Camera
|
|
Image Sensor
|
1/1.8" Progressive Scan CMOS
|
|
Max. Resolution
|
2688 × 1520
|
|
Min. Illumination
|
Color: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR
|
|
Shutter Time
|
1 s to 1/100,000 s
|
|
Day & Night
|
IR cut filter,
Blue glass module (less ghost phenomenon)
|
|
Lens
|
|
Focal Length & FOV
|
2.8 to 12 mm, horizontal FOV 106° to 41.8°, vertical FOV 55.4° to 23.6°, diagonal FOV 130° to 48.1°
|
|
Focus
|
Auto, Semi-auto, Manual
|
|
Iris Type
|
P-iris
|
|
Aperture
|
2.8 to 12 mm: F1.38 to F2.53
|
|
DORI
|
|
DORI
|
Wide:
2.8 to 12 mm: D (Detect): 60 m, O (Observe): 23.8 m, R (Recognize): 12 m, I (Identify): 6 m
The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard.
|
|
Illuminator
|
|
Supplement Light Type
|
IR
|
|
Supplement Light Range
|
2.8 to 12 mm: Monitoring: 60 m
|
|
Smart Supplement Light
|
Yes
|
|
IR Wavelength
|
850 nm
|
|
Video
|
|
Main Stream
|
Monitoring mode:
50 Hz: up to 50 fps (2688 × 1520, 1280 × 720), up to 100 fps (1920 × 1080)
60 Hz: up to 60 fps (2688 × 1520, 1280 × 720), up to 120 fps (1920 × 1080)
*High frame rate is supported under monitoring mode only. smart mode:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480)
|
|
Third Stream
|
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
|
|
Fourth Stream
|
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
|
|
Fifth Stream
|
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
|
|
Video Compression
|
Main stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream: H.265 / H.264 / MJPEG,
Third stream: H.265 / H.264,
Fourth stream: H.265 / H.264 / MJPEG,
Fifth stream: H.265 / H.264 / MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile, Main Profile, High Profile
|
|
H.265 Type
|
Main Profile
|
|
Bit Rate Control
|
CBR, VBR
|
|
Scalable Video Coding (SVC)
|
H.264 & H.265 encoding
|
|
Region of Interest (ROI)
|
4 fixed regions for each stream
|
|
Target Cropping
|
Yes
|
|
e-PTZ
|
Support Patrol and Auto Tracking settings
|
|
Network
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets
|
|
User/Host
|
Up to 32 users
3 user levels: administrator, operator, and user
|
|
Security
|
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256
|
|
Network Storage
|
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
|
|
|
|
Image Parameters Switch
|
Yes
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule, Alarm Trigger
|
|
Wide Dynamic Range (WDR)
|
150 dB
|
|
Image Enhancement
|
BLC, HLC, 3D DNR, Distortion Correction, Defog
|
|
SNR
|
≥ 52 dB
|
|
Privacy Mask
|
8 programmable polygon privacy masks
|
|
Picture Overlay
|
LOGO picture can be overlaid on video with 128 × 128 24-bit bmp format.
|
|
Image Stabilization
|
EIS
|
|
Interface
|
|
Video Output
|
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
|
|
On-Board Storage
|
Built-in memory card slot, support microSD / microSDHC / microSDXC card, up to 1 TB
|
|
Alarm
|
2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
|
|
Audio
|
1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
|
|
Event
|
|
Basic Event
|
Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, video quality diagnosis, exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error), vibration detection
|
|
Smart Event
|
scene change detection, audio exception detection, defocus detection
|
|
Linkage
|
Upload to FTP / NAS / memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning
|
|
Deep Learning Function
|
|
Multi-target-type Detection
|
Supports simultaneous detection and capture of human body, face, and vehicle, Gets 7 face features,
Gets 13 human body features, Gets 2 vehicle features,
Supports counting the number of line crossing targets by type, including human body, non-motor vehicle, motor vehicle,
Supports dynamic mosaic mask
|
|
Face Capture
|
Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second,
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°, Uploads face with background and closed-up face pictures,
Supports best shot and quick shot for capture mode, Supports dynamic mosaic mask,
Gets 7 face features
|
|
Face Comparison
|
Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total, Supports face library encryption
|
|
People Counting
|
Supports Multi-Dimension People Counting,
Supports counting, displaying and exporting the people flow data of entering, exiting and passing by (The data is stored in the flash.),
Supports real-time uploading and uploading by statistic cycle, Supports generating daily, weekly, monthly or annually reports,
Supports dynamic deduplication based on face picture comparison, and can filter out the target with the same custom face pictures, same attributes, or filter out repeated invalid targets within the set time interval,
Supports face feature deduplication, supports people flow data replenishment
|
|
Queue Management
|
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: regional people queuing-up, waiting time detection Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue
Supports raw data export for further analysis
Supports real-time data uploading and scheduled data uploading
Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold Waiting time detection: supports 1 alarm trigger condition, including greater than threshold
|
|
Heat Map
|
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area.,
Two report types are available, space heat map and time heat map line chart.
|
|
Perimeter Protection
|
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle) Support combined event alarm triggering
|
|
Hard Hat Detection
|
Detects up to 30 human targets simultaneously Supports up to 4 shield regions
|
|
Metadata
|
Intrusion detection, line crossing detection, region entrance detection, region exiting detection, face capture, multi-target-type detection
|
|
Regional People Counting
|
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 3 detection modes: people density detection, number of people exception detection, waiting time exception detection
Supports parameter settings: alarm times per exception, alarm interval, first alarm delay
Supports searching real-time number of people
People density detection: supports scheduled uploading, number of people change uploading, congestion level uploading
Number of people exception detection: supports 6 alarm trigger conditions, including greater than threshold A, less than threshold A, equal to threshold A, not equal to threshold A, greater than threshold A and less than threshold B, less than threshold A or greater than threshold B (threshold A should be less than threshold B)
Waiting time exception detection: supports 3 alarm trigger conditions, including greater than threshold A, less than threshold A, greater than threshold A and less than threshold B (threshold A should be less than threshold B)
|
|
On/Off Duty Detection
|
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: absence detection, on/off duty detection Supports parameter settings: person on duty, absence duration
|
|
General
|
|
Material
|
Aluminum alloy body
|
|
Dimension
|
Without -Y: Ø144.1 mm × 374.7 mm (Ø5.7" × 14.8")
|
|
Package Dimension
|
425 mm × 190 mm × 180 mm (16.7" × 7.5" × 7.1")
|
|
Weight
|
Approx. 2170 g (4.78 lb.)
|
|
With Package Weight
|
Without -Y: Approx. 3364 g (7.42 lb.)
|
|
Storage Conditions
|
-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating Conditions
|
-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
|
|
Heater
|
Yes
|
|
Demist
|
Yes
|
|
Approval
|
|
EMC
|
CE-EMC: EN 55032: 2015+A1: 2020, EN 50130-4: 2011+A1: 2014, EN IEC 61000-3-2: 2019+A1: 2021, EN 61000-3-3: 2013+A1: 2019+A2: 2021,
RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
|
|
Safety
|
CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
|
|
Environment
|
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
|
|
Protection
|
IP67: IEC 60529-2013, IK10: IEC 62262:2002
|
|
Other
|
PVC FREE
|
