Video and Audio
|
|
IP
Video Input
|
32-ch
|
|
Incoming
Bandwidth
|
320
Mbps
|
|
Outgoing
Bandwidth
|
400
Mbps
|
|
HDMI
1 Output
|
8K
(7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz,
1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
|
|
HDMI
2 Output
|
4K
(3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz,
1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
*:
When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.
|
|
VGA
1 Output
|
1920
× 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
VGA
2 Output
|
1920
× 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
Video
Output Mode
|
HDMI
1 and VGA 1 provide simultaneous video output, and work as the main output;
HDMI
2 and VGA 2 provide simultaneous video output, and work as the auxiliary
output
|
|
CVBS
Output
|
1-ch,
BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
|
|
Audio
Output
|
2-ch,
RCA (Linear, 1 KΩ)
|
|
Two-Way
Audio
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ, using the audio input)
|
|
Decoding
|
|
Decoding
Format
|
H.265+
/ H.265 / H.264+ / H.264
|
|
Recording
Resolution
|
32
MP/24 MP/12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p
|
|
Synchronous
playback
|
16-ch
|
|
Decoding
Capability
|
2-ch@32
MP (30 fps) + 2-ch@8 MP (30 fps)/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p
(30 fps)
|
|
Network
|
|
Network
Protocol
|
TCP/IP,
DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™,
HTTP, HTTPS
|
|
Network
Interface
|
2,
RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
RAID
|
|
RAID
Type
|
RAID0,
RAID1, RAID5, RAID6, RAID10
|
|
Auxiliary Interface
|
|
Serial
Interface
|
1
RS-485 (full-duplex), 1 RS-232
|
|
SATA
|
8
SATA interfaces supporting hot-plug
|
|
eSATA
|
1
eSATA interface
|
|
Capacity
|
Up
to 16 TB capacity for each disk
|
|
Alarm
In/Out
|
16/9
|
|
USB
Interface
|
Front
panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0
|
|
DC
12V
|
12
VDC, 1 A power output
|
|
General
|
|
Power
Supply
|
100
to 240 VAC, 50 to 60 Hz
|
|
Consumption
|
≤ 50 W (without HDD)
|
|
Working
Temperature
|
-10
°C to 55 °C (14 °F to 131 °F)
|
|
Working
Humidity
|
10%
to 90%
|
|
Chassis
|
2U
chassis
|
|
Dimension
(W × D × H)
|
445
× 465 × 93 mm (17.5"× 18.3" × 3.7")
|
|
Weight
|
≤ 10 kg (without HDD, 22 lb.)
|
|
Certification
|
|
Obtained
Certification
|
CE,
FCC
|
|
FCC
|
Part
15 Subpart B, ANSI C63.4-2014
|
|
CE
|
EN
55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
|
