Camera
|
|
Sensor
|
1/1.8"
Progressive Scan CMOS
|
|
Max.
Resolution
|
2688
× 1520
|
|
Min.
Illumination
|
Color:
0.0005 Lux @ (F1.2, AGC ON);
B/W:
0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
|
|
Shutter
Time
|
1 s
to 1/100,000 s
|
|
Day
& Night
|
IR
cut filter
Blue
glass module to reduce ghost phenomenon
|
|
Lens
|
|
Focal
Length & FOV
|
2.8
to 12 mm, horizontal FOV: 114.5° to 41.8°, vertical FOV: 59.3° to 23.6°,
diagonal FOV: 141.1° to 48°
|
|
Focus
|
Auto,
semi-auto, manual
|
|
Iris
Type
|
P-iris
|
|
Aperture
|
2.8
to 12 mm: F1.2 to F2.5
|
|
DORI
|
|
DORI
|
Wide:
2.8
to 12 mm: D: 60 m, O: 23.8 m, R: 12 m, I: 6 m
Tele:
2.8
to 12 mm: D: 149 m, O: 59.1 m, R: 29.8 m, I: 14.9 m
|
|
Illuminator
|
|
Supplement
Light Type
|
IR
|
|
Supplement
Light Range
|
2.8
to 12 mm: 50 m
|
|
Smart
Supplement Light
|
Yes
|
|
IR Wavelength
|
850
nm
|
|
Video
|
|
Main
Stream
|
50
Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
60
Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50
Hz: 25 fps (704 × 576, 640 × 480)
60
Hz: 30 fps (704 × 480, 640 × 480)
|
|
Third
Stream
|
50
Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60
Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
|
|
Fourth
Stream
|
50
Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60
Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
|
|
Fifth
Stream
|
50
Hz: 25 fps (704 × 576, 640 × 480)
60
Hz: 30 fps (704 × 480, 640 × 480)
|
|
Video
Compression
|
Main
stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream:
H.265 / H.264 / MJPEG,
Third
stream: H.265 / H.264,
Fourth
stream: H.265 / H.264 / MJPEG,
Fifth
stream: H.265 / H.264 / MJPEG
|
|
Video
Bit Rate
|
32
Kbps to 8 Mbps
|
|
H.264
Type
|
Baseline
Profile, Main Profile, High Profile
|
|
H.265
Type
|
Main
Profile
|
|
Bit
Rate Control
|
CBR,
VBR
|
|
Scalable
Video Coding (SVC)
|
H.265
and H.264 encoding
|
|
Region
of Interest (ROI)
|
4
fixed regions for each stream
|
|
Target
Cropping
|
Yes
|
|
Network
|
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE,
NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket,
WebSockets
|
|
Security
|
Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for Open
Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security
Audit Log, TLS 1.2
|
|
Network
Storage
|
NAS
(NFS, SMB/CIFS), auto network replenishment (ANR)
Together
with high-end Hikvision memory card, memory card encryption and health
detection are supported
|
|
|
|
Parameters Switch
|
Yes
|
|
Settings
|
Saturation,
brightness, contrast, sharpness, gain, white balance adjustable by client
software or web browser
|
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule, Alarm Trigger, Video Trigger
|
|
Wide
Dynamic Range (WDR)
|
140
dB
|
|
SNR
|
≥ 52 dB
|
|
Enhancement
|
BLC,
HLC, Defog, 3D DNR
|
|
Overlay
|
LOGO
picture can be overlaid on video with 128 × 128 24bit bmp format
|
|
Stabilization
|
EIS
|
|
Interface
|
|
Video
Output
|
1
Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
|
|
Ethernet
Interface
|
1
RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
|
|
On-Board
Storage
|
Built-in
memory card slot, support microSD / microSDHC / microSDXC card, up to 1 TB
|
|
Alarm
|
2
input, 2 outputs (max. 24 VDC, 1 A)
|
|
Reset
Key
|
Yes
|
|
Event
|
|
Basic
Event
|
Motion
detection, video tampering alarm, exception (network disconnected, IP address
conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality
diagnosis, vibration detection
|
|
Smart
Event
|
Line
crossing detection, intrusion detection, region entrance detection, region
exiting detection, audio exception detection, scene change detection, defocus
detection
|
|
Linkage
|
Upload
to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm
output, trigger recording, trigger capture, audible warning
|
|
Deep Learning Function
|
|
Perimeter
Protection
|
Line
crossing, intrusion, region entrance, region exiting
Support
alarm triggering by specified target types
|
|
Road
Traffic and Vehicle Detection
|
Blocklist
and allowlist: up to 10,000 records
Support
license plate recognition of motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand,
etc. (City Street mode is recommended.)
License
plate recognition rate ≥98%
|
|
General
|
|
Power
|
12
VDC ± 20%, 1.19 A, max. 14.28 W, three-core terminal block
PoE:
802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.396 A to 0. 295 A, max. 16.8 W
|
|
Material
|
Aluminum
alloy body
|
|
Dimension
|
Without
-Y: Ø144 × 347 mm (Ø5.7" × 13.7")
With
-Y: Ø140 × 351 mm (Ø5.5" × 13.8")
|
|
Package
Dimension
|
405
× 190 × 180 mm (15.9" × 7.5" × 7.1")
|
|
Weight
|
Approx.
1950 g (4.2 lb.)
|
|
With
Package Weight
|
Approx.
3070 g (6.7 lb.)
|
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
General
Function
|
Anti-flicker,
5 streams, EPTZ, heartbeat, mirror, privacy mask, flash log, password reset via
email, pixel counter
|
|
Heater
|
Yes
|
|
Approval
|
|
EMC
|
FCC
(47 CFR Part 15, Subpart B);
CE-EMC
(EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN
50130-4:
2011 +A1: 2014);
RCM
(AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7);
KC
(KN 32: 2015, KN 35: 2015)
|
|
Safety
|
UL
(UL 62368-1);
CB
(IEC 62368-1:2014+A11);
CE-LVD
(EN 62368-1:2014/A11:2017);
BIS
(IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1)
|
|
Environment
|
CE-RoHS
(2011/65/EU); WEEE (2012/19/EU);
Reach
(Regulation (EC) No 1907/2006)
|
|
Anti-Corrosion
Protection
|
With
-Y: NEMA 4X(NEMA 250-2018)
|
|
Protection
|
IK10
(IEC 62262:2002), IP67 (IEC 60529-2013)
|
