DS-K3H4420-120
Full height turnstile, two 600 mm lanes in one frame
- Two 600 mm lanes in one frame, both directions
- SUS304 stainless steel, indoor and outdoor
- More than 30 persons per minute
- Arms turn freely in a power cut
DS-K3H4420-120
Full height turnstile, two 600 mm lanes in one frame
- Two 600 mm lanes in one frame, both directions
- SUS304 stainless steel, indoor and outdoor
- More than 30 persons per minute
- Arms turn freely in a power cut
Key specs
- Two lanes in one frame, 600 mm each, both directions
- Full height, 2230 mm
- More than 30 persons per minute
- MCBF more than 2 million cycles
- SUS304 stainless steel 1.2 mm, stainless steel pipe 1.0 mm
- Arms unlock into free passing in a power cut, for evacuation
- LED direction indicator, valid passing time
- 100 to 240 VAC; indoor and outdoor, -15 to 55 °C
- 2100 x 1270 x 2230 mm, 200 kg
| System | |
|---|---|
| MCBF | More than 2 million times |
| General | |
| Throughput | More than 30 persons per minute (the actual throughput depends on the person passing rate and passing method) |
| Lanes | Two, in one frame |
| Lane width | 600 mm |
| Pedestal material | SUS304 stainless steel 1.2 mm (0.05"); stainless steel pipe 1.0 mm (0.04") |
| Power supply | 100 to 240 VAC; 50 to 60 Hz |
| Working temperature | -15 °C to 55 °C (5 °F to 131 °F) |
| Working humidity | 10% to 90% (no condensing) |
| Dimensions | Without package: 2100 mm × 1270 mm × 2230 mm (82.7" × 50" × 87.8") |
| Application environment | Indoor and outdoor |
| Weight | Without package: 200 kg (441 lbs); with package: 400 kg (882 lbs) |
| Function | |
| Direction indicator | LED shows whether passing is allowed or forbidden |
| Power failure | Arms unlock into free passing for evacuation |
| Valid passing duration | Permission is cancelled if the person does not pass in time |
| Direction | Bi-directional |
| Accessory (optional) | |
| Face terminal | DS-K1T671, DS-K1T671M Pro face access terminals |
Know before you buy
Quick answers about the DS-K3H4420-120/Pg-Dm60, and how it compares.
How many people can pass per minute?
More than 30 persons per minute. The real figure depends on how fast people show their face or card and walk through.
What happens in a power cut?
The arms unlock into free passing, so people can leave the site. Plan a guard or a second lock point if the site must stay closed during a power cut.
Can it go outdoors?
Yes. Hikvision rates it for indoor and outdoor use, -15 to 55 °C, with a waterproof structure in SUS304 stainless steel. Clean it every month (every week near the sea or chemical plants); for those sites Hikvision suggests 316 stainless steel, so ask us first.
How do people get through?
The Pg version takes a Hikvision face terminal on the post (Hikvision lists the DS-K1T671M, DS-K1T671). The terminal checks the face or card and lets the person through. It turns both ways, so a second terminal can check people on the way out.
What if someone is let in but does not walk through?
The turnstile has a valid passing duration: if the person does not pass in time, the permission is cancelled and the next person must authenticate again.
Single lane or two lanes?
This is the two lane version: two 600 mm lanes in one frame. For one 650 mm lane, see the DS-K3H4411-120.
Can I buy it online?
Turnstiles are installed products, so we start with a free pre-sales consultation: our engineers survey the entrance, suggest the version and terminals, and send a quote. Use Request a Quote on this page, contact us or WhatsApp +92 300 ESCO 301. Offices in Karachi, Lahore, Islamabad and Rawalpindi.
