T-B60

ITC T-B60 60W Mini Mixer Amplifier with MP3/Bluetooth, 1 Microphone audio input with independent volume control, 2 line audio inputs with independent volume control, Support priority function, Speaker Output: 4~16Ω/100V, Input Sensitivity& Source: MIC Input: +5mV, unbalanced 6.3 connector, Impedance: AUX Input: 350mV, unbalanced RCA connector, Tone: Bass: 100Hz±10dB, Treble: 10KHz±10dB, Frequency Response: 80Hz~16KHz(-3dB), SNR: ≥75dB, T.H.D: Rated power output, distortion rate≤1%, ~220V 50Hz.

https://www.esco.pk/web/image/product.template/13329/image_1920?unique=003a51d

    Rs. 0.00 0.0 PKR Rs. 0.00

    Not Available For Sale

    This combination does not exist.

    Add to Cart
    Add to wishlist Compare

    Please get in touch for pricing & availability.

    Contact Us
    ITC

    Is our price higher than expected or showing as zero? Chat with us now for the best price and product availability. Prices if shown are inclusive of applicable taxes. Tax rate may be adjusted as per customer's taxation status. For supply of product only, excluding any cabling and/or installation. Shipping charges can sometimes vary.

    ​

    Digital Bluetooth Amplifier

    ITC T-B60 60W Mini Mixer Amplifier with MP3/Bluetooth

    Speaker Output

    Superior sound quality & speech intelligibility, support constant resistance 4~16Ω output, or 100V output.

    Protection

    Overheating protection, short circuit protection, overload protection

    Bluetooth

    Integrated Bluetooth module, support playing music through mobile phone Bluetooth.

    Input

    1 Microphone audio input with independent volume control,
    2 line audio inputs with independent volume control

    MP3 Function Module

    With MP3 function module, support playback of various file formats in U disk such as MP3, WMA, APE, FLAC, WAV, and AAC; with TF card.

    Description:

    It is a desktop mini constant voltage amplifier featuring beautiful appearance and light weight, which can be used for BGM playback and broadcast in small indoor venues such as homes, leisure cafes, classrooms, etc.

    Features:

    * Desktop amplifier, beautiful appearance, light weight, and portable design.

    * Suitable for different sound effect venues; the series includes 20W, 40W and 60W options.

    * Superior sound quality and speech intelligibility, support constant resistance 4~16Ω output, or 100V output; it can play beautiful music in short distances, and can also broadcast beautiful sounds in long distances.

    * The output terminal adopts standard 6.3 audio microphone jack and the line input uses RCA socket, providing users with different audio input interface selections.

    * 1 Microphone audio input with independent volume control.

    * 2 line audio inputs with independent volume control.

    * Support automatic playback of MP3 audio format music and power-off memory function.

    * Support priority function, the MIC1 input is prior to other audio signal inputs.

    * Designed with power indicator, when the mains power is connected and the power switch is turned on, the indicator turns blue.

    * Designed with signal indicator, the indicator color changes according to different signal outputs.

    * Support short circuit, overload, over temperature and other protection functions.

    * Equipped with MP3 function module, LCD display, support the playback of U disk MP3, WMA, APE, FLAC, WAV, AAC and other file formats, support TF card, and mobile phone Bluetooth function, support music name display.

    Specifications

    Rated Output Power

    60W

    Speaker Output

    4~16Ω/100V

    Input Sensitivity& Source

    MIC Input: +5mV, unbalanced 6.3 connector

    Impedance

    AUX Input: 350mV, unbalanced RCA connector

    Tone

    Bass: 100Hz±10dB, Treble: 10KHz±10dB

    Frequency Response

    80Hz~16KHz (-3dB)

    SNR

    ≥75dB

    T.H.D

    Rated power output, distortion rate≤1%

    Priority Function

    MIC1 input has the priority than other input

    Protection

    Overheating protection, short circuit protection, overload protection

    Input Power

    ~220V  50Hz

    Power Consumption

    120W

    Dimension

    284 x 188 x 66.5mm

    Weight

    4.2Kg
