Out of stock
Key specs
- 4-port LED controller (DT60P, built-in Android 12)
- Inputs: 2 × HDMI 1.4, 1 × built-in Android
- Load up to 2.6 MP, 0.65 MP per network port
- Android 12 with 4 GB memory, 32 GB storage
- 1U rack chassis
- Average consumption ≤16.5 W
| Product | |
|---|---|
| Model | DS-DT60P-02HI04NO |
| Product Type | LED controller |
| Processing Performance | |
| Brightness Control | 1 to 100 tunable (level-by-level white balance) |
| Input Frame Rate | 25 Hz to 60 Hz |
| Grey Level | 256 |
| Display Color | 16 MP |
| Processing Depth | 8 bit |
| Image Scaling | Supported |
| Chassis | |
| Chassis Height | 1 U |
| Chassis Width | Half-width |
| Sending Card Interface | |
| Light Sensor Port | Not supported |
| LED Controller Power | |
| Average Consumption | ≤16.5 W |
| Power Interface Quantity | 1 |
| Power Interface | 100 to 240 VAC, 50/60 Hz |
| Interface | |
| USB Interface | 1 channel USB 2.0 + 1 channel USB 3.0 |
| Network | |
| Control Network Port | 2 × 10/100/1000 Mbps auto-sensing Ethernet (RJ-45), connects to external network |
| Video Wall | |
| Open Windows | 3 signal source + 2 image + 1 scrolling text + 1 background window |
| Layers per Device | 7 |
| Scenes | 10 |
| Background Images | 1 |
| Background Resolution | Min. 640 × 480, Max. 1920 × 1200 |
| Background Format | JPG/JPEG |
| Subtitles | 1 |
| Subtitle Width | 32760 |
| Subtitle Font | Supports Xiaomi font and custom font |
| Audio Input | |
| Audio Input Interfaces | 3 |
| Audio Input Interface Type | 2 HDMI 1.4 + 1 embedded Android |
| Video Input | |
| Video Input Interfaces | 3 |
| Video Input Interface Type | 2 HDMI 1.4 + 1 embedded Android |
| Max. Video Input Resolution | 1080P |
| HDMI 1.4 Max. Resolution | 1920 × 1200@60 Hz |
| HDMI 1.4 Min. Resolution | 320 × 180@60 Hz |
| HDMI 1.4 Custom Resolution | Total ≤ 2.6 MP@60 Hz; max. width 144 to 4096 (2 alignment); max. height 144 to 4096 (1 alignment) |
| HDCP | 1.4; interlaced signal input not supported |
| Embedded Android Resolution | Max. 1920 × 1200@60 Hz; Min. 320 × 180@60 Hz; custom total ≤ 2.6 MP@60 Hz |
| Video Input Processing Feature | |
| Processing Depth | 8 bit |
| Sampling Format | RGB 444; YUV 444; YUV 422 |
| Video Output | |
| Max. Video Output Resolution | 2600000 |
| Loading Capacity for Video Output to LED | Single port load 650000; width 144 to 5120; height 64 to 5120; width multiple of 2, height multiple of 1 |
| LED Loading Interfaces | 4 |
| LED Loading Interface Type | RJ-45 |
| Loading Mode | Mini loading: single port load 650000; Standard loading: single port load 2925000 (ports 1 and 2 only) |
| Video Live View Output | |
| Interfaces | 1 |
| Interface Type | HDMI 1.4 |
| Resolution | 720p@60 Hz |
| Audio Output | |
| Audio Output Interfaces | 1 |
| Audio Output Interface | 3.5 mm audio output |
| System | |
| System | Android 12 |
| Memory Capacity | 4 GB |
| Storage Capacity | 32 GB |
| CPU | 4-core 64-bit ARM Cortex-A55, 2.0 GHz |
| Wireless | |
| Wi-Fi | 2.4 GHz |
| Bluetooth | Bluetooth 4.0 |
| Antenna | 1 × bar antenna |
| Remote Control | IR remote control supported |
| Device Parameters | |
| Button | +: increase brightness; -: decrease brightness; Source: change signal source |
| Power Switch | Button switch |
| Serial Interface | |
| Ports | 1 × debugging serial port (4-pin connector) + 1 × RS-485 central control serial port (green Phoenix contact) |
| Baud Rate | 115200 |
| Data Bit | 8 |
| Broadcast Control | |
| WonderCast Client | Supported |
| File Format | Video, image, webpage, document, clock, text, background music |
| Video Playback | |
| Performance | 1-channel 4096 × 2160@60 Hz; 4-channel 1920 × 1080@60 Hz; 6-channel 1280 × 720@60 Hz |
| Front Panel | |
| Screen | 128 × 64, OLED screen |
| Indicators | Active (device running), Source (signal accessed), Error (operation exception) |
| Power Switch | On (started and running); Off (not powered or not started) |
| Control Interface | |
| IR Input | 1 × 3.5 mm connector |
| General | |
| Working Temperature | -10°C to 50°C |
| Working Humidity | 10% to 90% |
| Dimensions (W × H × D) | 210 mm × 42 mm × 180 mm (8.26 in × 1.65 in × 7.08 in) |
| Net Weight | 1.03 kg |
| Packing List | |
| Contents | 1 × AC power cord, 1 × connecting bracket, 1 × mounting bracket, 1 × RS-485 green Phoenix contact for central control device, 1 × regulatory compliance and safety information manual, 1 × bar antenna, 1 × RF remote control |
Questions & answers
Know before you buy
Quick answers about the DS-DT60P-02HI04NO, and how it compares.
How big a screen can it drive?
Up to 2.6 MP in total (4 ports × 0.65 MP per port). For example, a P2.5 screen of 1280 × 768 pixels (3.2 m × 1.92 m) is 0.98 MP and uses 2 ports.
What inputs does it take?
2 × HDMI 1.4, 1 × built-in Android.
Can it play content without a PC?
Yes. The built-in Android 12 player plays programs from a USB drive.
Can I cast from a laptop or phone?
Yes, with the WonderCast application (Hikvision).
