Motion Detection 2.0
|
Human/Vehicle
Analysis
|
Deep
learning-based motion detection 2.0 is enabled by default for all analog channels,
it can classify human and vehicle, and extremely reduce false alarms caused by
objects like leaves and lights;
Quick
search by object or event type is supported;
|
Recording
|
Video
Compression
|
H.265
Pro/H.265
|
Encoding
Resolution
|
1080p
Lite / 720p / 720p Lite
|
Frame
Rate
|
Main
stream:
1080p Lite/720p/720p Lite/WD1/4CIF@25 fps (P)/30 fps (N)
Note:
1080p Lite/720p is 15 fps by default
Sub-stream:
4CIF@15 fps; CIF/QVGA@25 fps (P) / 30 fps (N)
|
Video
Bitrate
|
According
to the actual scene, scene-adaptive bitrate control technology would automatically
allocate appropriate bitrate to ensure the stability of recording period.
|
Stream
Type
|
Video,
Video & Audio
Note: In order to protect privacy, the device will only record video (without
audio) by default. If you want to record audio, you shall manually enable
audio recording. For operation details, refer to the user manual.
|
Audio
Compression
|
G.711u
|
Audio
Bitrate
|
64 Kbps
|
Video and Audio
|
IP Video
Input
|
1-ch
Up to
1080p resolution
Support
H.265+/H.265 IP cameras
|
Analog
Video Input
|
4-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
|
HDTVI
Input
|
1080p25,
1080p30, 720p25, 720p30
|
AHD
Input
|
1080p25,
1080p30, 720p25, 720p30
|
HDCVI
Input
|
1080p25,
1080p30, 720p25, 720p30
|
CVBS
Input
|
Support
|
HDMI
Output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
|
VGA
Output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
|
Video
Output Mode
|
HDMI/VGA
simultaneous output
|
Audio
Input
|
4-ch
via coaxial cable
|
Audio
Output
|
1-ch
via HDMI
|
Synchronous
playback
|
4-ch
|
Network
|
Total
Bandwidth
|
64 Mbps
Incoming
bandwidth: 4 Mbps
|
Remote
Connection
|
32
|
Network
Protocol
|
TCP/IP,
DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
|
Network
Interface
|
1, RJ45
10/100 Mbps self-adaptive Ethernet interface
|
Auxiliary Interface
|
Capacity
|
Built-in
330 GB eSSD (300 GB available)
Note: The device can store about 2 weeks videos for 4-ch analog cameras (default
parameters), this estimation is for reference only.
|
USB
Interface
|
Rear
panel: 2 × USB 2.0
|
Alarm
In/Out
|
N/A
|
General
|
Power
Supply
|
12 VDC,
1 A
|
Consumption
|
≤ 5.4 W (with eSSD)
|
Working
Temperature
|
-10
°C to 45 °C (14 °F to +113 °F)
|
Working
Humidity
|
10%
to 90%
|
Dimension
(W × D × H)
|
151
× 121 × 46 mm (5.94 × 4.76 × 1.81 inch)
|
Weight
|
≤ 0.5 kg (with eSSD, 1.1 lb.)
|
