Motion Detection 2.0
|
|
Human/Vehicle
Analysis
|
Deep
learning-based motion detection 2.0 is enabled by default for all analog
channels, it can classify human and vehicle, and extremely reduce false
alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
|
|
Perimeter Protection
|
|
Human/Vehicle
Analysis
|
Up to
4-ch
|
|
Facial Detection
|
|
Facial
Detection and Capture
|
Face
picture detection, face picture search
|
|
Recording
|
|
Video
Compression
|
H.265
Pro+ / H.265 Pro / H.265 / H.264+ / H.264
|
|
Encoding
Resolution
|
When
1080p Lite mode is not enabled:
3K lite / 5 MP lite / 4 MP lite / 1080p / 720p;
When 1080p Lite mode is enabled:
3K lite / 5MP lite / 4MP lite / 1080p lite / 720p lite
|
|
Video
Bitrate
|
32 Kbps
to 10 Mbps
|
|
Dual-stream
|
Support
|
|
Stream
Type
|
Video,
Video & Audio
|
|
Audio
Compression
|
G.711u
|
|
Audio
Bitrate
|
64 Kbps
|
|
Video and Audio
|
|
IP Video
Input
|
2-ch
(up to 34-ch)
Enhanced IP mode on:
8-ch (up to 40-ch), each up to 4 Mbps, Up to 6 MP resolution.
Support H.265+ / H.265 / H.264+ / H.264 IP cameras
|
|
Analog
Video Input
|
32-ch
BNC
interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
|
|
HDTVI
Input
|
3K@20
fps, 5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps,1080p@30 fps, 1080p@25 fps,720p@30
fps, 720p@25 fps
|
|
AHD
Input
|
5 MP@20
fps,4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25
fps
|
|
HDCVI
Input
|
5 MP@20
fps,4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25
fps
|
|
CVBS
Input
|
PAL/NTSC
|
|
CVBS
Output
|
1-ch,
BNC (1.0 Vp-p, 75 Ω),
resolution:
PAL: 704 × 576, NTSC: 704 × 480
|
|
HDMI
Output
|
1-ch,
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz,
1280 × 720/60Hz
|
|
VGA
Output
|
1-ch,
1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
HDMI/VGA
simultaneous output
|
|
Audio
Input
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ)，32-ch via coaxial cable
|
|
Audio
Output
|
1-ch,
RCA (Linear, 1 KΩ)
|
|
Two-Way
Audio
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
|
|
Synchronous
playback
|
16-ch
|
|
Network
|
|
Remote
Connection
|
128
|
|
Total
Bandwidth
|
128
Mbps
|
|
Network
Protocol
|
TCP/IP,
PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
|
Network
Interface
|
1,RJ45
10/100/1000 Mbps self-adaptive Ethernet interface
|
|
Wi-Fi
|
Wi-Fi
Connectable to Wi-Fi network by Wi-Fi dongle through USB interface
|
|
Auxiliary Interface
|
|
SATA
|
2 SATA
interfaces
|
|
Capacity
|
Up to
10 TB capacity for each disk
|
|
Serial
Interface
|
RS-485
(half-duplex)
|
|
USB
Interface
|
Front
panel: 1 × USB 2.0
Rear
panel: 1 × USB 3.0
|
|
Alarm
In/Out
|
N/A
(optional to support)
|
|
General
|
|
Power
Supply
|
12 VDC,
5 A
|
|
Consumption
|
≤ 40 W
|
|
Working
Temperature
|
-10
°C to +55 °C (+14 °F to +131 °F)
|
|
Working
Humidity
|
10%
to 90%
|
|
Dimension
(W × D × H)
|
380
× 320 × 48 mm (15.0” × 12.6” × 1.9”)
|
|
Weight
|
≤ 2.1 kg (4.6 lb)
|
