Key specs
- P1.5 indoor LED display cabinet
- Cabinet 600 × 337.5 mm, 384 × 216 pixels
- Pixel pitch 1.56 mm, Surface mounted trinity LED
- Brightness 600 cd/m² (up to 800 cd/m²)
- Refresh rate up to 3840 Hz, grey level up to 16 bit
- Contrast ≥ 3000:1
- Front maintenance for all components
- Power max. ≤ 750 W/m², average < 280 W/m²
| General | |
|---|---|
| Working Temperature | -10 °C to 40 °C |
| Working Humidity | 10% to 80% RH (non-condensing) |
| Independent Package Material | Corrugated Paper |
| Exterior Package Type | Corrugated Case |
| Wooden Box Dimensions | 1035 × 875 × 605 mm (40.75 × 34.45 × 23.82 inch) |
| Wooden Box Material | 5 A Plywood |
| Cabinet | |
| Pixel Structure | Surface mounted trinity LED |
| Pixel Pitch | 1.56 mm |
| Modules Component | 1 × 2 |
| Dimensions | 600 (W) × 337.5 (H) × 61 (D) mm (23.62 × 13.29 × 2.40 inch) |
| Resolution | 384 × 216 |
| Area | 0.2025 m² |
| Weight | 8.3 kg |
| Pixel Density | 409600 dots/m² |
| Cabinet Material | Magnalium |
| Maintenance Method | Front maintenance for all components. Power supply can be maintained from both front and rear. |
| Processing Performance | |
| Driving Method | Constant current driving |
| Frame Frequency | 60 Hz |
| Refresh Rate | Up to 3840 Hz |
| Grey Level | Up to 16 bit |
| Display | |
| Viewing Angle | Horizontal 160°, vertical 160° |
| Contrast Ratio | ≥ 3000:1 |
| White Balance Brightness | 600 cd/m² by default. Up to 800 cd/m². |
| Color Temperature | 3000 to 10000 adjustable |
| Brightness Uniformity | ≥ 97% |
| Color Uniformity | ≤ ± 0.003Cx, Cy |
| Electrical | |
| Power Supply | 100 to 240 VAC ± 15% |
| Max. Consumption | ≤ 750 W/m² |
| Average Consumption | < 280 W/m² |
Know before you buy
Quick answers about the DS-D4215FI-CWF, and how it compares.
How many cabinets do I need?
Divide the screen width by 0.6 m and the height by 0.3375 m. For example, 4 × 4 = 16 cabinets make a 2.4 m × 1.35 m screen of 1536 × 864 pixels (1.33 MP). At 0.65 MP per network port (Hikvision), the controller needs 3 ports for it.
How is it serviced?
Front maintenance for all components. Power supply can be maintained from both front and rear. Modules come off from the front with the front maintenance tool.
Can it be used outdoors?
No, it is an indoor cabinet (600 cd/m² (up to 800 cd/m²)). For outdoor screens ask our engineers for an outdoor cabinet or outdoor modules.
How much power does it use?
Up to 750 W/m² and about 280 W/m² on average (Hikvision figures).
Can I buy it online?
LED screens are installed products, so we start with a free pre-sales consultation: our engineers confirm the right models and quantities for your site and send a quote. Use Request a Quote on this page, contact us or WhatsApp +92 300 ESCO 301. Offices in Karachi, Lahore, Islamabad and Rawalpindi.
