Camera |
Sensor | Channel
1: 1/1.8" Progressive Scan CMOS, Channel 2: 1/1.8" Progressive Scan
CMOS |
Max.
Resolution | Channel
1: 2688 1520, channel 2: 2560 1440 |
Min.
Illumination | Channel
1: Color: 0.0005 Lux @ (F1.2, AGC ON),0 Lux with Light, B/W: 0.0001 Lux @
(F1.2, AGC ON),0 Lux with IR, Channel
2: Color: 0.0003 Lux @ (F1.0, AGC ON),0 Lux with Light, B/W: 0.0001 Lux @
(F1.0, AGC ON),0 Lux with IR |
Shutter
Time | 1 s
to 1/100,000 s |
Day
＆ Night | IR
cut filter, Blue
glass module (less ghost phenomenon) |
Angle
Adjustment | Pan:
0 to 355 , tilt: 0 to 90 , rotate: 0 to 360 |
Lens |
Focal
Length ＆ FOV | Channel
1: 8 to 32 mm: Horizontal FOV 42.5 to 15.2 , Vertical FOV: 23.4 to 8.7 , Diagonal
FOV 49.7 to 17.3 Channel
2: 4 mm: Horizontal FOV: 89 , Vertical FOV: 45 , Diagonal FOV: 107 |
Focus | Channel
1: Auto, semi-auto, manual |
Iris
Type | Channel
1: P-iris, Channel 2: Fixed |
Aperture | Channel
1: Constant F1.6 throughout the zoom range, Channel 2: F1.0 |
DORI |
DORI | Channel
1: Wide:
D: 150.3 m, O: 59.7 m, R: 30.1 m, I: 15 m Tele:
D: 400 m, O: 158.7 m, R: 80 m, I: 40 m Channel
2: D:
77 m, O: 30.5 m, R: 15.4 m, I: 7.7 m |
Illuminator |
Supplement
Light Type | Hybrid
(IR and White Light) |
Supplement
Light Range | Channel
1: up to 100 m, Channel
2: up to 30 m |
Smart
Supplement Light | Yes |
IR
Wavelength | 850
nm |
Video |
Main
Stream | Channel
1: 50
Hz: 50 fps (2688 1520, 2560 1440, 1920 1080, 1280 720) 60
Hz: 60 fps (2688 1520, 2560 1440, 1920 1080, 1280 720) Channel
2: 50
Hz: 25 fps (2560 1440, 1920 1080, 1280 720) 60
Hz: 30 fps (2560 1440, 1920 1080, 1280 720) |
Sub-Stream | Channel
1: 50
Hz: 25 fps (704 576, 640 480) 60
Hz: 30 fps (704 480, 640 480) Channel
2: 50
Hz: 25 fps (704 576, 640 480) 60
Hz: 30 fps (704 480, 640 480) |
Third
Stream | Channel
1: 50
Hz: 25 fps (1920 1080, 1280 720, 704 576, 640 480) 60
Hz: 30 fps (1920 1080, 1280 720, 704 480, 640 480) Channel
2: 50
Hz: 25 fps (1920 1080, 1280 720, 704 576, 640 480) 60
Hz: 30 fps (1920 1080, 1280 720, 704 480, 640 480) |
Fourth
Stream | Channel
1: 50
Hz: 25 fps (1920 1080, 1280 720, 704 576, 640 480) 60
Hz: 30 fps (1920 1080, 1280 720, 704 480, 640 480) Channel
2: 50
Hz: 25 fps (704 576, 640 480) 60
Hz: 30 fps (704 480, 640 480) |
Fifth
Stream | Channel
1: 50
Hz: 25 fps (704 576, 640 480) 60
Hz: 30 fps (704 480, 640 480) Channel
2: 50
Hz: 25 fps (704 576, 640 480) 60
Hz: 30 fps (704 480, 640 480) |
Video
Compression | Main
stream: H.265+ / H.265 / H.264+ / H.264, Sub-stream:
H.265 / H.264 / MJPEG, Third
stream: H.265 / H.264, Fourth
stream: H.265 / H.264 / MJPEG, Fifth
stream: H.265/H.264/MJPEG |
Video
Bit Rate | 32
Kbps to 8 Mbps |
H.264
Type | Baseline
Profile, Main Profile, High Profile |
H.265
Type | Main
Profile |
Bit
Rate Control | CBR,
VBR |
Scalable
Video Coding (SVC) | H.264
and H.265 encoding |
Region
of Interest (ROI) | 4
fixed regions for each stream |
Target
Cropping | Yes |
Audio |
Audio
Type | Mono
sound |
Audio
Compression | G.711
/ G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC |
Audio
Bit Rate | 64
Kbps (G.711ulaw/G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 192
Kbps (MP2L2) / 8 to 320 Kbps (MP3) / 16 to 64 Kbps (AAC-LC) |
Audio
Sampling Rate | 8
kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz |
Environment
Noise Filtering | Yes |
Network |
Protocols | TCP/IP,
ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,
UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, WebSocket,
WebSockets |
Security | Password
protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5),watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for Open
Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings,
Security Audit Log, TLS 1.2, TLS 1.3 |
Network
Storage | NAS
(NFS, SMB/CIFS),Auto Network Replenishment (ANR),Together with high-end
Hikvision memory card, memory card encryption and health detection are
supported. |
Image |
Parameters Switch | Yes |
Settings | Saturation,
brightness, contrast, sharpness, AGC, white balance, adjustable by client
software or web browser |
Day/Night
Switch | Channel
1: Day, Night, Auto, Schedule, Alarm Trigger, Video Trigger, Channel 2: Day,
Night, Auto, Schedule, Alarm Trigger |
