Camera
|
Sensor
|
1/2.7"
Progressive Scan CMOS
|
Min.
Illumination
|
Color:
0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR
|
Shutter
Speed
|
1/3
s to 1/100, 000 s
|
Slow
Shutter
|
Yes
|
Wide
Dynamic Range
|
Digital
WDR
|
Day
& Night
|
IR cut
filter
|
Angle
Adjustment
|
Pan:
0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
|
Lens
|
Focal
Length & FOV
|
4 mm,
horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
|
Lens
Mount
|
M12
|
Focus
|
Fixed
|
Aperture
|
F2.0
|
Illuminator
|
IR
Wavelength
|
850
nm
|
IR
Range
|
Up to
30 m
|
Video
|
Max.
Resolution
|
1920
× 1080
|
Main
Stream
|
50 Hz:
25 fps (1920 × 1080, 1280 × 720)
60 Hz:
30 fps (1920 × 1080, 1280 × 720)
|
Sub-Stream
|
50 Hz:
25 fps (640 × 480, 640 × 360)
60 Hz:
30 fps (640 × 480, 640 × 360)
|
Video
Compression
|
Main
Stream: H.265/H.264
Sub-Stream:
H.265/H.264
|
Video
Bit Rate
|
32 Kbps
to 8 Mbps
|
H.264
Type
|
Baseline
Profile / Main Profile / High Profile
|
H.265
Type
|
Main
Profile
|
H.264+
|
Main
Stream supports
|
H.265+
|
Main
Stream supports
|
Region
of Interest (ROI)
|
1 fixed
region for main stream
|
Audio
|
Audio
Compression
|
G.711ulaw
/ G.711alaw / G.722.1 / G.726 / MP2L2 / PCM/AAC
|
Audio
Bit Rate
|
64 Kbps
(G.711ulaw / G.711alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 160 Kbps
(MP2L2) / 16 to 64 Kbps (AAC)
|
Audio
Sampling Rate
|
8 kHz/16
kHz
|
Environment
Noise Filtering
|
Yes
|
Network
|
Protocols
|
TCP/IP,
ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP,
802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
|
Simultaneous
Live View
|
Up to
6 channels
|
Network
Storage
|
MicroSD
/ SDHC / SDXC card (256 GB) local storage
|
|
Settings
|
Saturation,
brightness, contrast, sharpness, AGC, white balance adjustable by client software
or web browser.
|
Day/Night
Switch
|
Day,
Night, Auto, Schedule
|
Enhancement
|
BLC,
3D DNR
|
Interface
|
Ethernet
Interface
|
1 RJ45
10 M/100 M self-adaptive Ethernet port
|
On-Board
Storage
|
Built-in
memory card slot, support microSD card, up to 256 GB
|
Built-in
Microphone
|
Yes
|
Hardware
Reset
|
Yes
|
Event
|
Basic
Event
|
Motion
detection, video tampering alarm, exception
|
General
|
Linkage
Method
|
Upload
to FTP/memory card, notify surveillance center, send email, trigger recording,
trigger
capture
|
Camera
Material
|
Metal
& Plastic
|
Camera
Dimension
|
177.6
mm × 66.2 mm × 67.8 mm (7.0" × 2.6" × 2.7")
|
Package
Dimension
|
216
mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
|
Camera
Weight
|
Approx.
270 g (0.6 lb.)
|
With
Package Weight
|
Approx.
490 g (1.1 lb.)
|
Storage
Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
|
Startup
and Operating Conditions
|
-30
°C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
|
General
Function
|
Anti-flicker,
heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
Power
Consumption and Current
|
12 VDC,
0.4 A, max. 5 W
PoE:
(802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W
|
Power
Supply
|
12 VDC
± 25%
PoE:
802.3af, Class 3
|
Power
Interface
|
Ø5.5
mm coaxial power plug
|
Approval
|
EMC
|
FCC
SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014,
EN 61000-3-3:
2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
VoC
(ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
|
Safety
|
UL (UL
60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD
(EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS
13252(Part 1):2010+A1:2013+A2:2015)
|
Environment
|
CE-RoHS
(2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
|
Protection
|
IP67
(IEC 60529-2013)
|
