iDS-7204HUHI-M1/X

Facial Recognition

Face Picture Library

Up to 16 face picture libraries

Face Picture Comparison

Face picture comparison, face picture search;

2-ch face picture comparison alarm (HD analog camera)

Perimeter Protection

Human/Vehicle Analysis

Up to 4-ch

Recording

Video Compression

H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264

Encoding Resolution

Main stream:

8 MP@8 fps / 5 MP@12 fps / 4 MP@15 fps / 3 MP@18 fps 1080p / 720p / WD1 @25 fps (P)/30 fps (N)

*: 8 MP@8 fps is only available for channel 1. Sub-stream:

WD1 / 4CIF / CIF @ 25 fps (P)/30 fps (N)

Video Bitrate

32 Kbps to 10 Mbps

Dual-stream

Support main stream or sub stream

Stream Type

Video, Video & Audio

Audio Compression

G.711u

Audio Bitrate

64 Kbps

Video and Audio

IP Video Input

2-ch (up to 6-ch)

Up to 8 MP resolution IP enhanced mode on:

4-ch (up to 8-ch), each up to 4 Mbps

Support H.265+ / H.265 / H.264+ / H.264 IP cameras

Analog Video Input

4-ch

BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDMI Output

1-ch, 2K (2560 × 1440)/60Hz,

1920 × 1080/60Hz,

1280 × 1024/60Hz,

1280 × 720/60Hz

HDMI/VGA simultaneous output

VGA Output

1-ch, 1920 × 1080/60Hz,

1280 × 1024/60Hz,

1280 × 720/60Hz

HDMI/VGA simultaneous output

CVBS Input

PAL/NTSC

CVBS Output

1-ch, BNC (1.0 Vp-p, 75 Ω),

resolution: PAL: 704 × 576, NTSC: 704 × 480

Synchronous Playback

4-ch

HDTVI Input

8MP (3840 × 2160)@15 fps, 8MP (3840 × 2160)@12 fps, 3K (2960 x 1665)@20 fps, 5MP (2560 × 1944)@20 fps, 5MP (2560 × 1944)@12 fps, 4MP (2560 × 1440)@30 fps, 4MP (2560 × 1440)@25 fps, 3MP@18 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@ 25 fps

AHD Input

5MP (2560 × 1944)@20 fps, 5MP (2560 × 1944)@12 fps, 4MP (2560 × 1440)@30 fps, 4MP (2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps

HDCVI Input

8MP (3840 × 2160) @15 fps, 8MP (3840 × 2160) @12 fps, 5MP (2592 × 1944) @20 fps, 4MP (2560 × 1440) @30 fps, 4MP (2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps

Audio Output

1-ch, RCA (Linear, 1 KΩ)

Audio Input

1-ch, RCA (2.0 Vp-p, 1 KΩ)，4-ch via coaxial cable

Two-Way Audio

1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)

Network

Total Bandwidth

96 Mbps

Network Protocol

TCP/IP,  PPPoE, DHCP,  Hik-Connect, DNS, DDNS, NTP,  SADP,  NFS, iSCSI, UPnP™,  HTTPS, ONVIF

Remote Connection

32

Network Interface

1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface

SATA

1 SATA interface

Capacity

up to 10 TB capacity for each disk

Serial Interface

RS-485 (half-duplex)

USB Interface

Front panel: 1 × USB 2.0;

Rear panel: 1 × USB 2.0

Alarm In/Out

N/A

General

Power Supply

12 VDC, 1.5 A

Consumption

≤ 10 W

Working Temperature

-10 °C to 55 °C (14 °F to 131 °F)

Working Humidity

10% to 90%

Dimension (W × D × H)

315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)

Weight

≤ 1.16 kg (2.6 lb)
