DS-K3B411BX
Value swing barrier, indoor and outdoor, 650 to 1100 mm lanes
- Card, face or QR code; built-in access controller
- 6 pairs of IR detectors stop tailgating
- Brushless motor, MCBF 3 million or more
- Opens on fire alarm and on power failure
DS-K3B411BX
Value swing barrier, indoor and outdoor, 650 to 1100 mm lanes
- Card, face or QR code; built-in access controller
- 6 pairs of IR detectors stop tailgating
- Brushless motor, MCBF 3 million or more
- Opens on fire alarm and on power failure
Key specs
- Swing barrier: stainless steel pipe and acrylic glass wings, SUS304 pedestals
- Built-in access controller: 500,000 cards; card, face or QR code
- M versions: Mifare reader; Pg versions: face terminal bought separately
- 6 pairs of IR detectors: anti-tailgating
- Lanes 650, 750, 900 or 1100 mm; 20 to 60 persons per minute
- Brushless motor, MCBF 3 million or more
- Opens on fire alarm and on power failure; stops on obstruction
- Indoor and outdoor, -20 to 65 °C; 65 W standby
- 1200 x 200 x 1020 mm per pedestal; door height 0.77 m
| System | |
|---|---|
| Motor | Brushless motor |
| MCBF | ≥ 3 million times |
| IR light detectors | 6 pairs |
| Interface | |
| Network interface | 1 |
| Lock control | 2 |
| Exit button | 2 |
| Alarm output | 2 |
| RS-485 | 4 |
| RS-232 | 2 |
| Hardware | |
| Access controller | Supplied |
| Capacity | |
| Card capacity | 500,000 |
| Authentication | |
| Authentication mode | Card, face, QR code |
| Card type | EM, M1 |
| Function | |
| IR light detectors | 6 pairs: permission validation and anti-tailgating |
| Direction indicator | LED shows the passing direction |
| Obstruction | The barrier stops for a while when it detects an obstruction while opening or closing |
| Self-check | Self-detection, self-diagnostics and automatic alarm |
| Valid passing duration | Permission is cancelled if the person does not pass in time |
| Fire alarm | The barrier opens automatically when the fire alarm is triggered |
| Power failure | The barrier opens automatically when the power goes down |
| Remote controller | 433 MHz, 868 MHz |
| General | |
| Throughput | 20 to 60 persons per minute (the actual throughput depends on the person passing rate and passing method) |
| Lane width | 550 mm to 1100 mm; configurations 650, 750, 900, 1100 mm (650 mm recommended) |
| Barrier material | Stainless steel pipe; acrylic glass |
| Door height | 0.77 m (default) |
| Door wing gap | 50 mm (default) |
| Pedestal material | SUS304 stainless steel |
| Pedestal size | Length 1200 mm, width 200 mm; wall distance 60 mm |
| Power consumption | 65 W (standby) |
| Working temperature | -20 °C to 65 °C (-4 °F to 149 °F) |
| Working humidity | 10% to 95% (no condensing) |
| Dimensions | Without package: 1200 mm × 200 mm × 1020 mm (47.2" × 7.9" × 40.2"); with package: 1408 mm × 348 mm × 1156 mm |
| Weight (net) | Left: 38.3 kg; middle: 43.3 kg; right: 40.2 kg |
| Application environment | Indoor and outdoor |
| Base | DS-KSM01/B411 |
| Accessory (optional) | |
| Remote | DS-K7R01-433, DS-K7R01-868, DS-K7R05-433, DS-K7R05-868 |
| Remote control pad | DS-K7R83X |
| Base | DS-KSM01/B411 |
| Other | DS-K7B01, DS-KSD24-M, DS-KSD24-P |
Know before you buy
Quick answers about the DS-K3B411BX Series, and how it compares.
How do people get through?
By card (the M pedestals have a Mifare reader), by face with a Hikvision face terminal on the Pg pedestals (bought separately), or by QR code. The access controller is built in and stores 500,000 cards.
Which pedestals do I need?
One L (left end) and one R (right end) for the first lane, then one M (middle) for every extra lane: 1 lane = L + R, 2 lanes = L + M + R, 3 lanes = L + M + M + R.
How wide can the lane be?
Hikvision configures this series for 650, 750, 900 or 1100 mm lanes; 650 mm is the recommended width. Tell us your lane width and we confirm the set.
How does it stop tailgating?
6 pairs of IR detectors check each passage. If a person is let in but does not pass in time, the valid passing duration cancels the permission.
What happens in a fire alarm or power cut?
The barrier opens automatically in both cases, so people can leave.
What if the wing touches someone?
When it detects an obstruction while opening or closing, the barrier stops for a while. It also runs self-diagnostics and raises an alarm on faults.
Can it go outdoors?
Yes. Hikvision rates it for indoor and outdoor use, -20 to 65 °C. Clean the stainless steel every month (every week near the sea or chemical plants).
How many people can pass per minute?
20 to 60 persons per minute, depending on how fast people authenticate and walk through.
Can I buy it online?
Turnstiles are installed products, so we start with a free pre-sales consultation: our engineers survey the entrance, suggest the version and terminals, and send a quote. Use Request a Quote on this page, contact us or WhatsApp +92 300 ESCO 301. Offices in Karachi, Lahore, Islamabad and Rawalpindi.
