HM 3

An omnidirectional condenser headworn microphone for hands-free speaking: light double-ear headband, boom on either side, TA4F connector for the R300 bodypack. Scroll down for details.

Rs. 0 Rs. 0

  • Brand - Electro-Voice
Electro-Voice
Electro-Voice

Innovative audio, trusted worldwide for clarity and reliability.

R300 Wireless

HM 3

Headworn omni condenser microphone, TA4F

Omni condenser | 50 Hz to 20 kHz | 10 mV/Pa | TA4F | For R300-E and bodypacks

Electro-Voice

HM3 · Omnidirectional Headworn Microphone

Hands-free sound.
A fit that adapts.

An adjustable double-ear headband and a flexible boom that mounts on either side. Position your microphone for presentations and performances, with a TA4F connection to your compatible bodypack.

Electro-Voice HM3 black headworn microphone shown in two views, including its cable and TA4F connector

Designed around the way you wear it

Explore the fit, positioning and connection features of the Electro-Voice HM3.

Hands-free presentations

Keep your hands available for notes, demonstrations or performing while the microphone stays supported on your head.

Adjust the fit

Set the lightweight double-ear headband to fit securely over both ears for your presentation or performance.

Choose your boom side

Mount the microphone boom on the left or right ear hook to suit your preferred wearing position.

Position the microphone

Use the flexible gooseneck at the boom end to place the microphone where you need it.

Keep the cable in place

Clip the cable securely to the headband to manage its routing as you wear the microphone.

Connect to your R300 bodypack

The TA4F connector connects the HM3 to the BP-300 bodypack used in the Electro-Voice R300 wireless system.

R300 wireless systems

Electro-Voice R300-HD/B handheld wireless system with clearscan

R300-HD/B

Handheld wireless system with ClearScan

View product

Electro-Voice R300-L/B lavalier wireless system for presenters

R300-L/B

Lavalier wireless system for presenters

View product

Electro-Voice R300-E/B headworn wireless system, hands free

R300-E/B

Headworn wireless system, hands free

View product

electro-voice-hm3-datasheet.pdf
Download
electro-voice-r300-wireless-system-user-guide.pdf
Download

Key specs

  • Omnidirectional back-electret condenser microphone
  • Frequency response: 50 Hz–20 kHz
  • Sensitivity: 10 mV/Pa at 1 kHz; impedance: 200 Ω
  • TA4F connector with 1 m cable
  • Compatible with the Electro-Voice BP-300 bodypack in the R300 wireless system
  • Adjustable double-ear headband with left- or right-side boom mounting
Chat on WhatsApp

Electro-Voice HM3 Technical Specifications

Audio Specifications

SpecificationValue
Generating elementBack-electret condenser
Polar patternOmnidirectional
Frequency response50–20,000 Hz
Impedance200 Ω
Sensitivity — open-circuit voltage at 1 kHz10.0 mV/Pa

Connectivity

SpecificationValue
ConnectorTA4F
Cable length1 m
Pin 1Ground
Pin 2Microphone input
Pin 3+5 V bias
Pin 4Not connected

Mechanical Specifications

SpecificationValue
HeadbandAdjustable, double-ear design
Boom mountingLeft or right side
Microphone positioningFlexible gooseneck at boom end
Length — without cable180 mm (7.086 in)
Width — widest, without cable105 mm (4.133 in)
Width — narrowest, without cable15 mm (0.59 in)
FinishSemi-gloss black
Net weight28 g
Shipping weight40 g

Included Accessory

ItemDescription
WindscreenFoam windscreen
Questions & answers

Know before you buy

Quick answers about the HM 3, and how it compares.

What is the Electro-Voice HM3?

A lightweight omnidirectional condenser headworn microphone: double-ear headband, boom on the left or right, TA4F connector. It is the microphone head only, no transmitter.

Is the HM3 a complete wireless system?

No. The complete set is the R300-E/B: HM3, bodypack and receiver. Buy the HM3 alone as a spare or a second head.

Which bodypacks does it fit?

The R300 BP-300 bodypack and any bodypack with a TA4F input. 1 m cable, +5 V bias on pin 3.

Who is it for?

Presenters, trainers and teachers, fitness instructors, and Imams leading prayer hands-free. The omni pickup keeps the voice steady when the head turns.

Left or right side?

Either. The boom clips to the left or right ear hook, the flexible tip sets the position, and the cable clips to the band.

Who is the authorised Electro-Voice distributor in Pakistan?

ESCO is the authorised Electro-Voice distributor in Pakistan. Ask us for the price, stock and a quotation.
