Motion
Detection 2.0
|
|
|
Human/Vehicle Analysis
|
Deep learning-based motion detection
2.0 is enabled by default for all analog channels, it can classify human and
vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or
event type is supported;
|
|
|
Perimeter
Protection
|
|
|
Human/Vehicle Analysis
|
Up to 4-ch
|
|
|
Recording
|
|
|
Video compression
|
H.265 Pro+ / H.265 Pro / H.265
/ H.264+ / H.264
|
|
|
Encoding resolution
|
Main stream:
8 MP@8 fps / 5 MP@12 fps / 3K@12
fps/ 4 MP@15 fps / 3 MP@18 fps 1080p / 720p / WD1 / 4CIF / VGA / CIF@25 fps
(P)/30 fps (N)
|
|
|
Sub-stream:
WD1 / 4CIF / CIF @ 25 fps
(P) / 30 fps (N)
|
|
|
Video bit rate
|
32 Kbps to 10 Mbps
|
|
|
Dual stream
|
Support
|
|
|
Stream type
|
Video, Video & Audio
|
|
|
Audio compression
|
G.711u
|
|
|
Audio bit rate
|
64 Kbps
|
|
|
Video
and Audio
|
|
|
IP video input
|
8-ch (up to 24-ch)
Enhanced IP mode on: 16-ch
(up to 32-ch), each up to 4 Mbps
|
|
|
Up to 8 MP resolution
|
|
|
Support
H.265+ / H.265 / H.264+ / H.264 IP cameras
|
|
|
Analog video input
|
16-ch
|
|
|
BNC interface (1.0 Vp-p, 75
Ω), supporting coaxitron connection
|
|
|
HDTVI input
|
8 MP@15 fps, 5 MP@20 fps,
3K@20 fps, 4 MP@30 fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30 fps, 1080p@25 fps,
720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps
|
|
|
AHD input
|
5 MP@20 fps, 4 MP@30 fps,
1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
|
|
|
HDCVI input
|
4 MP@30 fps, 4 MP@25 fps,
1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
|
|
|
CVBS input
|
PAL/NTSC
|
|
CVBS output
|
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576,
NTSC: 704 × 480
|
|
VGA output
|
1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz
HDMI/VGA simultaneous
output
|
|
HDMI output
|
1-ch, 4K (3840 × 2160)/30Hz,
2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output |
|
Audio input
|
1-ch (up to 16-ch is
optional), RCA (2.0 Vp- p, 1 KΩ)
|
|
16-ch via coaxial cable
|
|
Audio output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-way audio
|
1-ch, RCA (2.0 Vp-p, 1 KΩ)
(using the audio input)
|
|
Synchronous playback
|
16-ch
|
|
Network
|
|
Remote connection
|
128
|
|
Network protocol
|
TCP/IP, PPPoE, DHCP, Hik-Connect,
DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
|
Network interface
|
1, RJ45 10/100/1000 Mbps
self-adaptive Ethernet interface
|
|
Wi-Fi
|
Connectable to Wi-Fi
network by Wi-Fi dongle through USB interface
|
|
Auxiliary
interface
|
|
SATA
|
2 SATA interfaces
|
|
Capacity
|
Up to 10 TB capacity for
each disk
|
|
Serial interface
|
RS-485 (half-duplex)
|
|
USB interface
|
Front panel: 1 × USB 2.0
Rear panel: 1 × USB 3.0
|
|
Alarm in/out3
|
N/A (optional to support)
|
|
General
|
|
Power supply
|
12 VDC, 5 A
|
|
Consumption (without HDD)
|
≤ 19 W
|
|
Working temperature
|
-10 °C to +55 °C (+14 °F to
+131 °F)
|
|
Working humidity
|
10% to 90%
|
|
Dimension (W × D × H)
|
380 × 320 × 48 mm (15.0 ×
12.6 × 1.9 inch)
|
|
Weight (without HDD)
|
≤ 2.1 kg (4.6 lb)
|
