Camera
|
|
Sensor Type
|
Optical: 1/2.7" Progressive Scan CMOS Flame: 4.3um (main) + 5.0um (auxiliary) + 3.8um (auxiliary)
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
25 fps (2560 × 1440, 1920 × 1080, 1600 × 1200, 1280 × 720)
|
|
Sub Stream
|
25 fps (704 × 576, 640 × 480, 352 × 288)
|
|
Min. Illumination
|
Color: 0.015 Lux@ (F1.6, AGC ON)
|
|
Lens
|
4 mm, F1.6
|
|
FoV
|
Horizontal: 84°, Vertical: 43°
|
|
Image Settings
|
Saturation, brightness, contrast, sharpness, AGC & white balance can be adjusted through the client or browser.
|
|
Shutter
|
1/25 ~ 1/100,000 s
|
|
WDR
|
120 dB
|
|
Day/Night Switch
|
Full color
|
|
Image Enhancement
|
Backlight compensation, 3D digital noise reduction, gray scale range adjustment
|
|
Sub Stream Compression Standard
|
H.265, H.264
|
|
Main Stream Video Compression Standard
|
H.265, H.264
|
|
Video Bitrate
|
256Kbps~8Mbps
|
|
Intelligent Alarm
|
Motion Detection, Video tampering alarm, Intrusion detection, Boundary violation detection, Smoke and fire detection
|
|
Protocol
|
TCP/IP, FTP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UDP
|
|
Interface Protocol
|
ONVIF (PROFILE S, PROFILE G), ISAPI, EZVIZ
|
|
WEB Configuration
|
Support web preview, configuration and parameter import/export
|
|
General
|
Reset, anti-flicker, heartbeat, mirror, password protection, video occlusion, IP address filtering
|
|
Storage
|
MicroSD/SDHC/SDXC card (128 G), disconnection local storge
|
|
Exception Detection
|
Network cable disconnection, IP conflict, Invalid access, Full memory, Memory error
|
|
Power Consumption
|
≤10 W
|
|
IR Range
|
< 30 m
|
|
Accessory Type
|
Wall mounted support, pendent support, universal joint
|
|
Detector
|
|
Fire and Smoke Detection
|
Yes
|
|
Detection Range
|
< 50m
|
|
Alarm Indicator Light
|
One, Red: Alarm; Green: Normal; Yellow: Fault
|
|
Function
|
|
Remote Silence
|
Yes
|
|
Interface
|
|
Alarm Interface
|
2-way alarm input (Alarm in), 2-way alarm output (Alarm out, support DC 30V/2A or AC 125V/0.5A)
|
|
Audio Interface
|
1 way audio input (Line in), 1 way audio output (Line out)
|
|
General
|
|
Using Environment
|
Temperature: -20 °C~60 °C, humidity: less than 95% (on condensing)
|
|
Ingress Protection
|
IP66
|
|
Communication Interface
|
RJ45 10 M/100 M adaptive Ethernet port * 1, support PoE power supply; RS-485 interface * 1
|
|
Mounting Height
|
Indoor: higher than 2.5 m
Outdoor: higher than 3.5 m
|
|
Power Interface Type
|
3pin industrial terminal, spacing: 3.81
|
|
Power
|
DC 9V~DC 36V, 24W MAX; PoE: 802.3at, CLASS 4
|
|
Product Implementation Standard
|
Q/HKD 035－2022
|
|
Weight
|
1.4 kg (without packing), 1.7 kg (with packing)
|
|
Dimension (L × W × H)
|
212.5 mm × 130.0 mm × 84.8 mm
|
