Facial Recognition
|
Face
Picture Library
|
Up to 16 face picture libraries; HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash
|
Face
Picture Comparison
|
Face picture comparison, face picture search (4-ch face picture comparison alarm for HD analog camera)
|
Motion Detection 2.0
|
Human/Vehicle
Analysis
|
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
|
Perimeter Protection
|
Human/Vehicle
Analysis
|
Up to 8-ch (advanced model)
Note:
Face picture comparison, motion detection 2.0 and perimeter protection cannot
be enabled at the same time. Enable one function will make the other two
unavailable.
|
Recording
|
Video
Compression
|
H.265
Pro+ / H.265 Pro / H.265 / H.264+ / H.264
|
Encoding
Resolution
|
When
1080p Lite mode is not enabled:
3K
lite/5 MP lite/4 MP lite/1080p
When
1080p Lite mode is enabled:
3K
lite/5 MP lite/4 MP lite/1080p lite/720p lite
|
Frame
Rate
|
Main stream: When 1080p Lite mode not enabled: For 3K stream access: 3K lite@12fps;4 MP lite@15fps/1080p Lite@20fps;720p @20fps For 5 MP stream access: 5 MP lite@12fps, 4MP lite@15fps/1080pLite@20fps; 720p @20fps For 4 MP stream access: 4 MP lite@15fps / 1080pLite@25fps (P)/30fps For 1080p stream access: 1080p / 720p @15fps; VGA @25fps (P)/30fps (N) For 720p stream access: 720p / VGA @25fps (P)/30fps (N) When 1080p Lite mode enabled: 3K lite / 5MP lite @ 12fps; 4MP lite@ 15fps, 1080p lite/720p lite/VGA @25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
|
Video
Bitrate
|
32
Kbps to 6 Mbps
|
Dual-stream
|
Support
main stream or sub stream
|
Stream
Type
|
Video,
Video & Audio
|
Audio
Compression
|
G.711u
|
Audio
Bitrate
|
64
Kbps
|
Video and Audio
|
IP
Video Input
|
8-ch (up to 24-ch), each up to 4 Mbps Up to 6 MP resolution
Support
H.265+ / H.265 / H.264+ / H.264 IP cameras
|
Analog
Video Input
|
16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
|
HDTVI
Input
|
3K (2960 x 1665) @20 fps, 5MP (2560 × 1944) @20 fps, 4MP (2560 × 1440) @30 fps, 4MP (2560 × 1440) @25 fps,1080p @30 fps, 1080p @25 fps, 720p @30 fps, 720p@25 fps
|
HDMI
Output
|
1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
|
VGA
Output
|
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
|
CVBS
Output
|
1-ch,
BNC (1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576, NTSC: 704 × 480
|
Audio
Input
|
1-ch (up to 16-ch is optional), RCA (2.0 Vp-p, 1 KΩ) 16-ch via coaxial cable
|
Audio
Output
|
1-ch, RCA (Linear, 1 KΩ)
|
Two-Way
Audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
|
Synchronous
playback
|
16-ch
|
Network
|
Remote
Connection
|
128
|
Total
Bandwidth
|
256 Mbps
|
Network
Protocol
|
TCP/IP,
PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
Network
Interface
|
1,
RJ45 10/100 Mbps self-adaptive Ethernet interface
|
Wi-Fi
|
Connectable
to Wi-Fi network by Wi-Fi dongle through USB interface
|
Auxiliary Interface
|
Serial
Interface
|
RS-485
(half-duplex)
|
SATA
|
1
SATA interface, up to 12 TB capacity for each disk
|
Alarm
In/Out
|
N/A
(optional to support)
|
USB
Interface
|
Front
panel: 1 × USB 2.0; Rear panel: 2 × USB 3.0
|
General
|
Power
Supply
|
12
VDC, 2 A
|
Consumption
|
≤ 24 W (without HDD)
|
Working
Temperature
|
-10
°C to + 55 °C (14 °F to 131 °F)
|
Working
Humidity
|
10%
to 90%
|
Dimension
(W × D × H)
|
320 × 240 × 48 mm (12.6 × 9.4 × 1.9 inch)
|
Weight
|
≤ 2 kg (4.4 lb) (without HDD)
|
