Facial Recognition¹ |
Facial detection and analytics | Face picture comparison, human face capture, face picture search |
Face picture library | Up to 16 face picture libraries, with up to 100,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 20 GB) |
Face picture comparison | 16-ch face picture comparison alarm |
Performance of facial detection and analytics | 8-ch 8 MP human face capture (HD network camera, H.264/H.265) |
Perimeter Protection¹ |
Human/vehicle analysis | Up to 16-ch 4 MP (HD network camera, up to 8 MP, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm |
Video Structuralization¹ |
Structured analysis | Up to 8-ch 2 MP (HD network camera, up to 8 MP, H.264/H.265) live video structuralization analysis |
Face picture library | Up to 16 face picture libraries, with up to 100,000 face pictures in total |
Face picture comparison | 8-ch face picture comparison alarm |
Throwing Objects from Building¹ |
Capability | Up to 8-ch 2 MP (H.264/H.265) video analysis |
Video and Audio |
IP video input | 32-ch |
Up to 12 MP resolution *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. |
Incoming bandwidth | 320 Mbps |
Outgoing bandwidth | 256 Mbps |
HDMI1 output | 1-ch, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
HDMI2 output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
VGA output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
Video output mode | HDMI1/VGA simultaneous output, HDMI2/VGA independent output |
CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω ) |
Audio output | 1-ch, RCA (Linear, 1 KΩ) |
Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
Decoding |
Decoding format | H.265+ / H.265 / H.264+ / H.264 / MPEG4 |
Recording resolution | 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p / 720p *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. |
Synchronous playback | 16-ch |
Capability | 1-ch@32 MP (30 fps)/16-ch@1080p (30 fps) |
Dual stream recording | Support |
Stream type | Video, Video & Audio |
Audio compression | G.711ulaw / G.711alaw / G.722 / G.726 / MP2L2 |
Network |
Remote connections | 128 |
Network protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
Network interface | 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
Auxiliary interface |
Serial port | RS-485 (half-duplex), RS-232, keyboard |
SATA | 4 SATA interfaces |
eSATA | 1 eSATA interface |
Capacity | Up to 10 TB capacity for each disk |
Alarm in/out | 16/8 |
USB interface | Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
General |
Power supply | 100 to 240 VAC, 50 to 60 Hz |
Consumption (without HDD) | ≤ 30 W |
Working temperature | -10 °C to 55 °C (14 °F to 131 °F) |
Working humidity | 10% to 90% |
Chassis | 19-inch rack-mounted 1.5U chassis |
Dimension (W × D × H) | 445 × 400 × 75 mm (17.5"× 15.7" × 3.0") |
Weight (without HDD) | ≤ 5 kg (11 lb ) |
Certification |
Obtained Certification | FCC, CE, UL, CB, WEEE, BIS, IC, RCM, KC, LOA |
CE | EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
FCC | Part 15 Subpart B, ANSI C63.4-2014 |
