Key specs
- 32-inch Full HD monitor
- 1920 × 1080, Typical 60 Hz, Max 75 Hz
- 300 cd/m², 4000:1 contrast
- Response time 8 ms
- Inputs: VGA, HDMI 1.4, Audio Output
- Speakers 8Ω 10W × 2
- Rated for 7 × 24 h operation
- Stand included, VESA 100 × 100 mm
- ≤ 48 W, 4.55 ±0.5 kg
| Display | |
|---|---|
| Screen Size | 32 inch |
| Active Display Area | 698.4 mm (H) × 392.85 mm (V) |
| Resolution | 1920 × 1080 |
| Backlight | D-LED |
| Pixel Pitch | 0.12125 mm (H) × 0.36375 mm (V) |
| Brightness | 300 cd/m² |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Depth | 8 bit |
| Contrast Ratio | 4000:1 |
| Response Time | 8 ms |
| Refresh Rate | Typical 60 Hz, Max 75 Hz |
| Haze | 2% |
| Reliability | 7 × 24 H |
| Color Gamut | 72% NTSC |
| Interface | |
| Video & Audio Input | VGA × 1, HDMI 1.4 × 1, Audio Output × 1 |
| Video & Audio Output | Speaker (8Ω 10W) × 2 |
| Data Transmission Interface | None |
| Control Interface | None |
| Physical Interfaces | POWER: AC power input; HDMI: HDMI 1.4 digital signal input; VGA: analog signal input; AUDIO OUT: 3.5 mm audio output |
| Power | |
| Power Supply | 100 to 240 VAC, 50/60 Hz |
| Power Consumption | ≤ 48 W |
| Standby Consumption | ≤ 0.5 W |
| Working Environment | |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Operating Humidity | 20% to 90% RH (non-condensing) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Storage Humidity | 10% to 90% RH (non-condensing) |
| General | |
| Speaker | 8Ω 10W × 2 |
| Casing Material | Plastic |
| VESA | 100 mm × 100 mm (4 × M6 × 10 mm) |
| Bezel Width | 16.7 mm (top/left/right), 20.5 mm (bottom) |
| Product Dimensions (with base, W × H × D) | 735.08 × 489.16 × 207.95 mm |
| Product Dimensions (without base, W × H × D) | 735.08 × 433.46 × 80.19 mm |
| Standby Time | 600 s |
| Package Dimensions (W × H × D) | 808 × 510 × 140 mm |
| Net Weight | 4.55 ± 0.5 kg |
| Gross Weight | 6.1 ± 0.5 kg |
| Packing List | |
| Contents | Monitor × 1, Base component × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1, Remote control × 1, Base screws × 6, Wall-mount screws × 4 |
| Remarks | Base is included by default |
Questions & answers
Know before you buy
Quick answers about the DS-D5032F3-1V0S, and how it compares.
Can it run 24/7?
Yes. Hikvision rates it for 7 × 24 h operation.
Can I connect it to my NVR or DVR?
Yes. Connect the HDMI output of the NVR or DVR to the monitor (an HDMI cable is in the box).
Can it be wall-mounted?
Yes. It takes a VESA 100 × 100 mm wall mount such as DS-DM1940W. The table stand is in the box too.
Does it have speakers?
Yes, built-in speakers: 8Ω 10W × 2.
Can I buy it online?
Monitors and their mounts are installed products, so we start with a free pre-sales consultation: our engineers confirm the right models and quantities for your site and send a quote. Use Request a Quote on this page, contact us or WhatsApp +92 300 ESCO 301. Offices in Karachi, Lahore, Islamabad and Rawalpindi.
