Intelligent Analytics
|
|
AI
by NVR
|
Facial
recognition, perimeter protection, video structuralization, throwing objects
from building
|
|
AI
by Camera
|
Facial
recognition, perimeter protection, video structuralization, throwing objects
from building, motion detection 2.0, ANPR, people counting, VCA
|
|
Engine
|
2,
each engine can run an intelligent algorithm, engine mode is adjustable
|
|
Facial Recognition
|
|
Facial
Detection and Analytics
|
Face
picture comparison, human face capture, face picture search
|
|
Face
Picture Library
|
Up
to 32 face picture libraries, up to 100,000 face pictures in list library, up
to 10,000 face pictures in stranger library, up to 10,000,000 face pictures
in face capture (each picture ≤ 4
MB, total capacity ≤ 20
GB)
|
|
Face
Picture Comparison
(Captured
from Camera)
|
48-ch
(24-ch for each engine);
Comparison
speed: 48 pictures per second
|
|
Facial
Detection and Analytics performance
|
16-ch
2 MP (8-ch for each engine), up to 8 MP
|
|
Perimeter Protection
|
|
By
NVR
|
24-ch
2 MP (12-ch for each engine), up to 8 MP
|
|
By
Camera
|
All
channels
|
|
Video Structuralization
|
|
Structured
Analysis
|
12-ch
2 MP (6-ch for each engine), up to 8 MP
|
|
Face
Picture Library
|
Up
to 32 face picture libraries, up to 100,000 face pictures in list library, up
to 10,000 face pictures in stranger library,
up to 10,000,000 face pictures in face capture (each picture ≤ 4 MB, total capacity ≤ 20 GB)
|
|
Face
Picture Comparison
|
16-ch;
Comparison
speed: 32 pictures per second
|
|
Throwing Objects from Building
|
|
By
NVR
|
16-ch
2 MP (8-ch for each engine), up to 8 MP)
|
|
By
Camera
|
All
channels
|
|
ANPR
|
|
By
Camera
|
All
channels
|
|
Plate
Attributes
|
Plate
number, license plate color, license plate type
|
|
Vehicle
Attributes
|
Vehicle
brand, vehicle color, vehicle type
|
|
Video and Audio
|
|
|
IP
Video Input
|
64-ch
Up
to 32 MP resolution
*:
After ultra-HD resolution mode is enabled, the NVR supports up to 8-ch 32
MP/24 MP IP video inputs.
|
|
|
Incoming
Bandwidth
|
400
Mbps
|
|
|
Outgoing
Bandwidth
|
400
Mbps
|
|
|
HDMI
1 Output
|
8K (7680
× 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/6
0Hz, 1920 × 1080/60Hz, 1600 ×1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
|
|
|
HDMI
2 Output
|
4K (3840
× 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz,
1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
*:
When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is
1080p.
|
|
|
VGA
1 Output
|
1920
× 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
|
VGA
2 Output
|
1920
× 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
|
Video
Output Mode
|
HDMI1/VGA1
simultaneous output, HDMI2/VGA2 simultaneous output
|
|
|
CVBS
Output
|
1-ch,
BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
|
|
|
Audio
Output
|
2-ch,
RCA (Linear, 1 KΩ)
|
|
|
Two-Way
Audio
|
1-ch,
RCA (2.0 Vp-p, 1 k Ω)
|
|
|
Decoding
|
|
|
Decoding Format
|
H.265
/ H.265+ / H.264 / H.264+
|
|
|
Decoding
Capability
|
2-ch@32MP
(30 fps) / 2-ch@24MP (30 fps) / 4-ch@12MP (20 fps) / 8-ch@8MP (25 fps) / 16-ch@4MP
(30 fps) / 32-ch@1080p (30 fps)
|
|
|
Synchronous
Playback
|
16-ch
|
|
|
Recording
Resolution
|
32 MP/24
MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p
*: After ultra-HD resolution mode is enabled, the NVR supports up to 8-ch 32
MP/24 MP IP video inputs.
|
|
|
Network
|
|
|
Remote
Connection
|
128
|
|
|
Network
Protocol
|
TCP/IP,
DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™,
HTTP, HTTPS
|
|
|
Network
Interface
|
2,
RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
|
RAID
|
|
|
RAID
Type
|
RAID0,
RAID1, RAID5, RAID6, RAID10
|
|
|
Auxiliary Interface
|
|
|
DC
12V
|
12
VDC, 1 A power output
|
|
|
SATA
|
8
SATA interfaces; 3.5-inch HDD
|
|
|
eSATA
|
1
eSATA interface
|
|
|
Capacity
|
Up
to 14 TB capacity for each HDD
|
|
|
Serial
Interface
|
1
RS-232, 1 RS-485 (full-duplex), 1 keyboard
|
|
|
USB
Interface
|
Front
panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
|
|
|
Alarm
In/Out
|
16/9
|
|
|
General
|
|
|
Power
Supply
|
100
to 240 VAC, 50 to 60 Hz
|
|
|
Consumption
|
≤ 50 W (without HDD)
|
|
|
Working
Temperature
|
-10
to 55° C (14 to 131° F)
|
|
|
Working
Humidity
|
10
to 90%
|
|
|
Dimension
(W × D × H)
|
445
× 465 × 93 mm (17.5"× 18.3" × 3.7")
|
|
|
Weight
|
≤ 10 kg (without HDD, 28.7 lb.)
|
|
|
Certification
|
|
|
Obtained
Certification
|
CE,
FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
|
|
|
FCC
|
Part
15 Subpart B, ANSI C63.4-2014
|
|
