Clear, balanced vocals
A balanced frequency response supports clear vocals for live singing and spoken-word performances.
| Specification | Value |
|---|---|
| Element type | Dynamic |
| Magnet structure | Neodymium |
| Polar pattern | Supercardioid |
| Frequency response | 80 Hz–16,000 Hz |
| Sensitivity — open-circuit voltage at 1 kHz | 2.2 mV/Pa (−53 dBV) |
| Rated impedance | 600 Ω |
| Polarity | Positive diaphragm pressure produces positive voltage on pin 2 relative to pin 3 |
| Specification | Value |
|---|---|
| Microphone connector | 3-pin XLR-type |
| Switch | On/off switch |
| Switch locking | Can be locked in the ON position |
| Specification | Value |
|---|---|
| Finish | Textured black satin handle |
| Grille | Fine-mesh Memraflex™ |
| Capsule mounting | Shock-mounted |
| Length | 184.0 mm (7.23 in) |
| Width | 53.0 mm (2.10 in) |
| Shank diameter | 23.6 mm (0.93 in) |
| Net weight | 294 g (10.4 oz) |
| Shipping weight | 547 g (19.3 oz) |
| Item | Description |
|---|---|
| Stand adapter | Includes Euro-thread insert |
| Carrying bag | Soft zippered gig bag |
Quick answers about the PL24S, and how it compares.
A dynamic supercardioid handheld vocal microphone with a lockable on/off switch, 80 Hz to 16 kHz, XLR. No phantom power or battery.
The supercardioid pickup rejects sound from the sides and from monitors. Hold it close and point it at the mouth; no microphone removes feedback on its own.
No, it is a passive dynamic mic. Plug it into any XLR mic input: Dynacord U Series, PM3000-X, VZX-8 or a powered speaker.
Singing 0 to 6 in (0 to 15 cm) for more bass, speech 5 to 10 in (13 to 25 cm). Closer than 6 in adds bass through the proximity effect.
Stand adapter with Euro-thread insert and a zipped soft bag.
ESCO is the authorised Electro-Voice distributor in Pakistan. Ask us for the price, stock and a quotation.
