Key specs
- 3MP (2K, 2048 × 1296) outdoor unit, 162° view, IR night vision up to 6 m
- 7-inch indoor touch screen
- Human motion and lingering detection alerts
- Opens the door and the gate: RFID card, app, indoor screen
- 2-wire connection, up to 50 m (100 m with 1.5 mm² cable)
- Two-way talk with voice changer, up to 20 ringtones
- 2.4 / 5 GHz Wi-Fi, microSD up to 512 GB, EZVIZ Cloud
- Weatherproof outdoor unit with tamper alarm, −30 to 60 °C
|
Outdoor Doorbell |
|
|
Image Sensor |
1/2.7" Progressive Scan CMOS (Supports low light sensitivity) |
|
Lens |
2.0 mm @ F2.2, viewing angle: 162° (Diagonal) |
|
Day & Night |
IR-cut filter with auto-switching, 850 nm infrared light × 2 (max. 6m) |
|
Max. Resolution |
2048 × 1296 |
|
DNR |
2D / 3D DNR |
|
Video Compression |
H.265 / H.264 |
|
Frame Rate |
Max: 15fps; Self-Adaptive during network transmission |
|
Connection and Function |
|
|
Connection Method |
Wired connection (2-Wired, capable with 4-Wired), digital signal transmission |
|
Transmission Distance |
Φ 2 x 0.75mm², max. 50m Φ 2 x 1.5mm² , max. 100m Twisted pair, max. 120m |
|
Open the door (Gate) |
Support 2 wiring ports. 1-10m distance. The intercom panel provides a “dry”-contact connection, without an electric current, to connect to the button for automated gate, gate breaking capacity: 12V / 2A |
|
Unlock (Electric strike plate) |
Support 2 wiring ports. 1-10m distance. The electric strike plate or lock that you order must have a mechanical memory; the power supply to the electric strike plate or lock must not exceed 12V / 1.1A, otherwise should do as user manual. |
|
Door Open Methods |
1. RFID badge unlock 2. App remote unlock 3. Indoor display unlock |
|
Outdoor Doorbell Interface |
|
|
Audio Input |
Built-in high-sensitivity microphone |
|
Audio Output |
Built-in high-power speaker |
|
Doorbell Button |
Yes. The light can be set on or off. |
|
Name Card |
Three handwritten name cards in total (one already on the intercom panel). The light can be set on or off. |
Functions | |
Intelligent Alarm | Smart human motion detection, Lingering Detection |
Tamper Alarm | Supports |
Video Intercom | Long-distance video two-way talk |
General | |
Operation Conditions | -30°C to 60°C, Humidity 95% or less (non-condensing) |
IP Grade | Waterproof, with shield cover |
Size | 161 × 87 × 20 mm (6.34 × 3.42 × 0.79 inch) |
Interior Display | |
Display size | 7” touch screen |
Resolution | 1024 × 600 |
Interface | |
Audio Input | Built-in high-sensitivity microphone |
Audio Output | Built-in high-power speaker |
Button | Screen On / Off Button |
Terminal | Two wiring ports to connect 1st outdoor doorbell. |
Storage | Supports microSD card up to 512 GB Supports EZVIZ Cloud storage |
Network Parameters | |
Protocol | EZVIZ Cloud Proprietary Protocol |
Interface Protocol | EZVIZ Coud Proprietary Protocol |
Protocol | EZVIZ Connect Protocol |
Wi-Fi Parameters | |
Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n, 802.11ac |
Frequency Range | 2.4G: 2.4 GHz ~ 2.4835 GHz 5G: 5.15 GHz ~ 5.25 GHz |
Channel Bandwidth | Supports 20MHz |
Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps, 11ac: 433.3Mbps |
Function | |
Multiple ringtones | Up to 20 ringtones |
Functions | Live view, playback, two-way talk, video call |
General | |
Operation Conditions | -10°C to 45°C, humidity 95% or less (non-condensing) |
Weight | Net weight: 855 g (30.16 oz) With package: 1825 g (64.37 oz) |
Size | 180 × 111 × 15 mm (7.09 × 4.37 × 0.59 inch) |
Power Supply | DC 24V / 1A power supply, adaptor (100- 240Vac) |
Power Consumption | 8W, Max. 24W |
Know before you buy
Quick answers about the HP7, and how it compares.
What does people and lingering detection do?
The HP7 recognises people at the door and alerts your phone when someone stays there, even if they do not ring. Passing cars and animals are ignored, so you get fewer false alerts.
HP7 or HP5?
The HP5 costs less, with a 2MP camera and 134° view. The HP7 adds 3MP, a wider 162° view that shows parcels and people close to the door, and people detection.
What wiring does it need, and can it open my door or gate?
The outdoor and indoor units connect with just 2 wires, up to 50 m apart (100 m with 1.5 mm² cable), so an old doorbell or intercom cable can often be reused. The indoor screen needs a power point.
It can release an electric door lock and a gate from the screen, an RFID card or the EZVIZ app. The electric lock or gate motor is separate; ask us on WhatsApp what suits your door.
Which EZVIZ door phone should I choose?
| Model | Camera | Inside screen | Wiring | Opens door or gate |
|---|---|---|---|---|
| DP2C | 2MP, 155° | 4.3-inch | None, battery, fits the door peephole | No |
| HP5 | 2MP, 134° | 7-inch touch | 2 wires, up to 50 m | Yes, door and gate |
| HP7 | 3MP, 162°, detects people | 7-inch touch | 2 wires, up to 50 m | Yes, door and gate |
Flat or apartment door with a peephole: DP2C. House with a gate or main door you want to open from inside or from your phone: HP5, or HP7 for a wider view and people detection.
How does it record, and do I need a subscription?
Video is saved on a microSD card in the camera (not included). When the card is full, the oldest video is overwritten automatically. ESCO stocks genuine EZVIZ cards in 64 GB and 128 GB.
No subscription is needed: live view, playback, alerts and AI detection all work in the free EZVIZ app. EZVIZ CloudPlay is an optional paid plan that also keeps alert clips online, so they are safe even if the camera or card is stolen.
Who sells EZVIZ in Pakistan, and what warranty and support do I get?
Electronic Security Company (ESCO) is the authorized national distributor of EZVIZ in Pakistan, so every unit is genuine and comes with a 1-year warranty. Warranty is carry-in: bring the unit to an ESCO office or the dealer you bought from, and after inspection it is repaired or replaced.
Order here and delivery is free anywhere in Pakistan. We keep stock in Karachi, Lahore, Islamabad and Rawalpindi, and our dealer network covers almost every other city. EZVIZ products are made to set up yourself in the EZVIZ app; if you get stuck, our helpdesk helps on WhatsApp, phone and email, 10am to 6pm. Use Add to Cart, or Request a Quote for several units.
