Camera
|
|
|
Sensor
|
1/3",
4MP, progressive scan, CMOS
|
|
|
Minimum
Illumination
|
Color:
0.003 lux (F1.6, AGC ON)
|
|
|
Day/Night
|
IR-cut
filter with auto switch (ICR)
|
|
|
Adjustment
Angle
|
Pan:
0° ~ 360°; Tilt: 0° ~ 90°; Rotate: 0° ~ 360°
|
|
|
S/N
|
>52dB
|
|
|
WDR
|
120dB
|
|
|
Lens
|
|
|
Lens
Type
|
4.0mm
@F1.6
|
|
|
Iris
|
Fixed
|
|
|
Field
of View (H)
|
91.2°
|
|
|
Field
of View (V)
|
47.9°
|
|
|
Field
of View (D)
|
95.9°
|
|
|
DORI
|
|
|
DORI
Distance
|
Detect
(m): 90; Observe (m): 36; Recognize (m): 18; Identify(m): 9.0
|
|
|
Illuminator
|
|
|
IR
Range
|
Up
to 30m (98ft) IR range
|
|
|
White
Light Range
|
Up
to 30m (98ft) white light range
|
|
|
Wavelength
|
IR：850nm
|
|
|
IR
On/Off Control
|
Auto/Manual
|
|
|
Video
|
|
|
Video
Compression
|
Ultra
265, H.265, H.264, MJPEG
|
|
|
H.264
Code Profile
|
Baseline
profile, Main profile, High profile
|
|
|
Frame
Rate
|
Main
Stream: 4MP (2688*1520), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP
(2304*1296), Max 30fps; 1080P (1920*1080), Max
30fps;
720P (1280*720), Max 30fps;
Sub
Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360, Max
30fps;
|
|
|
Video
Bit Rate
|
128
Kbps~16 Mbps
|
|
|
OSD
|
Up
to 4 OSDs
|
|
|
Privacy
Mask
|
Up
to 4 areas
|
|
|
ROI
|
Up
to 8 areas
|
|
|
|
|
|
White
Balance
|
Auto
/ Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
|
|
Digital
Noise Reduction
|
2D/3D
DNR
|
|
Smart
IR
|
Support
|
|
Flip
|
Normal
/ Vertical / Horizontal / 180° / 90°Clockwise / 90°Anti-clockwise
|
|
HLC
|
Supported
|
|
BLC
|
Supported
|
|
Defog
|
Digital
Defog
|
|
Events
|
|
Basic
Detection
|
Cross
line, intrusion (based on human body detection), motion detection, Ultra
motion detection, tampering alarm, audio detection
|
|
General
Function
|
Watermark,
IP address filtering, access policy, ARP protection, RTSP authentication,
user authentication, HTTP authentication
|
|
Audio
|
|
Audio
Compression
|
G.711U,
G.711A
|
|
Audio
Bitrate
|
64
Kbps
|
|
Two-way
Audio
|
Support
|
|
Suppression
|
Support
|
|
Sampling
Rate
|
8KHZ
|
|
Storage
|
|
Edge
Storage
|
MicroSD
Slot, up to 128GB
|
|
Network
Storage
|
ANR,
NAS(NFS)
|
|
Network
|
|
Protocols
|
IPv4,
IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP,
FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS, 802.1x, SNMP
|
|
Compatible
Integration
|
ONVIF
(Profile S, Profile G, Profile T), API, SDK
|
|
User/Host
|
Up
to 32 users. 2 user levels: administrator and common user
|
|
Security
|
Password
protection, Strong password, HTTPS encryption, Export operation logs, Basic
and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2,
WSSE and digest authentication for ONVIF
|
|
Interface
|
|
Built-in
Mic
|
Support
|
|
Built-in
Speaker
|
Support
|
|
Network
|
1 *
RJ45 10M/100M Base-TX Ethernet
|
|
Interface
|
|
Power
|
DC
12V±25%, PoE (IEEE 802.3af) Power consumption: Max 9.0W
|
|
Power
Interface
|
Ø
5.5mm coaxial power plug
|
|
Dimensions
(L × W × H)
|
191×75×74mm
(7.5” ×2.9” × 2.9”)
|
|
Weight
|
0.41kg
(0.90lb)
|
|
Working
Environment
|
-30°C
~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
|
|
Storage
Environment
|
-30°C
~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
|
|
Surge
Protection
|
4KV
|
|
Reset
Button
|
N/A
|
