Key specs
- 5 V 200 W LED power supply, 40 A output
- Input 176 to 264 VAC
- Efficiency ≥ 87%
- Protection: short circuit and overload
- Size 190 × 82 × 30 mm (L × W × H)
- Working temperature -20 °C to +50 °C (AC 230 V, see load derating curve)
- 100% full-load aging test (Hikvision)
| Output | |
|---|---|
| Output voltage | 5 V |
| Output current | 40 A |
| Rated power | 200 W |
| Ripple noise | 150 mVp-p |
| Voltage adjustment range | ± 10% |
| Voltage accuracy | ± 1.0% |
| Line regulation | ± 0.5% |
| Load regulation | ± 2% |
| Start-up and rise time | 500 ms, 50 ms / 230 VAC, load 100% |
| Hold-up time | 20 ms / 230 VAC, load 100% |
| Input | |
| Input voltage | 176 to 264 VAC |
| Frequency range | 47 to 63 Hz |
| Power factor | PF ≥ 0.5 |
| Efficiency | ≥ 87% |
| AC current | 2.3 A (230 VAC) |
| Inrush current | 60 A / 230 VAC |
| Leakage current | < 1 mA / 230 VAC |
| Overload protection | 110% to 140% rated |
| Environment | |
| Operating temperature | -20 °C to +50 °C (AC 230 V, see load derating curve) |
| Operating humidity | 20% to 90% RH, non-condensing |
| General | |
| Product size | 190 × 82 × 30 mm (L × W × H) |
