Facial Recognition
|
|
Face
Picture Library
|
Up
to 16 face picture libraries;
HDD
damage will not cause data loss in the face picture library, because the
library has been backed up by HDD and flash.
|
|
Face
Picture Comparison
|
4-ch
face picture comparison alarm (HD analog camera)
|
|
Perimeter Protection
|
|
Human/Vehicle
Analysis
|
Up
to 8-ch (advanced model)
|
|
Facial Detection
|
|
Facial
Detection and Capture
|
Face
picture detection, face picture search, 4-ch face picture capture
|
|
Recording
|
|
Video
Compression
|
H.265
Pro+ / H.265 Pro / H.265 / H.264+ / H.264
|
|
Encoding
Resolution
|
8MP
/ 5MP / 3K / 4MP / 3MP / 1080p / 720
|
|
Frame
Rate
|
Main
stream:
8MP@8fps
/ 3K@12fps / 5MP@12 fps / 4MP@15 fps / 8MP Lite@15 fps / 3MP@18 fps; 1080p/720p
@25 fps (P)/30 fps (N)
|
|
Video
Bitrate
|
32
Kbps to 10 Mbps
|
|
Dual-stream
|
Support
|
|
Stream
Type
|
Video,
Video & Audio
|
|
Audio
Compression
|
G.711u
|
|
Audio
Bitrate
|
64
Kbps
|
|
Video and Audio
|
|
IP
Video Input
|
8-ch
(up to 16-ch), each up to 4 Mbps
Support
H.265+ / H.265 / H.264+ / H.264 IP cameras
|
|
Analog
Video Input
|
8-ch
BNC
interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
|
|
HDMI
Output
|
1-ch,
4K (3840 × 2160)/30Hz,
2K
(2560 × 1440)/60Hz,
1920
× 1080/60Hz,
1280
× 1024/60Hz,
1280
× 720/60Hz
HDMI/VGA
simultaneous output
|
|
VGA
Output
|
1-ch,
1920 × 1080/60Hz,
1280
× 1024/60Hz,
1280
× 720/60Hz
HDMI/VGA
simultaneous output
|
|
CVBS
Input
|
PAL/NTSC
|
|
CVBS
Output
|
1-ch,
BNC (1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576, NTSC: 704 × 480
|
|
Synchronous
Playback
|
8-ch
|
|
HDTVI
Input
|
8MP
(3840 × 2160)@15 fps, 8MP (3840 × 2160)@12 fps, 3K(2960 x 1665)@20 fps, 5MP (2560
× 1944)@20 fps, 5MP(2560 × 1944)@12 fps, 4MP (2560 × 1440)@30 fps, 4MP (2560
× 1440)@25 fps, 1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps
|
|
AHD
Input
|
5MP
(2560 × 1944)@20 fps, 5MP (2560 × 1944)@12 fps, 4MP (2560 × 1440)@30 fps, 4MP
(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
|
|
HDCVI
Input
|
8MP
(3840 × 2160)@15 fps, 8MP (3840 × 2160)@12 fps, 5M (2880 × 1620)@25 fps, 5MP (2592
× 1944)@20 fps, 4MP (2560 × 1440)@30 fps, 4MP(2560 × 1440)@25 fps, 1080p@30
fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
|
|
Audio
Output
|
1-ch,
RCA (Linear, 1 KΩ)
|
|
Audio
Input
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ)，8-ch via coaxial cable
|
|
Two-Way
Audio
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
|
|
Decoding
|
|
Decoding
Capability
|
up
to 24-ch 1080P@30fps
|
|
Network
|
|
Total
Bandwidth
|
256
Mbps
|
|
Network
Protocol
|
TCP/IP,
PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF,
ISUP
|
|
Remote
Connection
|
64
|
|
Network
Interface
|
1,
RJ45 10M/100M/1000M self-adaptive Ethernet interface
|
|
Auxiliary Interface
|
|
SATA
|
1
SATA interface
|
|
Capacity
|
up
to 12 TB capacity for each disk
|
|
Serial
Interface
|
RS-485
(half-duplex)
|
|
USB
Interface
|
Front
panel: 1 × USB 2.0; Rear panel: 2 × USB 3.0
|
|
General
|
|
Power
Supply
|
12
VDC, 2 A
|
|
Consumption
|
≤ 24 W
|
|
Working
Temperature
|
-10
°C to 55 °C (14 °F to 131 °F)
|
|
Working
Humidity
|
10%
to 90%
|
|
Dimension
(W × D × H)
|
320
× 240 × 48 mm (12.6 × 9.4 × 1.9 inch)
|
|
Weight
|
≤ 2 kg (4.4 lb)
|
