Key specs
- P0.9 indoor LED module
- Pixel pitch 0.9375 mm
- Module 300 × 168.75 mm, 320 × 160 pixels
- Brightness 600 cd/m²
- Refresh rate 3840 Hz, grey level 16 bit
- Regular Chip MIP
- 4 modules per DS-D40W-2F cabinet structure
- Power max. ≤ 373 W/m² (600 cd/m²), average ≤ 125 W/m²
- Front maintenance for all components
| Product Type | |
|---|---|
| Product Type | Small Pixel Pitch Indoor Full-color LED Display |
| Cabinet | |
| Pixel Configuration | Regular Chip MIP |
| Pixel Pitch | 0.9375 mm |
| Pixel Pitch Category | P0.9 |
| Pixel Density | 1137777 dots/m² |
| Modules Component | 2 × 2 |
| Dimensions (W × H × D) | 600 mm × 337.5 mm × 29.5 mm |
| Resolution | 640 × 360 |
| Area | 0.2025 m² |
| Cabinet Material | Aluminium die casting |
| Maintenance Method | Front maintenance for all components |
| Module | |
| Dimensions | 300 × 168.75 mm |
| Module Resolution | 320 × 160 |
| Display | |
| White Balance Brightness | 600 cd/m² |
| Color Temperature | 3000-10000 K adjustable |
| Viewing Angle | 160°(H)/160°(V) |
| Contrast Ratio | 10000:1 |
| Color Uniformity | ≤ ± 0.003Cx, Cy |
| Brightness Uniformity | ≥ 97% |
| Processing Performance | |
| Driving Method | Constant current driving |
| Frame Frequency | 60 Hz |
| Refresh Rate | 3840 Hz |
| Grey Level | 16 bit |
| Power | |
| Max. Consumption | ≤ 373 W/m² (600 cd/m²) |
| Average Consumption | ≤ 125 W/m² |
| Input Voltage | 100 to 240 VAC ± 10% |
| Working Environment | |
| Working Temperature | -10 °C to 40 °C |
| Working Humidity | 10% to 60% RH (without condensation) |
| General | |
| Package | module 4-in-1 (443 × 360 × 52 mm), structure 5-in-1 |
| Bracket | |
| Modular Bracket | standard bracket DP-D40XXCB22-1X1-Q0.3-NW-Q0.3-HC 1*1, DP-D40XXCB22-2X2-Q0.8-NW-Q0.8-HC 2*2; ultra-thin bracket DP-D40XXCB22-1X1-Q0.2-NW-Q0.2-ZF |
Know before you buy
Quick answers about the DS-D4009AW-2FQ/A 0.9mm 300*168.75 Module, and how it compares.
How many modules do I need?
Divide the screen width by 0.3 m and the height by 0.16875 m. For example, a 2.4 m × 1.35 m screen takes 8 × 8 = 64 modules, 2560 × 1280 pixels (3.28 MP). Our engineers size it for your wall and add the cabinet structures and controller.
What else does an LED screen need?
DS-D40W-2F cabinet structures (one per four modules) with their receiving card, HUB and power parts, an LED controller, a wall bracket or frame, power and network cabling, and installation. See What you need above; our engineers prepare the full BOQ.
Can it be used outdoors?
No, it is an indoor module (600 cd/m²). For outdoor screens use our outdoor LED modules, P3 to P8, IP65 front.
How much power does it use?
Up to 373 W/m² (600 cd/m²) and about 125 W/m² on average (Hikvision figures). Our engineers size the power and the cabling for the whole screen.
Can I buy it online?
LED screens are installed products, so we start with a free pre-sales consultation: our engineers confirm the right models and quantities for your site and send a quote. Use Request a Quote on this page, contact us or WhatsApp +92 300 ESCO 301. Offices in Karachi, Lahore, Islamabad and Rawalpindi.
