Perimeter Protection
|
False
alarm reduction
|
Up
to 16-ch 4 MP (HD network camera, up to 8MP, H.264/H.265)
Video
analysis for human and vehicle recognition to reduce false alarm
|
Video and Audio
|
IP
video input
|
64-ch
|
Up
to 12 MP resolution
*:
32 MP and 24 MP is only available for channel 1 when ultra-HD resolution mode
is enabled.
|
Incoming/outgoing
bandwidth
|
320
Mbps / 256 Mbps
|
Incoming/outgoing
bandwidth (RAID mode)
|
200
Mbps / 200 Mbps
|
HDMI1
output
|
1-ch,
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 ×
1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
|
HDMI2
output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
|
VGA1
output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
VGA2
output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
Video
output mode
|
HDMI1/VGA1
simultaneous output,
HDMI2/VGA2
simultaneous output
|
CVBS
output
|
N/A
|
Audio
output
|
2-ch,
RCA (Linear, 1 KΩ)
|
Two-way
audio input
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ)
|
Decoding
|
Decoding
format
|
H.265
/ H.265+ / H.264 / H.264+ / MPEG4
|
Recording
resolution
|
32MP
/ 24MP / 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA
*:
32 MP and 24 MP is only available for channel 1 when ultra-HD resolution mode
is enabled.
|
Synchronous
playback
|
16-ch
|
Capability
|
1-ch@32
MP (30 fps) / 16-ch@1080p (30 fps)
|
Dual
stream recording
|
Support
|
Stream
type
|
Video,
Video & Audio
|
Audio
compression
|
G.711ulaw
/ G.711alaw / G.722 / G.726 / MP2L2
|
Network
|
Remote
connections
|
128
|
Network
protocol
|
TCP/IP,
DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™,
HTTP, HTTPS
|
Network
interface
|
2,
RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
RAID
|
RAID
Type
|
RAID0,
RAID1, RAID5, RAID6, RAID10
|
Auxiliary interface
|
Serial
port
|
RS-232;
RS-485; Keyboard
|
SATA
|
8
SATA interfaces
|
Capacity
|
Up
to 10 TB capacity for each disk
|
eSATA
|
1
eSATA interface
|
Alarm
in/out
|
16/8
|
USB
interface
|
Front
panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
|
General
|
Power
supply
|
100
to 240 VAC, 50 to 60 Hz
|
Consumption
(without HDD)
|
≤ 70 W
|
Working
temperature
|
-10
to +55° C (+14 to +131° F)
|
Working
humidity
|
10%
to 90%
|
Dimension
(W × D × H)
|
445
× 465 × 92 mm (17.5"× 18.3" × 3.6")
|
Weight
(without HDD)
|
≤ 10 kg (22 lb)
|
Certification
|
Obtained
Certification
|
CE,
FCC, UL, CB, WEEE, BIS, IC, RCM, KC, LOA
|
FCC
|
Part
15 Subpart B, ANSI C63.4-2014
|
CE
|
EN
55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
|