Wide
Dynamic Range (WDR) | 140
dB |
Enhancement | Channel
1: BLC, HLC, 3D DNR, Defog, EIS, Channel 2: BLC, HLC, 3D DNR, Defog |
Privacy
Mask | 8
programmable polygon privacy masks |
Overlay | LOGO
picture can be overlaid on video with 128 128 24 bit bmp format. |
Interface |
Video
Output | 1
Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) |
Ethernet
Interface | 1
RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
On-Board
Storage | Built-in
memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
Alarm | 2
inputs, 2 outputs (max. 24 VDC, 1 A) |
Audio | 1
input (line in),3.5 mm connector, three-contact, max. input amplitude: 3.3
Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1
output (line out),3.5 mm connector, three-contact, max. output amplitude:
3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono
sound |
RS-485 | 1
RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
Reset
Key | Yes |
Power
Output | 12
VDC, max. 50 mA |
Event |
Basic
Event | Motion
detection, video tampering alarm, network disconnected, IP address conflict, illegal
login, HDD full, HDD error, video quality diagnosis, vibration detection |
Smart
Event | Scene
change detection, audio exception detection, defocus detection |
Linkage | Upload
to FTP / NAS / memory card, notify surveillance center, send email, trigger
alarm output, trigger recording, trigger capture, white light flashing |
Deep Learning Function |
Multi-target-type
Detection | Channel
1: Detects
up to 60 targets simultaneously, Supports
simultaneous detection and capture of human body, face and vehicle, Gets 7
face features, Gets
13 human body features, Gets 2 vehicle features |
Face
Capture | Channel
1: Detects
up to 120 faces simultaneously, Supports
swing left and right from -60 to 60 , tilt up and down from -30 to 30 ,
Uploads face with background and closed-up face pictures |
Face
Comparison | Channel
1: Up
to 10 face libraries. 30,000 faces for each library. 150,000 faces in total.
, Recognizes face identity via face modeling, grading and comparing to those
in face library, Supports face library encryption |
Perimeter
Protection | Channel
1: Line
crossing, intrusion, region entrance, region exiting, Support
alarm triggering by specified target types (human and vehicle), Channel
2: Line
crossing, intrusion, region entrance, region exiting, Support
alarm triggering by specified target types (human and vehicle) |
Road
Traffic and Vehicle Detection | Channel
1, Blocklist
and allowlist: up to 10,000 records Support
license plate recognition of motorcycles (only in checkpoint scenario)
Support vehicle attribute detection, including vehicle type, color, brand,
etc. (City Street mode is recommended.) License
plate recognition rate ≥98% |
General |
Power | Three-core
terminal block, 12
VDC 20%, 1.90 A, max. 22.7 W, 24
VAC 20%, 1.39 A, max. 22.3 W, PoE:
IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.59 A to 0.44 A, max. 24.7 W |
Material | Aluminum
alloy body |
Dimension | 140
mm 410.1 mm ( 5.5" 16.1") |
Package
Dimension | 462
mm 197 mm 195 mm (18.2" 7.76" 7.68") |
Weight | Approx.
2.2 kg (4.85 lb.) |
With
Package Weight | Approx.
3.38 kg (7.45 lb.) |
Storage
Conditions | -40
C to 60 C (-40 F to 140 F). Humidity 95% or less (non-condensing) |
Startup
and Operating Conditions | With
-H: -40 C to 60 C (-40 F to 140 F). Humidity 95% or less
(non-condensing),Without -H: -30 C to 60 C (-22 F to 140 F). Humidity
95% or less (non-condensing) |
General
Function | Heartbeat,
one-key reset, mirror, password protection, flash log, anti-banding |
Heater | Yes |
Demist | Yes |
Approval |
EMC | FCC:
47 CFR Part 15, Subpart B, CE-EMC:
EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:
2011 +A1: 2014, RCM:
AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 |
Safety | UL:
UL 62368-1, CB:
IEC 62368-1: 2014+A11, CE-LVD:
EN 62368-1: 2014/A11: 2017, LOA:
IEC/EN 60950-1 |
Environment | CE-RoHS:
2011/65/EU, WEEE: 2012/19/EU, Reach:
Regulation (EC) No 1907/2006 |
Protection | IP67:
IEC 60529-2013, IK10: IEC 62262:2002 |
Anti-Corrosion
Protection | -Y
model: NEMA 4X (NEMA 250-2018) |
Automotive
and Railway | EN50121-4 |
Other | PVC
FREE |
