Facial Recognition¹
|
|
Facial
detection and analytics
|
Face
picture comparison, human face capture, face picture search
|
|
Face
picture library
|
Up
to 32 face picture libraries, with up to 100,000 face pictures in total (each
picture ≤ 4 MB, total capacity ≤ 20 GB)
|
|
Face
picture comparison
|
16-ch
face picture comparison alarm
|
|
Performance
of facial detection and analytics
|
8-ch
8 MP human face capture (HD network camera, H.264/H.265)
|
|
Perimeter Protection¹
|
|
False
alarm reduction
|
Up
to 16-ch 4 MP (HD network camera, up to 8 MP, H.264/H.265) video analysis for
human and vehicle recognition to reduce false alarm
|
|
Video Structuralization¹
|
|
Structured
analysis
|
Up
to 8-ch 2 MP (HD network camera, up to 8 MP, H.264/H.265) live video
structuralization analysis
|
|
Face
picture library
|
Up
to 32 face picture libraries, with up to 100,000 face pictures in total
|
|
Face
picture comparison
|
8-ch
face picture comparison alarm
|
|
Throwing Objects from Building¹
|
|
Capability
|
Up
to 8-ch 2 MP (H.264/H.265) video analysis
|
|
Video and Audio
|
|
IP
video input
|
64-ch
|
|
Up
to 12 MP resolution
*:
32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode
is enabled.
|
|
Incoming/outgoing
bandwidth
|
320
Mbps/256 Mbps
|
|
Incoming/outgoing
bandwidth (RAID mode)
|
200
Mbps/200 Mbps
|
|
HDMI1
output
|
1-ch,
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920
×
1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
|
|
HDMI2
output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
VGA1
output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
VGA2
output
|
1-ch,
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
Video
output mode
|
HDMI1/VGA1
simultaneous output, HDMI2/VGA2 simultaneous output
|
|
CVBS
output
|
N/A
|
|
Audio
output
|
2-ch,
RCA (Linear, 1 KΩ)
|
|
Two-way
audio input
|
1-ch,
RCA (2.0 Vp-p, 1 KΩ)
|
|
Decoding
|
|
Decoding
format
|
H.265
/ H.265+ / H.264 / H.264+ / MPEG4
|
|
Recording
resolution
|
32MP
/ 24MP / 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA
*:
32 MP and 24 MP is only available for channel 1 when ultra-HD resolution mode
is enabled.
|
|
Synchronous
playback
|
16-ch
|
|
Capability
|
1-ch@32
MP (30 fps)/16-ch@1080p (30 fps)
|
|
Dual
stream recording
|
Support
|
|
Stream
type
|
Video,
Video & Audio
|
|
Network
|
|
Remote
connections
|
128
|
|
Network
protocol
|
TCP/IP,
DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™,
HTTP, HTTPS
|
|
Network
interface
|
2,
RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
RAID
|
|
RAID
Type
|
RAID0,
RAID1, RAID5, RAID6, RAID10
|
|
Auxiliary interface
|
|
Serial
port
|
RS-232;
RS-485; Keyboard
|
|
SATA
|
8
SATA interfaces
|
|
Capacity
|
Up
to 10 TB capacity for each disk
|
|
eSATA
|
1
eSATA interface
|
|
Alarm
in/out
|
16/8
|
|
USB
interface
|
Front
panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
|
|
General
|
|
Power
supply
|
100
to 240 VAC, 50 to 60 Hz
|
|
Consumption
(without HDD)
|
≤ 70 W
|
|
Working
temperature
|
-10
to +55° C (+14 to +131° F)
|
|
Working
humidity
|
10%
to 90%
|
|
Dimension
(W × D × H)
|
445
× 465 × 92 mm (17.5"× 18.3" × 3.6")
|
|
Weight
(without HDD)
|
≤ 10 kg (22 lb)
|
|
Certification
|
|
Obtained
Certification
|
FCC,
CE, UL, CB, WEEE, BIS, IC, RCM, KC, LOA
|
|
CE
|
EN
55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
|
|
FCC
|
Part
15 Subpart B, ANSI C63.4-2014
|
