Camera
|
Image Sensor
|
1/1.7" Progressive Scan CMOS
|
Min. Illumination
|
Color: 0.009 Lux @ (F1.2, AGC ON); B/W: 0.0009
Lux @ (F1.2, AGC ON)
|
Shutter Speed
|
1 s to 1/100,000 s
|
Slow Shutter
|
Yes
|
P/N
|
P/N
|
Wide Dynamic Range
|
Digital WDR
|
Day & Night
|
IR cut filter
|
Power-off Memory
|
Yes
|
Lens
|
Focus
|
Auto, semi-auto, manual
|
Lens Type & FOV
|
2.8 to 12 mm, horizontal FOV: 96.2° to 36.4°,
vertical FOV: 69.3° to 27.2°, diagonal FOV: 129.4° to 45.5°
|
Aperture
|
2.8 to 12 mm: F1.2 to F2.5
|
Lens Mount
|
Integrated
|
Blue Glass Module
|
Blue glass module to reduce ghost phenomenon.
|
P-Iris
|
Yes
|
Illuminator
|
IR Range
|
2.8 to 12 mm: 50 m
|
Wavelength
|
850 nm
|
Smart Supplement Light
|
Yes
|
Video
|
Max. Resolution
|
4000 × 3000
|
Main Stream
|
50Hz: 25fps (4096 × 2160, 3840 × 2160, 3072 ×
1728, 2560 × 1440, 1920 × 1080, 128 x 720)
60Hz: 30fps (4096 × 2160, 3840 × 2160, 3072 ×
1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
50Hz: 20fps (4000 × 3000)
60Hz: 20fps (4000 × 3000)
|
Sub-Stream
|
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
|
Third Stream
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576,
640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480,
640 × 480)
|
Fourth Stream
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576,
640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480,
640 × 480)
|
Fifth Stream
|
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
|
Custom Stream
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576,
640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480,
640 × 480)
|
Video Compression
|
Main stream: H.265+ / H.265 / H.264+ /
H.264
Sub-stream / Third stream / Fourth stream / Fifth
stream / custom stream: H.265 / H.264 / MJPEG
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
H.264 Type
|
Baseline Profile / Main Profile / High Profile
|
H.265 Type
|
Main Profile
|
H.264+
|
Main Stream supports
|
H.265+
|
Main Stream supports
|
Bit Rate Control
|
CBR/VBR
|
Stream Type
|
Main stream / Sub-stream / third stream / fourth
stream / fifth stream / custom stream
|
Scalable Video Coding (SVC)
|
H.265 and H.264 support
|
Region of Interest (ROI)
|
4 fixed regions for each stream
|
Network
|
Simultaneous Live View
|
Up to 20 channels
|
API
|
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI,
SDK, ISUP
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP,
DNS, DDNS, RTP, RTSP, RTCP,
PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS,
IPv6, UDP, Bonjour, SSL/TLS
|
Smooth Streaming
|
Yes
|
User/Host
|
Up to 32 users. 3 user levels: administrator,
operator and user
|
Security
|
Password protection, complicated password, HTTPS
encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP
address filter, basic and digest authentication for HTTP/HTTPS, WSSE and
digest authentication for ONVIF, RTP/RTSP
OVER HTTPS, Control Timeout Settings, Security
Audit Log, TLS 1.2
|
Network Storage
|
microSD / SDHC / SDXC card (256 GB) local
storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card,
memory card encryption and health detection is supported.
|
|
Smart IR
|
The IR LEDs on camera should support Smart IR
function to automatically adjust power to avoid image overexposure.
