Decoding
|
|
Decoding Format
|
H.265+ / H.265 / H.264+ / H.264
|
|
Recording Resolution
|
32MP / 24MP / 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
*: The NVR supports up to 4-ch 32 MP/24 MP IP video inputs.
|
|
Synchronous Playback
|
16-ch
|
|
Live View Window Division
|
1 / 2 / 4 / 6 / 8 / 9 / 16 / 25 / 32 / 36 / 64
|
|
Aux Port Window Division
|
1 / 2 / 4 / 6 / 8 / 9 / 16 / 25 / 32 / 36
|
|
Decoding Capability
|
Enable AI by NVR: 20-ch@1080p (30 fps) Disable AI by NVR: 32-ch@1080p (30 fps)
|
|
Dual-Stream Recording
|
Support
|
|
Stream Type
|
Video, Video & Audio
|
|
Audio Compression
|
G.711ulaw / G.711alaw / G.722 / G.726 / AAC / MP2L2 / PCM
|
|
Network
|
|
Network Interface
|
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
Remote Connection
|
128
|
|
Network Protocol
|
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
|
|
API
|
ONVIF (profile S/G); SDK; ISAPI
|
|
RAID
|
|
RAID Type
|
RAID0, RAID1, RAID5, RAID6, RAID10 Support global hot spare
|
|
Auxiliary Interface
|
|
Serial Interface
|
1 RS-485 (full-duplex), 1 RS-232
|
|
SATA
|
8 SATA interfaces
|
|
Capacity
|
Up to 14 TB capacity for each disk
|
|
eSATA
|
1 eSATA interface
|
|
Alarm In/Out
|
16/9
|
|
USB Interface
|
Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0
|
|
General
|
|
Power Supply
|
100 to 240 VAC, 50 to 60 Hz
|
|
Consumption
|
≤ 30 W (without HDD)
|
|
Working Temperature
|
-10 °C to 55 °C (14 °F to 131 °F)
|
|
Working Humidity
|
10% to 90%
|
|
Chassis
|
2U chassis
|
|
Dimension (W × D × H)
|
440 × 457 × 94 mm (17.4"× 18.0" × 3.7")
|
|
Weight
|
≤ 7.1 kg (without HDD, 15.7 lb.)
|
|
Certification
|
|
Obtained Certification
|
CE, CB, REACH, WEEE, UKCA, LOA
|
|
CE
|
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
|
