Video & Audio input
|
|
|
IP video input
|
128-ch
|
|
|
Incoming/outgoing bandwidth
|
768 Mbps / 512 Mbps
|
|
|
Incoming/outgoing bandwidth (RAID mode)
|
768 Mbps / 512 Mbps
|
|
|
TLS outgoing bandwidth
|
128 Mbps, or 64 Mbps (when RAID is enabled)
|
|
|
Video & Audio output
|
|
|
HDMI output
|
Two independent HDMI outputs of 4K resolution. Resolution: 4K
(4096 × 2160), 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1080p (1920 ×
1080)/60Hz, UXGA (1600 × 1200)/60Hz, SXGA (1280 × 1024)/60Hz, 720p (1280 ×
720)/60Hz, XGA (1024 × 768)/60Hz
|
|
|
VGA output
|
1-ch. Resolution: 1080p (1920 × 1080) /60Hz, UXGA (1600 ×
1200) /60Hz, SXGA (1280 × 1024) /60Hz, 720p (1280 × 720) /60Hz, XGA (1024 ×
768) /60Hz
|
|
|
Audio output
|
1-ch. RCA (2.0 Vp-p, 1 KΩ)
|
|
|
Video & Audio decoding
|
|
|
Decoding format
|
H.265, H.265+, H.264, H.264+ (for Hikvision IP camera only)
|
|
|
Video resolution
|
12MP / 8MP / 7MP / 6MP / 5MP / 4MP / 3MP / 1080p
|
|
|
Synchronous playback
|
Up to 16 channels
|
|
|
Capability
|
3-ch@12 MP (30fps), 5-ch@8 MP (30fps), 6-ch@6 MP (30fps),
10-ch@4 MP (30fps), 20-ch@1080p (30 fps)
|
|
|
HDD
|
|
|
Interface
|
16 SATA interfaces supporting hot-plug
|
|
|
Capacity
|
Up to 10 TB for each HDD
|
|
|
Storage extension
|
1 × eSATA interface
|
|
|
RAID
|
|
|
RAID Type
|
RAID0, RAID1, RAID5, RAID 6, and RAID10
|
|
|
Network management
|
|
|
Protocol
|
IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE,
DDNS
|
|
|
Network interface
|
4, RJ45 10M / 100M / 1000M self-adaptive Ethernet interface
|
|
|
External interface
|
|
|
Two-way audio input
|
1-ch, RCA (2.0 Vp-p, 1 KΩ)
|
|
|
Serial port
|
RS-232; RS-485; Keyboard
|
|
|
USB interface
|
Front Panel: 2 × USB 2.0; Rear Panel: 2 × USB 3.0
|
|
|
Alarm input/output
|
16/8
|
|
|
Decoding board
|
1
|
|
|
General
|
|
|
Power supply
|
100 to 240 VAC
|
|
|
Fan
|
Redundant dual ball bearing fan; Speed adjustable; Hot-plug
|
|
|
Consumption (without HDD)
|
≤ 140W
|
|
|
Working temperature
|
0 °C to + 50 °C (32 °F to 122 °F)
|
|
|
Working humidity
|
10% to 90%
|
|
|
Dimension (W × D × H)
|
442 × 494 × 146 mm (17.4 × 19.4 × 5.7 inch)
|
|
|
Weight (without HDD)
|
≤ 16 kg (35.3 lb)
|
|
|
Video wall management
|
|
HDMI output/input
|
6/1
|
|
HDMI output resolution
|
4K (3840x2160)/60Hz, 4K (3840x2160)/30Hz, 2K (2560x1440)/60Hz,
1080p (1920x1080)/60Hz, SXGA (1280x1024)/60Hz, 720p (1280x720)/60Hz, XGA
(1024x768)/60Hz
|
|
HDMI input resolution
|
1080p (1920x1080), SXGA (1280x1024), 720p (1280x720), XGA
(1024x768)
|
|
Decoding capacity
|
48-ch@1080p
|
|
Decoding resolution
|
12MP / 8MP / 7MP / 6MP / 5MP / 3MP / 1080p / 720p
|
|
Collage
|
Supported
|
|
Auto-switch
|
Supported
|
|
Open window
|
Supported
|
|
Layer overlay
|
Supported
|
|
Window roaming
|
Supported
|
|
Display local signal source on video wall
|
Supported
|