|
Day/Night Switch
|
Day, Night, Auto, Schedule, Triggered by Alarm In
|
Target Cropping
|
Yes
|
Picture Overlay
|
LOGO picture can be overlaid on video with 128 ×
128 24bit bmp format
|
Image Enhancement
|
BLC, HLC, 3D DNR, Defog, EIS, Distortion
Correction
|
Image Parameters Switch
|
Yes
|
Image Settings
|
Saturation, brightness, contrast, sharpness,
gain, white balance adjustable by client software or web browser
|
SNR
|
≥52dB
|
Interface
|
Alarm
|
2 input, 2 outputs (max. 24 VDC, 1 A)
|
On-board Storage
|
Built-in micro-SD / SDHC / SDXC slot, up to 256
GB
|
Hardware Reset
|
Yes
|
Communication Interface
|
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet
port
|
Heater
|
Yes
|
Smart Feature-Set
|
Basic Event
|
Motion detection, video tampering alarm,
vibration detection, exception (network disconnected, IP address conflict,
illegal login, HDD full, HDD error)
|
Smart Event
|
Line crossing detection, up to 4 lines
configurable Intrusion detection, up to 4 regions configurable Region
entrance detection, up to 4 regions configurable Region exiting detection, up
to 4 regions configurable
Unattended baggage detection, up to 4 regions
configurable Object removal detection, up to 4 regions configurable
Scene change detection, audio exception
detection, defocus detection
|
Counting
|
Yes
|
Intelligent (Deep Learning
Algorithm)
|
Face Recognition
|
Detects up to 30 faces simultaneously;
Supports swing left and right from -60° to 60°,
tilt up and down from -30° to 30°; Up to 3 face libraries with up to 30000
faces each are configurable;
Recognizes face identity via face modeling,
grading and comparing to those in face library;
Supports face library encryption.
|
Multi-target-type Detection
|
Supports simultaneous detection of human body and
face
Gets 8 face features and 13 human body features
|
Face Counting
|
Supports entering/exiting counting (track 30
targets simultaneously); Supports facial recognition;
Supports 24-hour dynamic deduplication and face
library deduplication (up to 3 face libraries with up to 30000 faces);
Supports reporting alarms when detecting the face
is the same as that in the face library.
|
Hard Hat Detection
|
Detects up to 30 human targets simultaneously
Supports up to 4 shield regions
|
Queue Management
|
Detects queuing-up people number, and waiting
time of each person
Generates reports to compare the efficiency of
different queuing-ups and display the changing status of one queue
Supports raw data export for further analysis
|
Premier Protection
|
Line crossing, intrusion, region entrance, region
exiting
Support alarm triggering by specified target
types (human and vehicle)
Filtering out mistaken alarm caused by target
types such as leaf, light, animal, and flag, etc.
|
General
|
Linkage Method
|
Upload to FTP / NAS / memory card, notify
surveillance center, send email, trigger alarm output, trigger
recording, Trigger recording: memory card, network storage, pre-record
and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS,
Email Trigger notification: HTTP, ISAPI, alarm output, Email
|
Online Upgrade
|
Yes
|
Dual Backup
|
Yes
|
General Function
|
Anti- flicker, 5 streams and up to 5 custom
streams, EPTZ, heartbeat, mirror, privacy masks, flash log, password reset
via e-mail, pixel counter
|
Software Reset
|
Yes
|
Storage Conditions
|
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95%
or less (non-condensing)
|
Startup and Operating Conditions
|
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95%
or less (non-condensing)
|
Power Supply
|
12 VDC ± 20%, three-core terminal block, reverse
polarity protection; PoE: 802.3at, Type 2 Class 4
|
Power Consumption and Current
|
12 VDC, 1.33 A, max. 16.0 W
PoE: (802.3at, 42.5V-57V), 0.43 A to 0.31 A, max.
18.0 W
|
Power Interface
|
3-core terminal block
|
Camera Material
|
Aluminum alloy body
|
Camera Dimension
|
Without -Y: Ø144 × 347 mm (Ø5.7″ × 13.7″)
With -Y: Ø140 × 351 mm (Ø5.5″ × 13.8″)
|
Package Dimension
|
405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)
|
Camera Weight
|
1920 g (4.2 lb.)
|
With Package Weight
|
3060 g (6.7 lb.) |
Protection
|
IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
|
